UPdate Intraday TS ,BB + Buy/Sell +Squeeze Mom.+ adx-dmi — Indicador por MarcoValente

Update version with legend on data window and new colors on the squeeze mom idicator

Script de código aberto

Dentro do verdadeiro espírito TradingView, o autor deste script publicou ele como um script de código aberto, para que os traders possam compreender e checar ele. Um viva ao autor! Você pode usá-lo gratuitamente, mas a reutilização deste código em uma publicação é regida pelas Regras da Casa. Você pode favoritá-lo para usá-lo em um gráfico.

Aviso legal

As informações e publicações não devem ser e não constituem conselhos ou recomendações financeiras, de investimento, de negociação ou de qualquer outro tipo, fornecidas ou endossadas pela TradingView. Leia mais em Termos de uso.

Quer usar esse script no gráfico?

//Created By Marco 25 03 2016
// Intraday 5 min
study(title="Intraday TS ,BB + Buy/Sell +Squeeze Mom.+ adx-dmi", shorttitle="Intraday (5 min+) Strategy", overlay=true)
bblenght = input(46, minval=1, title="Bollinger Bars Lenght")
bbstdev = input(0.35, minval=0.1,step=0.05, title="Bollinger Bars Standard Deviation")
tp =input(0.0,defval=0.0,step=0.1,title ="percentuale take profitto")

//Calculate BB 55 0.2
source = close
basis = sma(source, bblenght)
dev = bbstdev * stdev(source, bblenght)
upperBB = basis + dev
lowerBB = basis - dev
midBB=(upperBB+lowerBB)/2
//is over the top?
isOverBBTop = low > upperBB ? true : false
isUnderBBBottom = high < lowerBB ? true : false
newisOverBBTop = isOverBBTop != isOverBBTop[1]
newisUnderBBBottom = isUnderBBBottom != isUnderBBBottom[1]
//receive high and low range
high_range = valuewhen(newisOverBBTop,high,0)
low_range = valuewhen(newisUnderBBBottom,low,0)

bblow = valuewhen(newisOverBBTop,(lowerBB/0.00005) *  0.00005,0)
bbhigh = valuewhen(newisUnderBBBottom,(((upperBB*1000)/5)+5) * 5/1000,0)

//take it only if over the BB limit
buy_limit_entry = isOverBBTop ? high_range==high_range[1] ? high_range+0.001: na : na
sell_limit_entry = isUnderBBBottom ? low_range==low_range[1] ? low_range-0.001: na : na

take_profit_buy=  isOverBBTop ? high_range==high_range[1] ? (buy_limit_entry + buy_limit_entry-bblow)+(buy_limit_entry + buy_limit_entry-bblow)*tp/500 : na : na
take_profit_sell= isUnderBBBottom ? low_range==low_range[1] ?(sell_limit_entry -(bbhigh-sell_limit_entry))-(sell_limit_entry-(bbhigh-sell_limit_entry))*tp/500 : na : na

take_profit2_buy=  isOverBBTop ? high_range==high_range[1] ? buy_limit_entry + 2*(buy_limit_entry-bblow)+(buy_limit_entry + 2*(buy_limit_entry-bblow))*tp/500 : na : na
take_profit2_sell= isUnderBBBottom ? low_range==low_range[1] ? sell_limit_entry - 2*(bbhigh-sell_limit_entry)-(sell_limit_entry - 2*(bbhigh-sell_limit_entry))*tp/500 : na : na

stop_loss_buy = isOverBBTop ? high_range==high_range[1] ? bblow : na : na
stop_loss_sell = isUnderBBBottom ? low_range==low_range[1] ? bbhigh : na : na

highlightHigh = isOverBBTop ? lime : aqua
highlightLow  = isUnderBBBottom ? lime : aqua

colorLineUp = buy_limit_entry ? blue : blue
colorLineDown = sell_limit_entry ? red : red


colorBuyTP = close>=take_profit_buy ? lime : fuchsia
colorSellTP = close<=take_profit_sell ? lime : fuchsia
colorBuyTP2 = close>=take_profit2_buy ? lime : fuchsia
colorSellTP2 = close<=take_profit2_sell ? lime : fuchsia

barcolor((high >= lowerBB and low <= upperBB) ? aqua : na)
barcolor((high < sell_limit_entry and low > take_profit_sell) ? orange : na)
barcolor((low > buy_limit_entry and high < take_profit_buy) ? orange : na)
barcolor(high >= take_profit_buy and not(na(buy_limit_entry)==1) ? fuchsia : low <= take_profit_sell and not(na(sell_limit_entry)==1) ? fuchsia : na)
//plot Statements
bbup=plot(upperBB, title="BB Upper Band", style=linebr, linewidth=2, color=highlightHigh)
bbdo=plot(lowerBB, title="BB Bottom Band", style=linebr, linewidth=2, color=highlightLow)
plot( buy_limit_entry, title="Buy Entry", style=linebr, linewidth=2, color=colorLineUp, transp=80)
plot( sell_limit_entry, title="Short Entry", style=linebr, linewidth=2, color=colorLineDown, transp=80)
plot( stop_loss_buy, title="Buy Stop", style=circles, linewidth=2, color=maroon, transp=0)
plot( stop_loss_sell, title="Short Stop", style=circles, linewidth=2, color=maroon, transp=20)
plot( take_profit_buy, title="Buy TP 1:1", style=circles, linewidth=2, color=colorBuyTP, transp=20)
plot( take_profit_sell, title="Short TP 1:1", style=circles, linewidth=2, color=colorSellTP, transp=20)
plot( take_profit2_buy, title="Buy TP2 1:2", style=circles, linewidth=2, color=colorBuyTP2, transp=20)
plot( take_profit2_sell, title="Short TP2 1:2", style=circles, linewidth=2, color=colorSellTP2, transp=20)
fill(bbup, bbdo, color=aqua, transp=87)

////study("plotarrow example", overlay=true)
compra= isOverBBTop ? high_range==high_range[1] ? high_range+0.001: 1: 0
vendi = isUnderBBBottom ? low_range==low_range[1] ? low_range-0.001: 1 : 0
codiff = compra ==1 ? compra: 0
codiff2 = vendi ==1 ? vendi :0
plotarrow(codiff,colorup=green,title="Arrow Long entry",transp=40)
plotarrow(codiff2*-1,colordown=orange,title="Arrow Short entry",transp=40)
//Squeeze Mom

length = input(20, title="BB Length")
mult = input(2.0,title="BB MultFactor")
lengthKC=input(20, title="KC Length")
multKC = input(1.5, title="KC MultFactor")

useTrueRange = input(true, title="Use TrueRange (KC)", type=bool)

basis1 = sma(source, length)
dev1 = mult * stdev(source, length)
upperBB1 = basis1 + dev1
lowerBB1 = basis1 - dev1


// Calculate KC
ma = sma(source, lengthKC)
range = useTrueRange ? tr : (high - low)
rangema = sma(range, lengthKC)
upperKC = ma + rangema * multKC
lowerKC = ma - rangema * multKC

sqzOn  = (lowerBB1 > lowerKC) and (upperBB1 < upperKC)
sqzOff = (lowerBB1 < lowerKC) and (upperBB1 > upperKC)
noSqz  = (sqzOn == false) and (sqzOff == false)

val = linreg(source  -  avg(avg(highest(high, lengthKC), lowest(low, lengthKC)),sma(close,lengthKC)),
            lengthKC,0)

bcolor = iff( val > 0,
            iff( val > nz(val[1]), lime, green),
            iff( val < nz(val[1]), red, maroon))
scolor = noSqz ? blue : sqzOn ? black : aqua
plot(midBB,title="trend colors", color=bcolor, style=linebr, linewidth=3)
plot(midBB, title="True range colors",color=scolor, style=cross, linewidth=2)

//study(title="Directional Movement Index", shorttitle="DMI")
len = input(14, minval=1, title="DI Length")
lensig = input(14, title="ADX Smoothing", minval=1, maxval=50)
up = change(high)
down = -change(low)
trur = rma(tr, len)
plus = fixnan(100 * rma(up > down and up > 0 ? up : 0, len) / trur)
minus = fixnan(100 * rma(down > up and down > 0 ? down : 0, len) / trur)
sum = plus + minus
adx = 100 * rma(abs(plus - minus) / (sum == 0 ? 1 : sum), lensig)

//study(title="plotshape example 1", overlay=true)
dataup= plus >= minus and adx>=29
datadw=minus>=plus and adx>=29
datast=adx<=20
plotshape(dataup,style=shape.triangleup,title="DMI + ",location=location.abovebar,color=green)
plotshape(datadw,style=shape.triangledown,title="DMI -",location=location.belowbar,color=maroon)
plotshape(datast,style=shape.diamond,title="ADX Flat",color=red)
