[ A L P H A X ] VECTOR - Regime-Adaptive Flow EngineAlphaX VECTOR — Regime-Adaptive Flow Engine: Kaufman ER Regime Classification, KAMA Vector Line, Multi-Component Flow Score & Scalping-Optimized Entry Playbooks
AlphaX VECTOR is a professional-grade scalping system built around a fundamentally different architectural premise from every other indicator in the AlphaX suite: the market regime is identified first, and the entry playbook is selected automatically to match that regime. Most scalping systems apply the same entry logic regardless of whether the market is trending, ranging, or chopping — and then wonder why the same setup works brilliantly in one context and fails consistently in another. VECTOR solves this at the architectural level by running a three-metric regime classification engine (Efficiency Ratio, Choppiness Index, and ADX) that determines the current market character on every bar and locks in one of four states: Trend Bull, Trend Bear, Balance/Range, or Chop. Each state activates a different set of entry playbooks — micro-pullbacks to the Vector Line in trends, micro-impulse breaks in balance or trend, mean-reversion fades at band extremes in balance — and all entries are filtered through a 6-component Flow Vector score that measures the directional conviction of the current market from five independent dimensions. The result is a system where every signal is not just directionally filtered, but regime-appropriate — built for M1 through M15 scalping on gold, forex, indices, and crypto.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧭 The Core Philosophy — Regime First, Setup Second
The single biggest failure mode in scalping is applying trend-following entries in choppy markets and mean-reversion entries in trending markets. The market character changes continuously — a trending gold session can collapse into a tight range within minutes, and a balance period can explode into a directional impulse with no warning. Any fixed system that ignores this regime cycle will have extended periods of consistent losses whenever the market shifts character.
VECTOR's architecture inverts the standard approach. Instead of picking a setup type and then trying to filter bad signals, VECTOR determines the market's current character first — with three independent quantitative measurements — and then selects the correct playbook for that character. In Trend Bull, only pullback and impulse break setups fire. In Balance, only impulse breaks and band fades fire. In Chop, nothing fires. The dashboard explicitly tells you the active playbook at all times: SCALP PULLBACK ▲, SCALP PULLBACK ▼, SCALP FADE / BREAK, or NO TRADES.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 The Regime Engine — Three Independent Classifiers
The regime is determined on every bar by three completely independent measurements. The combination of all three produces a robust, multi-dimensional picture of market character that no single indicator alone could provide.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Kaufman Efficiency Ratio (ER)
The Efficiency Ratio measures how directionally efficient price movement has been over the lookback period (default: 10 bars). It divides the net directional change in price by the total path traveled — the sum of all individual bar-to-bar movements. A ratio close to 1.0 means every bar moved in the same direction — maximum efficiency, maximum trend. A ratio close to 0.0 means the total path traveled far exceeds the net movement — price oscillated back and forth with no net progress — maximum chop, minimum efficiency.
ER thresholds:
ER ≥ 0.35 (trend minimum) — price is moving with high directional efficiency. The market is trending and momentum setups are appropriate
ER ≤ 0.22 (chop maximum) — price is oscillating with low efficiency. Combined with low ADX, this triggers the CHOP regime and blocks all signals
Between thresholds — transitional state. Not clear trend, not clear chop
The ER is displayed live on the dashboard with color coding — yellow-green when in trend territory, orange when in chop territory, neutral otherwise. This single number tells you the fundamental quality of price direction at any given moment.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Choppiness Index
The Choppiness Index (CI) provides an independent measure of market randomness using a logarithmic ratio formula. It calculates the sum of all individual ATR readings over the lookback period (default: 14 bars) divided by the total high-low range of that period. High CI values indicate the range of the period was consumed by oscillating ATRs — choppy movement. Low CI values indicate the period's range was established by directional movement.
CI interpretation:
CI above 61.8 — the market is in a Golden Ratio chop zone. Institutional consensus is absent. All signals are suppressed when this threshold is exceeded (configurable, default: 61.0)
CI below 38.2 — maximum trending efficiency. In practice, CI values this low indicate an impulsive directional move in progress
CI between 38.2 and 61.8 — transitional territory, neither pure trend nor pure chop
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
ADX (Average Directional Index)
The ADX provides the most widely recognized trend strength measure, confirming whether a directional bias measured by ER and CI is backed by genuine momentum. ADX above the configured minimum (default: 20) is required for Trend Bull or Trend Bear regime classification. Below the minimum, even if ER is high and CI is low, the system classifies as Balance rather than Trend — the directional efficiency exists but the momentum confirmation is absent.
Combined regime logic:
CHOP (0) — CI above threshold OR (ER below chop max AND ADX below trend min). The market is in an untradeable oscillating state. Dashboard shows ⛔ CHOP — STAND ASIDE. All signals blocked
TREND BULL (1) — not chop, ADX above trend min, ER above trend min, Flow Vector positive, price above Vector Line. Playbook: SCALP PULLBACK ▲
TREND BEAR (2) — same conditions with Flow Vector negative and price below Vector Line. Playbook: SCALP PULLBACK ▼
BALANCE (3) — not chop, but ADX or ER conditions for trend not met. Market is directional enough for scalping but not in a clear trend. Playbook: SCALP FADE / BREAK
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 The KAMA Vector Line — Adaptive Trend Reference
The Vector Line is a Kaufman Adaptive Moving Average (KAMA) — the same ER-weighted adaptive EMA that forms the basis of the regime classification. It is the central price reference for all pullback entries and a key component of the Flow Vector score.
Why KAMA over a standard EMA: A standard EMA responds with the same speed regardless of market conditions. In a trending market, the EMA lags price and creates false pullback signals. In a choppy market, it whipsaws. KAMA self-adjusts — it moves quickly in trending conditions (tracking price closely) and moves slowly in choppy conditions (staying stable). This means the Vector Line acts as an accurate, self-calibrating trend reference that naturally tightens around price during strong trends and widens away from price during chop.
Vector Line color coding: The line is plotted in gradient color based on the current Flow Vector score — bright yellow-green when the Flow Vector is strongly positive (above the Strong Vector threshold), bright red when strongly negative, fading to semi-transparent in neutral territory. At a glance, the Vector Line's color tells you the directional conviction of the current market.
Vector Line price: The exact current Vector Line price is displayed on the dashboard as VECTOR LINE in real time — the precise price level where pullback entries are being monitored.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ The Flow Vector — 6-Component Directional Score
The Flow Vector is a composite directional score ranging from -100 (maximum bearish conviction) to +100 (maximum bullish conviction). It is computed on every bar from six independent measurements, each capturing a different dimension of directional bias.
Component 1 — EMA Stack (up to ±22 points):
A triple EMA (8/21/50) full stack alignment — EMA 8 above EMA 21 above EMA 50, with price above EMA 8 — scores +22 points for bull, -22 for bear stack. Partial alignment (price simply above or below EMA 21) scores ±8. This is the momentum structure layer.
Component 2 — Vector Line Slope (up to ±18 points):
Whether the KAMA Vector Line is currently rising or falling. A rising Vector Line in a bull trend confirms the adaptive average is itself accelerating — ±18 points. This ensures the entry direction is aligned with the KAMA's own momentum, not fighting it.
Component 3 — OBV Slope (up to ±15 points):
The slope of On-Balance Volume over the configured lookback period (default: 10 bars). A rising OBV slope means net buying pressure is accumulating (each up-close bar adds volume, each down-close subtracts). A falling slope confirms net selling. ±15 points. This is the volume accumulation/distribution layer — independent of price movement.
Component 4 — Volume Delta (up to ±12 points):
The estimated directional volume pressure — bull volume EMA minus bear volume EMA using the candle range position method. ±12 points. This captures intrabar volume directional bias as opposed to OBV's inter-bar accumulation bias.
Component 5 — HTF EMA Bias (up to ±18 points):
The higher timeframe EMA structure — fast EMA above slow EMA with close above fast EMA (bull) or the inverse (bear). ±18 points. This ensures the Flow Vector reflects the macro institutional direction, not just the current timeframe's local momentum.
Component 6 — Price vs Vector Line (up to ±15 points):
Whether the current close is above or below the KAMA Vector Line. ±15 points. Price above the Vector Line in a bull regime confirms the pullback has not reached the Vector Line yet (trend intact). Price below confirms the line has been reached or breached (potential reversal zone).
Flow Vector thresholds:
+40 to +100 — strong bull flow. Setup A (Trend Micro-Pullback) long entries require this minimum
+65 to +100 — extreme bull flow. Used as a fade signal when combined with upper balance band touch
-40 to -100 — strong bear flow. Setup A short entries require this minimum
-65 to -100 — extreme bear flow. Fade signal condition for lower band touches
-39 to +39 — neutral flow. Directional conviction insufficient for Trend regime entries
Flow Acceleration:
In addition to the absolute score, VECTOR checks whether the Flow Vector is currently accelerating — increasing for two consecutive bars (bull) or decreasing for two consecutive bars (bear). Acceleration is a hard requirement for Setup A (Trend Micro-Pullback) entries, ensuring the entry occurs when flow is building rather than stalling or reversing.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🕯 Scalping Candle Quality — The Pin Bar Filter
VECTOR applies a specific, tight candle quality standard for all entry types — the scalping pin bar. All four conditions must be simultaneously true:
Bull pin bar requirements:
Bullish close (close above open)
Lower wick covers at least 42% of the total bar range — the rejection of the low is dominant
Upper wick is at most 32% of the total range — no significant selling into the close
Body size at least 0.10× ATR — not a doji or near-doji
Close in the upper 28% of the bar range (upper quartile) — the bar closed strongly bullish
Bear pin bar requirements: The mirror conditions — upper wick dominant (42%+ of range), lower wick minimal (32% max), small minimum body, close in the lower quartile.
Why this specific candle quality standard for scalping: Scalping entries are executed in the wick of the signal candle — buying at the low of a bull pin bar, selling at the high of a bear pin bar. A candle that lacks a dominant rejection wick provides no clear structural fill level. The upper quartile close requirement for bulls ensures the rejection was decisive — not a bar that dipped into support and then closed mediocre. These parameters are significantly stricter than the standard 50% wick filter used in MERIDIAN and PIVOT, reflecting the precision required for scalping entries.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏷 Four Setup Types — Regime-Gated Playbooks
VECTOR implements four distinct setup types, each activated only in the appropriate regime state. The active playbook is displayed on the dashboard as a PLAYBOOK row, telling you exactly which setups are available right now.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup A — Trend Micro-Pullback (Regime: Trend Bull or Trend Bear only)
The primary VECTOR scalp entry. Fires in Trend Bull regime for longs, Trend Bear for shorts.
Full condition stack for long:
Regime is Trend Bull (regime == 1)
Flow Vector is strongly bullish (≥ +40)
Flow Vector is accelerating (rising for two consecutive bars)
Price has touched the EMA 8 or Vector Line from above — the micro-pullback has reached the trend reference level. Touch tolerance is ±0.22× ATR (configurable)
A qualifying bull pin bar has formed at the touch
The recent 5-bar low has dipped into the EMA 8 / Vector Line zone (confirming the touch was genuine, not just proximity)
Price is not extended above the Vector Line by more than the maximum extension setting (default: 1.0× ATR) — the anti-chase filter
RSI(7) is between 40 and 70 — not already overbought, not in a capitulation zone
Why this is the core scalp setup: In a confirmed Trend Bull regime with accelerating flow, the EMA 8 and Vector Line are the natural pullback magnets. Institutional buyers who are long in the trend use these levels to add on dips. The pin bar at the level confirms they stepped in. The anti-extension filter prevents chasing a move that has already run 1× ATR above the Vector Line — exactly the stretch that precedes a deeper pullback.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup B — Micro Impulse Break (Regime: Trend or Balance)
A momentum continuation scalp that fires when price breaks out of a micro swing range with a qualifying body and volume delta confirmation.
Key conditions for long:
Regime is Trend Bull or Balance (the setup fires across both regimes as momentum can develop in either)
Price closes above the highest high of the last 4 bars (configurable lookback) on the previous bar — a genuine micro swing break
The break bar's body meets the minimum body threshold (default: 0.85× the impulse body minimum × ATR)
Volume delta is positive — buying pressure drove the break
A qualifying bull pin bar is present on the break bar
HTF bias aligns — long only when the higher timeframe confirms bullish
Price is not over-extended above the Vector Line (anti-chase filter)
What this setup captures: The breakout from a micro consolidation range with volume confirmation — the intrabar equivalent of a structure break. On a 1-minute chart, a 4-bar micro range that breaks with a strong body and bull delta is a clean scalp entry with a tight stop at the bottom of the range. In Balance regime, this setup provides the best entries because the market character does not support pullback trades but does support momentum breaks on sufficient flow.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup C — Range Fade / Band Extreme (Regime: Balance only)
The mean-reversion scalp. Fires only in Balance regime when price reaches the outer balance band with an exhausted or reversing Flow Vector.
Short fade conditions:
Regime is Balance (regime == 3)
Price has touched the upper balance band (within 0.08× ATR of the upper band)
The Flow Vector is either in extreme bull territory (≥ +65, meaning the move to the band is overextended) OR the flow is beginning to fade (Flow Vector is falling and was recently above +53)
A qualifying bear pin bar confirms the rejection at the band
RSI(7) is above 58 — confirming the RSI is elevated at the band touch, consistent with a reversal setup
Why band fades only fire in Balance: In a Trend Bull regime, price touching the upper balance band is a continuation event — the trend is simply pushing to the next level. Fading that in a trend produces the most reliable losses in scalping. Setup C is therefore hard-gated to Balance regime only, where the market has proven it is oscillating rather than trending, and the balance band genuinely represents a mean-reversion boundary.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup D — Vector Shift / Flow Zero-Cross (Off by default)
A legacy setup type that fires when the Flow Vector crosses from negative to positive (long) or positive to negative (short) with a strong body candle and positive volume delta. Off by default on fast timeframes because flow zero-crosses on M1–M5 produce excessive noise. Available for traders who want to experiment with flow momentum entries on H1+ timeframes where the zero-cross carries more structural weight.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧠 The 7-Point Scalp-Weighted Confluence Score
VECTOR uses a setup-weighted scoring system specifically calibrated for scalping frequency and quality:
Score structure:
Setup Type (up to 2 points) — primary setups (Trend Micro-Pullback, Micro Impulse) score 2 points. Secondary setups (Range Fade, Vector Shift) score 1 point. This weighting reflects that Setup A and B have more prerequisite conditions and are inherently higher quality
Flow Acceleration (1 point) — Flow Vector is actively building in the signal direction over the last two bars. Ensures the entry coincides with momentum building, not stalling
HTF Bias (1 point) — higher timeframe EMA confirms the signal direction
Volume Expansion (1 point) — current bar volume exceeds the volume average by the configured minimum (default: 1.05×)
Non-Chop Market (1 point) — the market is not in Chop regime. This point is also enforced as a hard gate — signals cannot fire in Chop regardless of the score
RSI(7) Filter (1 point) — the 7-period RSI is in the acceptable zone for the signal direction (40–70 for longs, 30–60 for shorts)
Maximum score: 7. Default minimum: 4. The scalp-weighted system means that a Setup A or B entry with flow acceleration, HTF alignment, and volume can reach 5 points from the setup type, flow, HTF, and volume components alone — a clean high-quality signal. Setup C entries require more supporting factors to reach the threshold because their 1-point setup score means more of the other layers must confirm.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛡 Anti-Chase & Quality Filters
VECTOR includes several anti-chase and quality gates specifically designed for scalping precision that do not appear in the other AlphaX indicators.
Extension Filter: No long signal fires if price is already above the Vector Line by more than the configured maximum extension (default: 1.0× ATR). No short signal fires if price is already below by that much. This single filter eliminates the most common scalping failure — entering a pullback after it has already run too far from the reference level, leaving insufficient room for the signal to develop before hitting the stop.
Dip/Rip Confirmation: For Setup A entries, the 5-bar lowest low (bull) or highest high (bear) must have reached within a tight ATR tolerance of the reference lines. This confirms that the touch was genuine — price actually dipped into the zone — rather than just being close to it without contacting it.
RSI(7) Micro Filter: A 7-period RSI gate blocks entries when RSI is already overbought (above 70 for longs) or in a knife-catch zone (below 40 for shorts). On scalping timeframes, entering a long when 7-bar RSI is already at 75 means you are entering after the move is exhausted. This filter alone dramatically reduces the worst class of setup A false signals — those that occur when price is touching the EMA 8 on the way back down through it rather than bouncing off it.
Flow Acceleration Requirement: Setup A requires the Flow Vector to be accelerating (not just positive) for two consecutive bars. A stale, high but flat Flow Vector indicates the move is decelerating — the opposite of the momentum condition that produces clean scalp continuations.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Scalp Entry Reference — Wick-Based Positioning
Unlike the other AlphaX indicators where the entry is taken on the close or next open, VECTOR's entry reference is the rejection wick of the signal candle — specifically the bar's low (for bull signals) or high (for bear signals). This is the optimal scalp fill zone.
Why the wick, not the close: A scalp pin bar with a 42%+ lower wick has a significant low-to-close range. Entering at the close gives up nearly half that range unnecessarily. The institutional scalp entry is at the wick extreme — the exact level where buyers stepped in and stopped the selling. A limit order at the bar's low (bull) captures the optimal risk/reward because the stop goes below that low, and the full bar range is available as immediate profit space.
Entry reference visualization: A cross marker is plotted at the signal bar's low (bull) or high (bear) — the wick entry reference — distinct from the signal triangle. This gives you the precise price at which to place a limit order if you prefer limit entry over market-on-open execution.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Live Dashboard
The 17-row real-time dashboard displays the complete internal state across five sections.
REGIME
Market Regime — current regime state with icon: ⛔ CHOP — STAND ASIDE, ▲ TREND BULL, ▼ TREND BEAR, or ◆ BALANCE / RANGE. This is the primary trading context indicator
Playbook — the active setup playbook matching the current regime: NO TRADES, SCALP PULLBACK ▲, SCALP PULLBACK ▼, or SCALP FADE / BREAK. Tells you exactly which setup types can fire
Flow Vector — the live composite Flow Vector score with + or - sign. Yellow-green when strongly positive, red when strongly negative, neutral otherwise
METRICS
Efficiency — current Kaufman Efficiency Ratio value. Yellow-green when in trend territory (≥ threshold), orange when in chop territory (≤ chop max)
Chop Index — current Choppiness Index value. Orange when above the stand-aside threshold
ADX — current ADX value. Yellow-green when above the trend minimum
Vol Delta — ▲ BUYERS or ▼ SELLERS based on the current volume delta direction
FILTERS
HTF Bias — ▲ BULL, ▼ BEAR, or — FLAT
Session — ✓ ACTIVE or ✗ OFF
CONFLUENCE
Bull Score — live 0–7 score. Background highlights yellow-green when threshold is met and regime is not Chop
Bear Score — live 0–7 score. Background highlights red when threshold is met and regime is not Chop
Vector Line — the exact current KAMA Vector Line price, color-coded by Flow Vector strength
Live confluence label: During non-chop regimes, a small B x/7 · S x/7 label appears near the Vector Line on the current bar, updating in real time.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Chart Visual System
KAMA Vector Line — the adaptive trend reference line, color-coded by Flow Vector strength. Bright yellow-green when bull flow is strong, bright red when bear flow is strong, fading to semi-transparent in neutral/weak territory
Balance Bands (upper, lower, midline) — the Bollinger-style bands used as reference for Balance regime and Setup C fade entries. Purple-tinted at low opacity
▲ Label with setup tag (below bar, yellow-green) — bull scalp signal. Tag shows A, B, C, or D identifying which setup type fired. Tooltip shows the full setup description
▼ Label with setup tag (above bar, red) — bear scalp signal
Entry Reference Cross (× marker) — plotted at the signal bar's low (bull) or high (bear) — the optimal scalp limit entry price
SL Guide (red dotted circles) — stop loss reference below the EMA 8 and Vector Line minimum (bull) or above (bear), plus ATR buffer
TP Guide (yellow-green dotted circles) — dynamically computed reward target at R multiple
Regime Change Labels (optional) — small labels at regime transition bars showing TREND ▲, TREND ▼, or BALANCE. Off by default — regime visible on dashboard
Live confluence label — B x/7 · S x/7 near the Vector Line on the current bar
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚀 How to Trade with AlphaX VECTOR — Step by Step
Step 1 — Read the Regime First
Check the Market Regime row on the dashboard. ⛔ CHOP — do nothing, close the chart if needed. ◆ BALANCE — Setup B and C available. ▲ TREND BULL or ▼ TREND BEAR — Setup A is active
Check the Playbook row — it tells you exactly which setup type is currently firing-eligible
Note the Flow Vector value. Above +40 in Trend Bull is the optimal Setup A environment. Below +40 but still positive suggests the trend may be weakening
Step 2 — Prepare the Level
In Trend Bull, identify where the Vector Line is currently sitting (Vector Line on dashboard). This is your Setup A anchor level — watch for price to pull back toward it
Note the EMA 8 on the chart. For Setup A, price must touch either EMA 8 or the Vector Line — whichever is closest to price is the active support
In Balance, note where the upper and lower balance bands sit. These are the Setup C fade boundaries
Step 3 — Enter on the Signal Label
A ▲ label below the bar with setup tag is the core scalp signal — Trend Micro-Pullback long. All conditions including regime, flow acceleration, line touch, pin bar, RSI, and extension filter are confirmed
The entry reference × marker shows the wick low — the optimal limit order price
The SL guide is at the minimum of EMA 8, Vector Line, and the bar low, minus ATR buffer. This is a tight structural stop designed for scalping
The TP guide is at the R-multiple target. Default 2.0R for a tight scalp stop produces a larger absolute target than most other AlphaX indicators due to the compressed ATR-based stops
Step 4 — Manage the Scalp
Scalp trades in VECTOR are short-duration by design — move the stop to breakeven after any meaningful move in your favor
Watch the Flow Vector on the live label — if it drops below +40 during a long trade, the bull flow is weakening. Consider taking profit early
If the regime changes to Chop during an open trade, take profit immediately — the market character has changed and the setup's underlying logic no longer applies
Setup A targets in strong Trend Bull regimes can be extended toward the band extremes. In strong trends, the first R-target is often just the beginning of a larger move
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Identifying Low-Quality Conditions — When Not to Trade
Stand aside when:
Market Regime shows ⛔ CHOP — this is the clearest possible signal to step back. No signals will fire, and any manual entries during chop carry statistically negative expectation on scalping timeframes
Chop Index above 61 on the dashboard — even if regime hasn't fully shifted to CHOP, a CI above 61 is a warning that market character is deteriorating. Reduce size or stop trading
Flow Vector is between -39 and +39 — the directional conviction is insufficient for Setup A. In this zone, the market is neither clearly bullish nor bearish at the flow level. Wait for the vector to commit above ±40
Flow Vector is high but flat (no acceleration) — a Flow Vector at +55 that has been flat for 5 bars means the momentum is stale. Setup A requires active acceleration, not just a high score. The signal will be blocked, but the absence of acceleration is itself a warning
HTF Bias opposes the signal direction — scalping against the higher timeframe institutional flow is the highest-risk scalp. If HTF shows BEAR and you are attempting Setup A longs, every entry is fundamentally counter-trend
RSI(7) is above 70 at a bull pin bar — the 7-bar RSI filter will block the signal, but if you see a bull pin at the Vector Line with RSI at 72, it is a warning that the touch is occurring after an overbought condition rather than at a healthy pullback
Regime changes rapidly between states — if the regime is cycling between Trend Bull and Balance or Balance and Chop multiple times per session, the market is in an indecisive transition phase. These transitions produce the most noise and the lowest signal quality across all setup types
The ideal VECTOR scalp setup:
Trend Bull or Trend Bear regime sustained for 5+ bars
Flow Vector at ±55 or above, actively accelerating
HTF aligned with regime direction
Price pulling back cleanly to the Vector Line / EMA 8 zone with a tight, contained range
Bull or bear pin bar with lower/upper wick of 50%+ of range, closing in the upper/lower quartile
RSI(7) between 45–60 for longs or 40–55 for shorts — the healthy pullback RSI zone
Volume above average, volume delta confirming direction
Score at 5/7 or higher
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Key Features
🧭 Three-metric regime classification engine — Kaufman Efficiency Ratio, Choppiness Index, and ADX combined to classify every bar as Trend Bull, Trend Bear, Balance, or Chop
📊 Active playbook display — dashboard tells you exactly which setup type is eligible right now: SCALP PULLBACK ▲/▼, SCALP FADE / BREAK, or NO TRADES
📈 KAMA Vector Line — adaptive moving average that tightens in trends and stabilizes in chop, providing the most accurate scalp reference line available
⚡ 6-component Flow Vector — EMA Stack, KAMA Slope, OBV Slope, Volume Delta, HTF Bias, and Price vs Vector Line combined into a -100 to +100 directional conviction score
🔴 Flow Acceleration detection — Setup A requires the Flow Vector to be actively building for two consecutive bars, blocking stale or decelerating flow entries
🏷 Four regime-gated setup types — Setup A (Trend Micro-Pullback), Setup B (Micro Impulse Break), Setup C (Balance Band Fade), Setup D (Vector Shift, off by default)
🕯 Strict scalping pin bar standard — lower/upper wick ≥ 42% of range, opposing wick ≤ 32%, minimum body, close in upper/lower quartile — the highest candle quality standard in the AlphaX suite
🛡 Anti-chase extension filter — blocks signals when price has already moved too far from the Vector Line, eliminating chasing entries
📍 Wick-based entry reference — × marker at the signal bar's wick extreme for optimal limit order placement
🔢 RSI(7) micro filter — 7-period RSI gates block overbought longs and oversold shorts at the exact scalp entry bar
📊 Live Efficiency, Choppiness, and ADX metrics on dashboard — the three regime classification inputs displayed with live values and color-coded thresholds
🎨 Flow Vector–colored Vector Line — line color reflects directional conviction in real time from strong bull to neutral to strong bear
📊 17-row live dashboard — Regime, Playbook, Flow Vector, Efficiency, Chop Index, ADX, Vol Delta, HTF Bias, Session, Confluence, and Vector Line price updated every bar
🔔 5 alert conditions — long entry, short entry, chop warning, trend bull regime change, trend bear regime change
⚙ Fully configurable — ER lookback and thresholds, CI length and maximum, ADX length and minimum, KAMA parameters, OBV and delta lengths, flow vector thresholds, all four setup enables, pullback tolerance, anti-chase extension, impulse body minimum, confluence minimum, HTF timeframe and EMAs, volume filter, session, SL/TP parameters, and all colors are independently adjustable
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ Settings Reference
Regime Engine
ATR Length — ATR lookback for all ATR-relative calculations (default: 14)
Efficiency Ratio Length — Kaufman ER lookback period (default: 10)
ER Min for Trend Regime — minimum ER to qualify as trend (default: 0.35)
ER Max for Chop Regime — maximum ER that contributes to chop classification (default: 0.22)
Choppiness Index Length — CI calculation lookback (default: 14)
Chop Index — Stand Aside Above — CI threshold above which all signals are suppressed (default: 61.0)
ADX Length — ADX calculation lookback (default: 14)
ADX Min for Trend — minimum ADX for Trend Bull or Trend Bear classification (default: 20.0)
Balance Band Length / Mult — parameters for the balance band Bollinger calculation (defaults: 20 / 2.0)
Flow Vector
Vector Line (KAMA) Length — KAMA lookback period (default: 21)
KAMA Fast / KAMA Slow — KAMA smoothing constants (defaults: 2 / 30)
OBV Slope Length — lookback bars for OBV slope calculation (default: 10)
Volume Delta Length — EMA smoothing for volume delta estimation (default: 14)
Strong Vector Threshold — minimum absolute Flow Vector for strong directional condition (default: 40)
Extreme Vector (range fade) — Flow Vector level triggering the extreme condition for Setup C fades (default: 65)
Entries & Confluence (Scalping)
Setup A · Trend Micro-Pullback — toggle the primary trend scalp setup
Setup B · Micro Impulse Break — toggle the momentum continuation scalp
Setup C · Range Fade (band extreme) — toggle the balance band mean-reversion scalp
Setup D · Vector Shift (legacy) — toggle the flow zero-cross setup (default: off)
Pullback Touch Tolerance (xATR) — ATR tolerance for EMA 8 / Vector Line touch detection (default: 0.22)
Impulse Min Body (xATR) — minimum body size for Setup B impulse and Setup D shift candles (default: 0.55)
Max Extension from Vector (xATR) — maximum allowed distance from Vector Line before anti-chase blocks the signal (default: 1.0)
Micro Swing Lookback — bars for the Setup B micro swing high/low reference (default: 4)
Min Confluence Layers (of 7) — minimum score to fire a signal (default: 4)
Show Entry Signals — toggle signal labels
Show Confluence Label — toggle the live B/S score label near the Vector Line
Signal Cooldown (bars) — minimum bars between consecutive signals (default: 3)
Filters
HTF Trend Filter — toggle higher timeframe EMA alignment requirement
HTF Timeframe — higher timeframe for EMA data (default: 60-minute)
HTF Fast / Slow EMA — EMA periods on the HTF (defaults: 21 / 55)
Volume Confirm — toggle volume expansion requirement
Min Volume vs Avg — minimum volume ratio (default: 1.05)
Volume Avg Length — SMA length for volume baseline (default: 20)
Session Filter — toggle active hours restriction (default: off)
Active Session — configurable session window
Exit Guidance
Show SL / TP Guides — toggle stop and target circle plots
SL Distance (xATR) — ATR buffer added beyond the EMA 8 / Vector Line stop anchor (default: 0.85)
TP Reward (R) — take profit as a multiple of the actual risk (default: 2.0)
Display
Show Vector Line (KAMA) — toggle the adaptive trend reference line
Show Balance Bands — toggle the BB-style balance band plots
Show Regime Change Labels — toggle small regime transition labels on regime-change bars (default: off)
Show Dashboard — toggle the full dashboard
Dashboard Position — Top Left / Top Right / Bottom Left / Bottom Right
Colors
Bull / Bull Bright — yellow-green family for bullish signals and indicators
Bear / Bear Bright — red family for bearish signals
Chop / Caution — orange for chop regime and caution states
Balance / Vector — purple for balance bands, Vector Line neutral state, and equilibrium elements
SL Guide / TP Guide — stop and target circle colors
Dash Text / Dash BG / Dash Header / Dash Section / Dash Frame — full dashboard color control
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 Alert Conditions (5 total)
Entry Alerts
Vector Long — scalp long signal fired. Wick rejection entry confirmed with all regime and confluence conditions met
Vector Short — scalp short signal fired
Regime Alerts
Vector Chop Warning — market has entered Chop regime. Stand aside until regime clears
Vector Trend Bull — market has transitioned to Trend Bull regime. Watch Vector Line for Setup A pullback opportunities
Vector Trend Bear — market has transitioned to Trend Bear regime. Watch Vector Line for Setup A short pullback opportunities
All alert messages are formatted as const strings for clean webhook and notification platform integration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Recommended Settings by Instrument & Timeframe
The default configuration is optimized for XAUUSD, major forex pairs, and crypto on M1–M5 :
Cooldown at 3 bars — fast timeframes produce setups in rapid succession. A 3-bar cooldown prevents back-to-back signals on consecutive bars while allowing reasonable signal frequency
SL at 0.85× ATR — tight scalp stop anchored to the EMA 8 / Vector Line zone. The strict pin bar requirement ensures the signal bar's wick provides meaningful structural support, so the stop does not need to be large
TP at 2.0R — on M1–M5 with a 0.85× ATR stop, 2.0R produces a tight, achievable target during normal trending conditions
HTF at 60-minute — the standard intraday reference for M1–M5 scalping
Volume at 1.05× average — a very low multiplier appropriate for scalping timeframes where volume spikes are smaller and entry bars do not always show dramatic volume expansion
For other instruments or timeframes, adjust:
M15–H1 intraday — increase ER Length to 14, increase Chop Length to 20, increase CI stand-aside to 62, increase ADX minimum to 22, increase Cooldown to 6, increase TP to 2.5–3.0R
Crypto (BTC, ETH) — increase ATR Length to 20 for smoother ATR on high-volatility instruments, increase ER threshold to 0.40 for trend classification on more volatile assets
Indices (NAS100, US30) — use session filter restricted to market hours, increase ADX minimum to 22, consider enabling Setup D for the sharper zero-cross moves typical of index momentum
Fewer, higher-quality signals — raise Min Confluence to 5–6, increase ER trend minimum to 0.40, reduce CI stand-aside to 58, increase pullback touch tolerance slightly to 0.25 for tighter reference line proximity
Higher signal frequency — lower Min Confluence to 3, enable Setup D, reduce cooldown to 2, disable HTF filter on fast timeframes where the 60-minute EMA can lag too much
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
👥 Who This Is For
⚡ Pure scalpers on M1–M5 — VECTOR is the only indicator in the AlphaX suite specifically designed for sub-5-minute scalping. Every parameter — the pin bar standard, the wick entry reference, the tight ATR stop, the acceleration requirement, the anti-chase filter — is calibrated for fast-timeframe execution
🧭 Regime-aware traders — traders who understand that different market conditions require different strategies will immediately recognize the value of having the regime identified and the playbook selected automatically
🎯 Precision entry traders — the wick-entry reference and the strict pin bar requirements make VECTOR ideal for traders who want precise fill zones rather than market-on-close entries
📊 Traders who study market microstructure — the Efficiency Ratio, Choppiness Index, and KAMA components expose the internal mechanics of market character in ways that standard trend indicators do not
🔴 Traders who are burned by chasing — the anti-extension filter and RSI(7) gate are built specifically to stop the two most common scalping failures: entering too late after the move has already extended, and entering when momentum is actually exhausted
⚠ Traders who overtrade in choppy conditions — the Chop regime is the most powerful feature for discipline. When the dashboard shows ⛔ CHOP — STAND ASIDE, the system enforces what many traders cannot enforce themselves
🏦 Gold and forex scalpers — the default settings are calibrated for XAUUSD and major forex pairs, which exhibit the clearest regime cycling of any liquid instruments due to their session-driven institutional flows
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📝 Notes
All signals are confirmed on bar close — the indicator is non-repainting by design. All regime classification, Flow Vector, setup conditions, and confluence scoring finalize on confirmed bars only
The KAMA Vector Line has a warm-up period equal to the KAMA Length setting. On charts with insufficient bar history, the Vector Line may not display correctly until enough bars accumulate
The Efficiency Ratio and Choppiness Index require their full lookback periods to produce accurate readings. On charts with fewer bars than the longest lookback, readings may be imprecise during the initial warm-up period
The anti-chase extension filter uses the distance from close to the Vector Line. In fast-moving scalp conditions, this filter can sometimes block entries that a discretionary trader would take. Increase the extension maximum if this becomes a frequent issue on your instrument
The signal cooldown of 3 bars is deliberately short for scalping timeframes. On M1 charts, 3 bars = 3 minutes — sufficient to prevent back-to-back duplicate signals while allowing rapid sequential setups in trending conditions
Setup D (Vector Shift) is off by default and is not recommended for M1–M5 scalping. Flow Vector zero-crosses on fast timeframes occur too frequently and with insufficient signal-to-noise ratio to be useful without additional filtering. Consider enabling it only on H1+ timeframes
The balance bands in VECTOR are Bollinger-style ATR-smoothed bands used purely as visual references and Setup C trigger levels. They are not the same as the ANCHOR adaptive bands and do not produce trailing stop functionality
The indicator does not track open positions or P&L and does not connect to any broker or account
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Disclaimer
This indicator is a technical analysis and visualization tool intended for educational and informational purposes only. It does not constitute financial advice or a recommendation to buy or sell any financial instrument. All signals are generated from historical and real-time price data using mathematical calculations — their accuracy or profitability is not guaranteed. Past performance of any signal type does not guarantee future results. Always conduct your own analysis, use proper risk management, and consult a licensed financial advisor before making any trading decisions. The author accepts no responsibility for any losses incurred from the use of this indicator.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built for scalpers who know that trading the wrong setup in the wrong regime is not a signal problem — it is a system architecture problem. Indicador
[ A L P H A X ] MERIDIAN - Session Intelligence EngineAlphaX MERIDIAN — Session Intelligence Engine: Multi-Session Range Tracking, Prior Session Break & Retest, Opening Range Breakout, Meridian Bounce & 7-Layer Confluence Scoring
AlphaX MERIDIAN is a professional-grade session-based trading system built around the foundational truth that institutional price delivery is not random across the clock — it is organized by session. The Asian session defines the overnight range. London breaks it. New York confirms the direction or reverses it. Every major intraday move originates from one of three specific events: a break and retest of the prior session's high or low, a breakout of the opening range, or a pullback to the session's meridian equilibrium level. MERIDIAN detects all three in real time across all three global trading sessions, scores every potential entry through a 7-layer confluence engine, and fires signals only when session bias, VWAP positioning, HTF alignment, volume, and setup quality all confirm simultaneously. The result is a system that puts every trade in its correct session context — not just where price is, but which session it is in , what the prior session established , and where the institutional session bias currently sits . Designed for active traders across forex, gold, indices, and crypto on M1 through H1 timeframes.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌐 The Session Framework — Why Sessions Define Institutional Flow
Every liquid market is driven by three geographically separated groups of institutional participants operating in overlapping but distinct time windows: Asian banks and sovereign funds, European institutional desks and London market makers, and American institutional desks and New York banks. Each group has a characteristic trading behavior that shapes price during their active window.
Asian Session — The Range Builder:
During Asian hours, liquidity is thinner and price tends to consolidate or range within a defined high-low channel. The Asian session range represents the overnight consolidation — the zone where price equilibrates before the European open. The extremes of the Asian range are the first liquidity pools that London will target.
London Session — The Trend Initiator:
London is the world's most liquid trading session. European institutional desks frequently break the Asian range in the first hours of the London open — hunting the liquidity sitting above and below the overnight extremes before establishing the day's primary directional trend. The London opening range (the first N minutes of the session) frequently establishes the high or low of the day.
New York Session — The Confirmer or Reverser:
New York either confirms the London trend with continuation, or reverses the late-London move in the early New York hours. The London/NY overlap (typically 13:00–17:00 UTC) is the highest-volume period of the day and frequently produces the largest directional moves.
MERIDIAN is built around this three-session cycle. The prior session's high, low, and meridian are the key reference levels. The opening range of London or NY is the breakout reference. The session VWAP and meridian divide the current session into institutional premium (above) and discount (below). Every signal is evaluated in the context of which session it occurred in and what the prior session established.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⏱ Session Tracking Engine
MERIDIAN runs a fully independent session tracking system for all three global sessions simultaneously, configurable to any timezone.
Session detection:
Each session is defined by a configurable start and end hour in the selected timezone (default: UTC). The session engine detects the active session on every bar and correctly handles overnight sessions (sessions that span midnight). When no configured session is active, the system enters an OFF state and session-based calculations pause.
Session-by-session OHLC tracking:
From the first bar of each session, MERIDIAN tracks the rolling high, low, and open of the session in real time. Every new bar within the session extends these values — the session high and low expand with price, and the session meridian recalculates continuously as the range develops.
Session transition logic:
When a session changes, the completed session's high, low, and meridian are stored as the prior session reference. These prior session values persist until the next completed session overwrites them — giving you continuous access to the most recently completed session's key levels at all times.
Session VWAP (Volume Weighted Average Price):
A true session-anchored VWAP is computed from the first bar of each session — cumulative volume-weighted price divided by cumulative volume since the session open. This produces the purest possible VWAP calculation anchored to the correct institutional reference point: the session's opening bar.
Session Meridian (Equilibrium):
The midpoint of the current session's high-low range — (session high + session low) / 2. This level is the MERIDIAN line, plotted as a purple dotted line on the chart. It represents the current session's equilibrium — above is institutional premium, below is institutional discount, relative to where the session has traded.
Current session box:
The full range of the active session is visualized as a lightly tinted box extending from the session start bar to the current bar. Asian session boxes are gray, London boxes yellow-green tinted, and New York boxes red-tinted — providing immediate visual session identification across the chart.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📍 Prior Session Levels — The Institutional Reference Grid
The most important reference levels in intraday trading are the extremes established by the prior session. These are not arbitrary horizontal lines — they represent the boundaries of the range where an entire session's worth of institutional activity occurred. Breaking these levels is how one session's institutional participants establish control over the next session's price delivery.
Prior Session High (red dashed):
The highest price reached during the most recently completed session. This is the sell-side resistance level — the level above which bears were unable to sustain prices in the prior session. A close above this level in the current session is a significant break of prior institutional resistance.
Prior Session Low (yellow-green dashed):
The lowest price of the prior session. This is the buy-side support level — where buyers successfully defended price in the prior session. A close below this level represents a break of prior institutional support.
Prior Session Meridian (purple dotted):
The midpoint of the prior session's range. This level frequently acts as a magnet — price is drawn to the prior session's 50% level on pullbacks, retracements, and continuation moves. It represents the most-traded price zone of the prior session in range-position terms.
All three prior session levels are plotted as forward-extending lines covering the relevant history window. The prior session name (ASIAN / LONDON / NEW YORK) is displayed on the dashboard so you always know which session's levels you are referencing.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📦 Opening Range — The First N Minutes
The Opening Range (ORB) is one of the most consistently respected intraday reference structures across all liquid markets. It represents the range established in the first configurable number of minutes of the London or New York session (default: 30 minutes). Once the opening range is set, breakouts above and below its boundaries frequently produce the day's strongest directional moves.
How the opening range is built:
From the first bar of each London or New York session, MERIDIAN accumulates the highest high and lowest low across all bars that fall within the opening range time window. Once a bar falls outside the ORB time window, the range is locked — the ORB high and ORB low are fixed for the remainder of the session.
ORB visualization:
The completed opening range is rendered as an orange-tinted box on the chart, spanning from the first ORB bar to the last ORB bar. This box remains on the chart as a reference level for the session.
Dashboard ORB status:
The dashboard displays the ORB status as FORMING (while the range is still building) or SET (once locked), along with the exact ORB high and low prices. This gives you advance notice before the ORB is complete — you can watch it forming in real time and prepare for the Setup B breakout signal.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Session Bias — VWAP and Meridian Positioning
MERIDIAN defines the current session's directional bias through two independent price positioning checks that together create a clear institutional bias reading.
VWAP bias:
Price above the session VWAP indicates institutional net-buying for the session — the volume-weighted average of all transactions favors the bull side. Price below indicates net-selling. The VWAP bias is updated on every bar as new volume flows in.
Meridian bias:
Price above the session meridian (the session range midpoint) means price is in the upper, premium half of the session range. Price below is in the discount half.
Combined session bias:
sessBull — price is both above VWAP and above the session meridian. Both the volume-weighted and range-position measures confirm bullish institutional bias
sessBear — price is both below VWAP and below the session meridian. Both measures confirm bearish institutional bias
This combined bias is the most important single dashboard reading in MERIDIAN. A bullish session bias means the institutional context favors long entries. A bearish session bias favors shorts. Entries against the combined session bias carry the highest failure rate of any MERIDIAN setup.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏷 Three Setup Types — A, B, and C
MERIDIAN fires signals through three distinct setup configurations, each representing a different institutional entry scenario anchored to session-based reference levels. All three can be enabled simultaneously.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup A — Prior Session Break & Retest
The most institutionally significant setup type. Fires when:
The current session's price closes above the prior session high (long) or below the prior session low (short) — the structural break of the prior session's boundary
Within 30 bars of the break, price pulls back to within ATR tolerance of the broken level
A qualifying rejection candle forms at the retest — confirming the broken level has flipped from resistance to support (long) or support to resistance (short)
Why prior session break and retest is the highest-quality setup: When London breaks the Asian high and then retests it, the break has been confirmed as a genuine institutional breakout rather than a wick spike. The retest at the prior session level provides the optimal entry price — buying exactly at the prior resistance that has now become support, with the stop below the level and the continuation target above. This is the institutional "break, retest, continue" sequence that produces the cleanest risk/reward in session-based trading.
Break detection markers: Small semi-transparent circles appear above (prior high break) or below (prior low break) the bar that closes through the prior session boundary — alerting you that a pending retest setup is now active. The system tracks the pending retest for up to 30 bars. If no qualifying retest occurs within that window, the pending state expires.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup B — Opening Range Breakout
The high-momentum setup type. Fires when:
The opening range has been fully set (ORB locked after the opening range period has elapsed)
Price closes above the ORB high (long) or below the ORB low (short) — the first close-based break of the opening range boundary
The close is on the correct side of the prior bar's close relative to the ORB level — confirming the break is not a wick through and back
A qualifying bull or bear rejection candle (minimum 50% wick ratio) confirms the breakout bar's directional commitment
Why the ORB breakout is a high-conviction institutional signal: The opening range represents the indecision of the first N minutes of a session — the market testing price levels before committing to a direction. The first body close beyond the ORB boundary is the signal that the indecision has resolved and institutional order flow has committed to a direction. The rejection candle requirement ensures the break was not passive drift but a genuine directional conviction bar.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Setup C — Meridian Bounce
The continuation and trend-following setup type. Fires when:
The session bias is fully established (sessBull for long, sessBear for short)
Price pulls back to within ATR tolerance of the session meridian (the session range midpoint)
A qualifying rejection candle forms — confirming the meridian held and price is rejecting back in the bias direction
Why the meridian bounce is a reliable continuation entry: In a trending session where price is above VWAP and above the session midpoint (sessBull), the meridian represents the natural pullback target — the highest-volume price zone within the session's lower half. Institutional buyers who missed the initial move use meridian pullbacks to add to positions. The rejection at the meridian in a sessBull environment is the continuation entry that offers the tightest stop (just below the meridian) with the continuation toward the session high as the target.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧠 The 7-Layer Confluence Engine
Every potential entry across all three setup types is scored through the same 7-layer confluence engine. The minimum default is 5 of 7.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 1 — Session Bias (Combined)
Awards 1 point when the combined session bias (sessBull for long, sessBear for short) agrees with the signal direction. This requires both VWAP positioning and meridian positioning to be aligned — the strongest single session-level directional indicator available.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 2 — VWAP Positioning
Awards 1 point when price is on the correct side of the session VWAP — above for longs, below for shorts. The VWAP layer is available independently from the combined session bias layer. On bars where price is above VWAP but below the meridian (or vice versa), the session bias may not score but the VWAP layer still contributes.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 3 — HTF Bias
Awards 1 point when the higher timeframe EMA structure (default: 60-minute, 21/55 EMA pair) agrees with the signal direction. Ensures the session-level setup is aligned with the macro institutional flow. A session setup against the HTF trend carries the highest failure rate of any setup type.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 4 — Trading Session Enabled
Awards 1 point when the current session is one of the configured tradeable sessions (London and NY on by default, Asian off by default). This layer enforces session selectivity — preventing signals from firing during sessions you have chosen not to trade. If the Asian session is disabled for trading, Asian session signals are blocked at this layer regardless of how strong the other confluences are.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 5 — Volume Expansion
Awards 1 point when the current bar's volume exceeds the volume moving average by the configured minimum multiplier (default: 1.1×). Confirms that the rejection candle or breakout bar has genuine institutional participation behind it — not a low-volume drift through a reference level.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 6 — Rejection Candle Quality
Awards 1 point when a qualifying bull or bear rejection candle is present. Bull rejection requires a bullish close with the close-to-low distance exceeding 50% of the bar range. Bear rejection requires a bearish close with the high-to-close distance exceeding 50%. This layer ensures the reference level produced a visible, decisive price rejection — not a passive touch.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 7 — Setup Type Trigger
Awards 1 point when any of the three enabled setup types fires on the current bar — a prior session retest (Setup A), an ORB breakout (Setup B), or a meridian bounce (Setup C). This layer is both a confluence score contributor and a hard prerequisite — no signal can fire without at least one setup type triggering.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🕯 Rejection Candle Confirmation
All three setup types require a qualifying rejection candle for a signal to fire. Two candle types qualify:
Bull rejection: A bullish close (close above open) where the distance from close to bar low exceeds 50% of the total bar range. The bar closed in its upper half — buyers dominated and rejected the level being tested.
Bear rejection: A bearish close where the distance from bar high to close exceeds 50% of the total range. The bar closed in its lower half — sellers dominated the rejection.
The same 50% wick threshold applies across all three setup types, ensuring every MERIDIAN signal has a consistent, minimum candle quality standard regardless of which session event triggered it.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Session-Anchored Stop Loss Placement
MERIDIAN places the stop loss at the most conservative of several session-based reference levels, plus an ATR buffer.
For bull signals: The stop is placed at the minimum of the current bar's low, the prior session high (the retested level), the ORB low (if applicable), and the session meridian — whichever is lowest — minus the configured ATR buffer (default: 1.0× ATR). This ensures the stop is beyond the level that would structurally invalidate the signal.
For bear signals: The stop is at the maximum of the current bar's high, the prior session low, the ORB high, and the session meridian, plus the ATR buffer.
Dynamic TP target: The take profit is computed as `risk × R multiple` (default: 2.5R) from the entry close — adapting to the actual stop distance rather than using a fixed ATR projection. On entries where the session reference stop is very close to entry, this naturally produces a tighter target; on wider stops, the target scales accordingly.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Live Dashboard
The 16-row real-time dashboard displays the complete internal state across five sections.
SESSION
Active — the currently active session: ASIAN, LONDON, NEW YORK, or OFF
VWAP Bias — ▲ ABOVE or ▼ BELOW, showing whether price is above or below the session VWAP. Color-coded yellow-green and red
Meridian — the exact price of the current session's equilibrium midpoint (session high + low / 2), color-coded purple
PRIOR SESSION
Prior Sess — which session completed most recently: ASIAN, LONDON, or NEW YORK
Prior Hi / Lo — the exact high and low of the prior session displayed as a price pair. These are the Setup A reference levels
OPENING RANGE
ORB Status — FORMING (still within the ORB time window) or SET (locked, breakout mode active). Orange when SET
ORB Hi / Lo — the exact opening range high and low prices once the range is locked
FILTERS
HTF Bias — higher timeframe EMA alignment: ▲ BULL, ▼ BEAR, or — FLAT
CONFLUENCE
Bull Score — live 0–7 score. Background highlights yellow-green when threshold is met
Bear Score — live 0–7 score. Background highlights red when threshold is met
Live confluence label: During active sessions, a small label near the session box displays B x/7 · S x/7 in real time, updated every bar — identical to ANCHOR, PIVOT, and the other systems in the AlphaX suite.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Chart Visual System
Current Session Box — a lightly tinted box covering the full range of the active session from its first bar to the current bar. Gray for Asian, yellow-green tinted for London, red tinted for New York
Session VWAP (cyan) — the volume-weighted average price anchored to the session start, plotted as a solid cyan line. The most important intraday reference for institutional fair value
Session Meridian (purple dots) — the session range midpoint (50% of the current session's high-low range), continuously updated
Prior Session High (red dashed) — the completed prior session's high. Setup A reference level for long setups
Prior Session Low (yellow-green dashed) — the prior session's low. Setup A reference level for short setups
Prior Session Meridian (purple dotted) — the midpoint of the prior session's range
Opening Range Box (orange tinted) — the locked ORB from the session start to the end of the opening range period. Setup B reference box
● Break markers (semi-transparent circles) — appear above the bar (prior high break) or below (prior low break) at the moment of the structural break, signaling a pending retest opportunity
▲ Triangle (below bar, yellow-green) — long signal. All conditions confirmed across any of the three setup types
▼ Triangle (above bar, red) — short signal
Live confluence label — B x/7 · S x/7 near the current session range on the last bar
SL Guide (red dotted circles) — session-anchored stop loss reference level
TP Guide (yellow-green dotted circles) — dynamically computed reward target
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚀 How to Trade with AlphaX MERIDIAN — Step by Step
Step 1 — Begin Each Session with a Reference Review
At the start of each London or NY session, check the dashboard for Prior Hi / Lo — these are your key Setup A reference levels for the session
Note the ORB Status — during the first 30 minutes of London or NY, watch the ORB forming. The ORB Hi / Lo will be your Setup B breakout reference once SET
Check HTF Bias — does the higher timeframe trend favor longs or shorts? This is the filter that determines which direction's signals you prioritize
Step 2 — Monitor Session Bias Development
As the session opens and develops, watch the VWAP Bias and Meridian rows on the dashboard. When both show ▲ ABOVE, the session bias is fully bullish — prioritize long setups. Both ▼ BELOW = prioritize shorts
Watch the live B/S score label near the session box. When the bull or bear score approaches the threshold, a signal may be imminent
Step 3 — Enter on the MERIDIAN Signal
A ▲ triangle below the bar confirms one of the three setup types has fired with sufficient confluence
Read the signal context: did price just retest the prior session high? Break the ORB? Bounce from the session meridian? The setup type determines which level your stop references
The SL and TP guides appear as dotted circles. The SL is the session-anchored structural stop. The TP is the R-multiple target
Setup A retests are the highest-quality entries — the prior session level has been validated as the new support/resistance. Setup B ORB breaks are highest-momentum. Setup C meridian bounces are best in strongly trending sessions
Step 4 — Manage Within the Session Context
Watch the session VWAP as the trade develops — price returning to VWAP during a long trade is a warning sign that session bias may be weakening
If the session meridian switches sides (price moves from above to below the session midpoint), the session bias has flipped. Consider tightening the stop or taking partial profit
Session transitions are exits: if London closes while you are in a trade, the session reference levels will update to New York levels on the NY open. Reassess the position in the context of the new session
Step 5 — End of Session Reset
At session end, the current session's high, low, and meridian become the prior session reference for the next session
The ORB resets for the new session's opening
Review the completed session's range and meridian before the next session opens — these become your Setup A reference levels going forward
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Identifying Low-Quality Conditions — When Not to Trade
Stand aside when:
Session shows OFF — no active session is being tracked. All signals are blocked and session reference levels may be stale
Session bias is split — VWAP and Meridian disagree — price above VWAP but below the session meridian (or vice versa) means the session has no clear institutional direction. The combined session bias layer will not score, reducing confluence quality
HTF Bias opposes the session bias — a bullish session bias against a bearish HTF means the current session is moving counter to the macro trend. These setups carry significantly higher reversal risk
ORB Status shows FORMING — the opening range has not been locked. No Setup B signals can fire. Do not anticipate the ORB breakout before the range is set
Prior Hi / Lo shows — on the dashboard — no completed prior session data is available. Setup A setups cannot fire. This occurs at the start of the first session after the chart loads
Confluence score is at minimum threshold exactly — when the score is at exactly the minimum and one or two filters are failing, the setup is borderline. Reduce position size or wait for a higher-quality signal
Multiple setup types firing simultaneously in the same direction — this is usually a positive signal, but verify the session context. If the ORB breakout, prior session retest, and meridian bounce are all triggering at the same time in the same bar, one of them is likely being triggered by coincidental price overlap rather than genuine session mechanics
The ideal MERIDIAN setup:
London or NY session active with tradeSessOk confirmed
HTF Bias and Session Bias both aligned in the same direction
Prior session high or low recently broken (Setup A pending) OR ORB locked and ready for Setup B
Price returning to the reference level with VWAP and Meridian both on the correct side
Strong rejection candle with volume above average
Confluence score at 6/7 or 7/7
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Key Features
🌐 Three-session tracking engine — Asian, London, and New York sessions tracked simultaneously with configurable start/end hours and timezone support
📊 Session-anchored VWAP — true cumulative VWAP computed from the first bar of each session, providing the most accurate institutional fair value reference per session
📍 Prior session levels — high, low, and meridian of the most recently completed session maintained and displayed as dashed reference lines
📦 Opening Range Box — first N minutes of London/NY captured as an orange ORB box with live FORMING / SET status. Breakout reference for Setup B
⚖ Session Meridian (Equilibrium) — the session range midpoint plotted as a purple dotted line, the equilibrium level for Setup C bounces and the combined session bias divider
🏷 Three setup types — Setup A (Prior Session Break & Retest), Setup B (Opening Range Breakout), Setup C (Meridian Bounce) — all configurable independently
🔮 Pending retest tracking — 30-bar retest window after every prior session break, with break circle markers at the moment of the structural break
🧠 7-layer confluence engine — Session Bias, VWAP Position, HTF Bias, Trading Session Gate, Volume Expansion, Rejection Candle, and Setup Type Trigger scored independently every bar
📊 Live confluence label near the session box — B x/7 · S x/7 updating in real time on the current bar
🎯 Session-anchored stop loss — stop placed at the most conservative of multiple session reference levels, not a fixed ATR distance
💹 Dynamic R-multiple TP target — computed as risk × R multiple, adapting to the actual stop distance
📡 HTF EMA bias filter — dual-condition higher timeframe alignment (EMA crossover + price confirmation)
⏱ Session trading filter — independently enable or disable signal firing for each of the three sessions
🎨 Session-coded color system — session box tints differentiate Asian (gray), London (yellow-green), and New York (red) at a glance
📊 16-row live dashboard — Session, Prior Session, Opening Range, Filters, and Confluence sections updated in real time
🔔 6 alert conditions — long/short entry, prior high/low break, ORB long/short breakout
⚙ Fully configurable — all session hours, timezone, ORB duration, setup type enables, confluence minimum, HTF timeframe and EMAs, volume filter, session trading gates, SL buffer, R-multiple target, and all colors are independently adjustable
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ Settings Reference
Session Engine
Session Timezone — UTC / America/New_York / Europe/London / Asia/Tokyo. Set to your preferred reference timezone
Track Asian Session — toggle Asian session tracking on or off
Asian Start / End (hour) — hour boundaries for the Asian session in the selected timezone (defaults: 0 / 8)
Track London Session — toggle London session tracking
London Start / End (hour) — hour boundaries for London (defaults: 8 / 13)
Track NY Session — toggle New York session tracking
NY Start / End (hour) — hour boundaries for NY (defaults: 13 / 21)
Opening Range (mins) — the number of minutes from the session open used to build the ORB (default: 30)
Entries & Confluence
Setup A · Prior Session Break & Retest — toggle the break-and-retest setup type
Setup B · Opening Range Breakout — toggle the ORB breakout setup type
Setup C · Meridian Bounce — toggle the session equilibrium bounce setup type
Retest Tolerance (xATR) — maximum ATR distance from the reference level that still qualifies as a retest (default: 0.35)
Min Confluence Layers (of 7) — minimum score to fire a signal (default: 5)
Show Entry Signals — toggle signal triangles
Show Confluence Label — toggle the live B/S score label near the session box
Signal Cooldown (bars) — minimum bars between consecutive signals (default: 6)
Filters
HTF Trend Filter — toggle the higher timeframe EMA alignment requirement
HTF Timeframe — the higher timeframe for EMA data (default: 60-minute)
HTF Fast / Slow EMA — EMA periods on the HTF (defaults: 21 / 55)
Volume Confirm — when on, entry volume must exceed the average by the minimum multiplier
Min Volume vs Avg — minimum volume ratio (default: 1.1)
Volume Avg Length — SMA length for volume baseline (default: 20)
Trade London Session — when on, signals can fire during London hours
Trade NY Session — when on, signals can fire during NY hours
Trade Asian Session — when on, signals can fire during Asian hours (default: off — Asian sessions typically produce lower-quality setups)
Exit Guidance
ATR Length — ATR calculation lookback (default: 14)
Show SL / TP Guides — toggle stop and target dotted circle plots
SL Distance (xATR) — ATR buffer added beyond the session-anchored stop reference (default: 1.0)
TP Reward (R) — take profit as a multiple of the actual risk from entry to stop (default: 2.5)
Display
Show Current Session Box — toggle the session range box
Show Prior Session H/L — toggle prior session high, low, and meridian dashed lines
Show Session VWAP — toggle the session VWAP line
Show Opening Range Box — toggle the ORB orange box
Show Dashboard — toggle the full dashboard panel
Dashboard Position — Top Left / Top Right / Bottom Left / Bottom Right
Colors
Bull / Bull Bright — yellow-green family for all bullish signals and London session elements
Bear / Bear Bright — red family for all bearish signals and NY session elements
Opening Range — orange for ORB box and status indicators
Meridian / EQ — purple for session meridian, prior session meridian, and equilibrium elements
Session VWAP — cyan for the session VWAP line
SL Guide / TP Guide — stop and target circle colors
Dash Text / Dash BG / Dash Header / Dash Section / Dash Frame — full dashboard color control
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 Alert Conditions (6 total)
Entry Alerts
Meridian Long — all conditions confirmed. Long signal fired
Meridian Short — all conditions confirmed. Short signal fired
Structure Alerts
Meridian Break Prior High — price has closed above the prior session high. Setup A long retest window is now active — watch for the retest
Meridian Break Prior Low — price has closed below the prior session low. Setup A short retest window is now active
Opening Range Alerts
Meridian ORB Long — opening range broken to the upside with all setup and confluence conditions confirmed
Meridian ORB Short — opening range broken to the downside with all conditions confirmed
All alert messages are formatted as const strings for clean webhook and notification platform integration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Recommended Settings by Instrument & Timeframe
The default configuration is optimized for XAUUSD, major forex pairs, and indices on M5–M15 in UTC timezone:
Session hours in UTC — gold and forex are most active during London (08:00–13:00) and NY (13:00–21:00) hours. Asian session trading is disabled by default for clean intraday setups
ORB at 30 minutes — the classic institutional opening range. The first 30 minutes of London and NY frequently establish the session's directional commitment
Retest tolerance at 0.35× ATR — sensitive enough to catch genuine retests on M5–M15 without requiring price to tick exactly at the level
TP Reward at 2.5R — session-based setups on gold and forex typically produce moves sufficient to achieve 2.5R when the session bias is correctly identified
For other instruments or timeframes, adjust:
M1–M3 scalping — reduce Cooldown to 3, reduce SL Buffer to 0.5, reduce TP Reward to 1.5–2.0, use tighter Retest Tolerance at 0.2
H1 intraday swing — increase ORB to 60 minutes (capturing the first full H1 candle), increase Retest Tolerance to 0.5, increase TP Reward to 3.5–4.0, set HTF to H4 or Daily
Crypto (BTC, ETH) — use UTC timezone, enable all three sessions (crypto trades 24/7), reduce retest tolerance to 0.25 for the narrower wicks typical of crypto support/resistance retests
Indices (NAS100, US30) — focus exclusively on NY session (13:30–20:00 UTC for US equity cash session), disable London trading for equity index instruments, tighten ORB to 15 minutes (the US equity opening range is frequently set in the first 15 minutes)
More signals — lower Min Confluence to 4, enable Asian trading, disable volume filter
Highest-quality only — raise Min Confluence to 6–7, enable only Setup A and B (disable meridian bounce), require London and NY only
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
👥 Who This Is For
⏱ Session traders and market structure players — MERIDIAN is the definitive session intelligence system. Every reference level, every bias indicator, and every signal type is anchored to the session clock
🥇 Gold (XAUUSD) and forex intraday traders — the three-session framework is most powerful on instruments where London and New York session transitions drive the most significant intraday moves. Default settings are calibrated for gold and major forex pairs
📊 Opening range traders — the ORB system provides a complete, rules-based opening range breakout framework with confluence scoring, volume confirmation, and rejection candle quality filtering
🎯 Break-and-retest traders — Setup A is the quantitative implementation of the prior session break and retest — the most reliable institutional intraday pattern across all liquid markets
🧠 Traders who use VWAP as a primary reference — the session-anchored VWAP and the VWAP-based bias scoring system make MERIDIAN the ideal companion for any VWAP-centric trading approach
📈 Traders who want session context on every trade — every signal label, every dashboard row, and every reference level in MERIDIAN tells you exactly where you are in the session cycle and what the institutional context is
⚠ Traders who struggle with time-of-day discipline — the session trading gates (enable/disable individual sessions) enforce time-of-day discipline automatically. If you do not trade the Asian session, disable it and no Asian signals will ever appear
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📝 Notes
All signals are confirmed on bar close — the indicator is non-repainting by design. Session state, VWAP, meridian, ORB values, and confluence scoring all finalize on confirmed bars only
The session boxes and prior session lines are redrawn on the last bar only for chart performance. On very fast timeframes with long chart history, this redraw happens on every new bar's render — this is normal behavior for last-bar-only visual updates
The VWAP is a true session-anchored VWAP — it resets at each session's first bar and accumulates correctly through the entire session. It is not a daily VWAP or a rolling VWAP
The prior session data updates at session transitions. On the very first session after the chart loads, no prior session data may be available — the Prior Hi / Lo dashboard rows will show — until the first session completes
The 30-bar retest window for Setup A (prior session break and retest) starts from the bar of the break. If no retest occurs within 30 bars, the pending retest state expires. On slower timeframes (H1), 30 bars may cover many hours — consider reducing the window or accepting that H1 retests sometimes take longer to develop
Maximum 500 labels, 500 lines, and 50 boxes are rendered. With three sessions each potentially drawing boxes and lines, the limit is practically sufficient for standard chart history. On very long chart histories on very fast timeframes, the oldest visual elements may be removed by TradingView's rendering limits
The session timezone setting must match the timezone in which you want session boundaries defined. UTC is the default and recommended for instruments that trade globally. For US equity index traders, America/New_York may be more intuitive
The indicator does not connect to any broker or account — the dashboard and signals are purely analytical
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Disclaimer
This indicator is a technical analysis and visualization tool intended for educational and informational purposes only. It does not constitute financial advice or a recommendation to buy or sell any financial instrument. All signals are generated from historical and real-time price data using mathematical calculations — their accuracy or profitability is not guaranteed. Past performance of any signal type does not guarantee future results. Always conduct your own analysis, use proper risk management, and consult a licensed financial advisor before making any trading decisions. The author accepts no responsibility for any losses incurred from the use of this indicator.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built for traders who understand that the market tells a different story in every session — and who want a system that reads each chapter in real time. Indicador
NLMS Volatility Trail [BackQuant]NLMS Volatility Trail
Overview
NLMS Volatility Trail is an adaptive trend-following overlay that combines a machine-learning style adaptive filter with a volatility-based trailing structure. It is built around the Normalized Least Mean Squares (NLMS) algorithm, then converts that adaptive estimate into an ATR-based trailing line designed to follow directional regimes while filtering out minor noise.
The indicator has two core layers:
An NLMS adaptive filter , which learns a dynamic price estimate from prior bars.
An ATR volatility trail , which converts that learned estimate into a step-like directional trailing structure.
The goal is to produce a trend line that is more adaptive than a traditional moving average and more structured than a raw adaptive filter. The NLMS engine learns the underlying price path, while the ATR trail adds volatility-aware confirmation so trend shifts only occur when the adaptive estimate moves meaningfully.
Core idea
Most trend filters use fixed smoothing rules. An EMA, SMA, WMA, or HMA always applies the same mathematical weighting scheme regardless of whether the market is trending, ranging, expanding, or compressing.
NLMS is different. It continuously updates its internal weights based on prediction error.
This means the filter is not just averaging price. It is constantly asking:
How well did the previous weighting structure predict the current bar?
How large was the error?
How should the weights adjust to reduce future error?
The second layer then takes that adaptive estimate and applies an ATR-based trailing mechanism around it. This creates a volatility-adjusted trend trail that reacts to confirmed shifts while ignoring smaller movements that do not exceed the range structure.
What NLMS is
NLMS stands for Normalized Least Mean Squares . It is an adaptive filtering algorithm from digital signal processing. It is closely related to the original LMS algorithm developed by Bernard Widrow and Ted Hoff, which became one of the foundational online learning methods used in adaptive systems.
Adaptive filters have historically been used in:
Noise cancellation
Echo cancellation
Telecommunications
Radar and sonar processing
Signal prediction
Control systems
The basic purpose is to estimate or predict a signal while continuously adapting to changing conditions.
In trading terms, this indicator uses NLMS to build a learned estimate of price from prior bars.
How the NLMS filter works
The filter uses a set of historical inputs called taps .
If taps = 72, the model uses the previous 72 bars:
source
source
source
...
source
Each tap has a learned weight.
The prediction is calculated as:
prediction = w1 × source + w2 × source + ... + wM × source
The filter then compares the prediction to the actual current source:
error = source - prediction
That error drives the weight update.
If the prediction was poor, the weights adjust more.
If the prediction was accurate, the weights adjust less.
This creates an adaptive estimate that evolves with market behavior.
Why it is normalized
The normal LMS algorithm updates weights based on the raw input and prediction error. The issue is that if the input signal becomes large or volatile, updates can become unstable.
NLMS solves this by dividing the update by the input power:
power = sum(source ²)
The update becomes:
w = w + (μ / (ε + power)) × error × input
This normalization makes the learning process more stable across different volatility environments.
When the input power is high:
Updates are scaled down.
The filter avoids overreacting.
When the input power is low:
Updates are allowed to remain meaningful.
This is why NLMS is better suited to markets than a basic adaptive filter. Markets constantly shift between quiet and volatile regimes.
Weight initialization
The script initializes all weights equally:
weight = 1 / M
This means the filter starts with an SMA-like prior. Before learning begins, every historical bar contributes equally.
Over time, the filter adapts away from that equal-weight baseline and learns its own weighting structure.
Inputs that control the NLMS engine
Filter Taps (M)
Controls how many historical bars the model learns from.
Higher taps:
More memory
Smoother adaptive estimate
Slower response to regime change
Lower taps:
Less memory
Faster reaction
More noise sensitivity
Step Size (μ)
Controls the learning rate.
Lower μ:
Slower learning
Smoother output
More stable
Higher μ:
Faster learning
More responsive
Can become noisy if too aggressive
This is one of the most important settings. It controls how quickly the model changes its internal weights.
Regularization (ε)
Prevents instability when input power is very low.
It acts as a stabilizer in the denominator:
ε + power
Higher values make updates more conservative.
Lower values allow stronger adaptation but can become less stable in quiet conditions.
From adaptive filter to volatility trail
The raw NLMS output is not plotted directly as the main trend line. Instead, it is passed into a volatility trailing structure.
The script builds an ATR band around the NLMS estimate:
Upper band = NLMS output + ATR × factor
Lower band = NLMS output - ATR × factor
Then it creates a trailing value that only updates when the NLMS band structure forces it to move.
This creates a trail that behaves similarly to a volatility stop, but the center is not price or hl2. It is the learned NLMS estimate .
ATR volatility trail logic
The trail starts from the NLMS output, then carries forward its previous value:
nlmsAtr := previous nlmsAtr
Then:
If lower band rises above the trail, the trail moves up.
If upper band falls below the trail, the trail moves down.
This creates a directional trailing structure:
In bullish regimes, the trail ratchets upward.
In bearish regimes, the trail ratchets downward.
It filters out small movements because price must move enough relative to ATR and the adaptive estimate to change the trail direction.
Why combine NLMS with ATR
NLMS alone gives an adaptive estimate, but it can still wiggle as the model learns.
ATR alone gives volatility structure, but it is usually tied to raw price and fixed smoothing.
Combining them gives:
Adaptive intelligence from NLMS.
Volatility confirmation from ATR.
Cleaner trend state transitions.
Less dependence on fixed moving-average assumptions.
The NLMS model learns the underlying price behavior, while ATR decides whether movement is large enough to matter.
Trend direction
Trend flips are detected from the trail itself:
Bullish when nlmsAtr crosses above its previous value.
Bearish when nlmsAtr crosses below its previous value.
This means signals are generated when the volatility trail changes direction, not when price simply crosses the line.
That is important because:
The trail must structurally move.
The signal is tied to confirmed trail direction.
Noise around the line does not automatically create a flip.
Visual design
The indicator includes several visual layers.
Main trail line
The central plotted line is the NLMS ATR trail. It changes color based on the current trend state:
Green for bullish trail direction.
Red for bearish trail direction.
Gray before a trend state is established.
Gradient fill
The script fills the space between price and the trail:
If price is above the trail, bullish fill is shown.
If price is below the trail, bearish fill is shown.
The fill is stronger near the trail and fades toward price, making the trail feel like the active structural reference.
Trail glow
A soft glow is drawn around the trail using a small ATR offset:
glow = ATR(14) × 0.06
This highlights the trail visually without cluttering the chart.
Trend candles
Candles are colored by trend state:
Bullish trend = bullish candles.
Bearish trend = bearish candles.
This allows the script to function as a complete regime overlay.
How to interpret the indicator
Bullish state
A bullish state occurs when the NLMS volatility trail turns upward.
This suggests:
The adaptive filter is shifting higher.
The ATR trail has confirmed upward structure.
Trend pressure has turned bullish.
Bearish state
A bearish state occurs when the NLMS volatility trail turns downward.
This suggests:
The adaptive estimate is shifting lower.
The volatility trail has confirmed downside structure.
Trend pressure has turned bearish.
Price above the trail
Generally indicates bullish structure.
Price below the trail
Generally indicates bearish structure.
But the most important signal is the direction of the trail itself, not every price touch.
How to use it in practice
1) Trend following
Use the trail direction as the primary bias:
Favor longs when the trail is bullish.
Favor shorts when the trail is bearish.
2) Dynamic support/resistance
The trail can act like a dynamic structural level:
In uptrends, pullbacks toward the trail can act as support.
In downtrends, rallies toward the trail can act as resistance.
3) Trade management
The trail can be used as:
A trailing stop guide.
A regime invalidation level.
A trend continuation reference.
4) Regime filtering
Because the line adapts using NLMS and only flips when the volatility trail turns, it can be used to filter other entries:
Take only long setups during bullish trail regimes.
Take only short setups during bearish trail regimes.
Avoid countertrend trades when the trail is strongly directional.
Difference from normal Supertrend or ATR trails
A normal ATR trail is usually built directly from price or hl2.
This indicator is different because the trail is built around an adaptive learned estimate.
That means:
The centerline is not raw price.
It is not a fixed moving average.
It is a continuously learned NLMS estimate.
So the trail has a different character:
More adaptive than a standard moving average trail.
More stable than a raw price-based ATR stop.
More responsive to changing market structure than fixed filters.
Difference from the NLMS Adaptive Trend Filter
The NLMS Adaptive Trend Filter plots the learned estimate directly and reads trend from its slope.
NLMS Volatility Trail goes one step further:
It uses the learned estimate as the base.
Then wraps it with ATR structure.
Then turns that into a trailing regime line.
So this version is more structure-oriented and better suited for trailing trend behavior.
Parameter tuning
Taps
Use higher taps for smoother trend structure.
Use lower taps for faster adaptation.
Step Size
Use lower step size for stability.
Use higher step size for responsiveness.
Regularization
Use higher regularization when the filter feels unstable.
Use lower regularization when the filter is too sluggish.
ATR Period
Controls volatility estimate:
Shorter = more reactive trail.
Longer = smoother trail.
ATR Factor
Controls band width:
Higher factor = wider trail, fewer flips.
Lower factor = tighter trail, more flips.
Strengths
Combines adaptive filtering with volatility trailing logic.
Learns from market structure instead of using fixed weights.
Uses ATR to reduce noise and confirm meaningful movement.
Good for trend following and trailing stop frameworks.
Visually clean with gradient fill and candle coloring.
Limitations
Still reactive, not predictive.
Can lag during violent reversals.
High learning rates may create noise.
Low ATR factors may cause whipsaws.
Requires tuning for timeframe and asset volatility.
Summary
NLMS Volatility Trail combines an adaptive NLMS predictor with an ATR-based trailing structure. The NLMS layer continuously learns a dynamic estimate of price from historical bars, while the ATR trail converts that estimate into a cleaner directional regime line. This makes the indicator more adaptive than a traditional moving average and more structured than a raw adaptive filter. It is best used as a trend-following overlay, dynamic support/resistance guide, and volatility-aware trailing framework.
Indicador
[ A L P H A X ] PIVOT - Smart Money StructureAlphaX PIVOT — Smart Money Structure + OTE Pullback Engine: Market Structure Tracking, Optimal Trade Entry Zones, Liquidity Sweep Detection & 7-Layer Confluence Scoring
AlphaX PIVOT is a professional-grade smart money pullback system built around two of the most powerful concepts in institutional price action: market structure and the Optimal Trade Entry zone. Where breakout-based systems enter at the moment of structural displacement — chasing the move after it has already begun — PIVOT waits for the market to pull back into the precise Fibonacci retracement zone where institutional continuation orders are resting, and fires only when a qualified rejection candle confirms within that zone with multi-layer confluence backing. The result is a system that gives you the same directional conviction as a breakout entry at a structurally superior price — buying the pullback into institutional demand after a bullish BOS or CHoCH, selling the pullback into institutional supply after a bearish structure shift — with a stop anchored to the structural swing low or high rather than an arbitrary ATR distance. Designed for precision-entry traders across crypto, forex, gold, and indices on any timeframe.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📐 The Core Philosophy — Why Pull Back to OTE?
A Break of Structure or Change of Character tells you that the market has shifted direction at the institutional level. But the bar that breaks structure is rarely the optimal entry — it has already moved aggressively, the risk/reward from entry is reduced, and a pullback is statistically likely before the continuation begins.
The Optimal Trade Entry concept solves this. After a structural displacement move, price almost always retraces into a specific Fibonacci retracement zone — the 61.8% to 78.6% retracement of the displacement leg — before the next move in the structural direction begins. This zone is where institutional orders waiting at discount prices (in a bull structure) or premium prices (in a bear structure) are filled. Entering in the OTE zone means entering where institutions are entering, with the displacement leg already confirmed as the directional signal and the structural swing as the natural stop reference.
PIVOT detects every structural event, computes the OTE zone for the displacement leg in real time, and monitors for qualified rejection entries within that zone — all while running a 7-layer confluence engine that scores every potential entry before it fires.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏗 Market Structure Engine — Tracking BOS & CHoCH
The market structure engine runs a real-time fractal pivot detection system that tracks the most recent confirmed swing high and swing low on every bar, identifies every Break of Structure and Change of Character event, and maintains a live structural trend state.
Pivot detection:
Swing highs and lows are detected using a configurable pivot length (default: 5 bars each side). A pivot is confirmed when the specified number of bars on both the left and right side are lower (for a pivot high) or higher (for a pivot low). This creates confirmation — not just a local high or low, but a genuine fractal swing point.
Break of Structure (BOS):
When price closes above the most recent confirmed swing high while the structure is already bullish, a bullish BOS is detected — confirming the uptrend is intact and continuing. When price closes below the most recent swing low in a bearish structure, a bearish BOS is confirmed. BOS events are continuation signals — the existing structure is reinforcing itself.
Change of Character (CHoCH):
When price closes above a swing high while the structure is bearish, a bullish CHoCH is detected — the character of the market has changed from bearish to bullish. A bearish CHoCH is the inverse. CHoCH events are the highest-quality structural signals — they represent genuine institutional trend reversals and form the trigger for PIVOT's highest-conviction setup type.
Structure break mode:
The Close Only setting (default: on) requires a candle body close beyond the swing level for a BOS or CHoCH to register. When off, any wick touch counts. Body close is the stricter, cleaner mode — it eliminates false structure breaks caused by wick spikes that fail to close through the level, producing fewer but more reliable structural events.
Live swing levels:
The most recent confirmed swing high (plotted as a red dashed line) and swing low (yellow-green dashed line) are maintained on the chart in real time, extending forward until superseded by a new confirmed pivot. These levels represent the current active liquidity pools — the precise levels where the next sweep event is likely to occur.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📦 Structure Leg Box & Equilibrium — The Dealing Range
Every confirmed structure break event spawns a Structure Leg Box — a semi-transparent purple rectangle anchored to the displacement leg that produced the structural event. This box is the visual equivalent of the ANCHOR trend segment box, providing immediate context for the current structural move's price range.
Box construction:
For a bullish structure break, the leg box spans from the previous swing low (the origin of the displacement) to the close that broke structure — capturing the full range of the institutional displacement move. For a bearish structure break, it spans from the previous swing high down to the structure break close.
Equilibrium line:
The midpoint of the structure leg box — the 50% retracement level — is plotted as a purple dotted line extending forward. This is the leg's equilibrium level and the dividing line between discount (below EQ, favorable for longs) and premium (above EQ, favorable for shorts). The Premium/Discount requirement enforces that PIVOT signals can only fire when price is in the institutionally correct zone relative to this level.
Live updating:
The box expands as the trend develops — if price makes new highs in a bull leg, the box top extends upward. The equilibrium adjusts continuously. This ensures the OTE calculations always reflect the full extent of the current structural leg, not just the initial displacement.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 The OTE Zone — Optimal Trade Entry Band
The Optimal Trade Entry zone is a Fibonacci retracement band calculated from the structure leg's high and low — the 61.8% to 78.6% retracement zone (configurable). This is the institutional re-entry zone — the price area where sophisticated traders who missed the initial displacement fill their positions on the pullback.
OTE calculation for bull structure:
OTE Top = Leg High − (Leg Range × OTE Fib Low). Default: Leg High − (Range × 0.618)
OTE Bottom = Leg High − (Leg Range × OTE Fib High). Default: Leg High − (Range × 0.786)
This creates a band in the lower portion of the leg range — price must retrace between 61.8% and 78.6% of the upward displacement before the OTE zone is active.
OTE calculation for bear structure:
OTE Bottom = Leg Low + (Leg Range × OTE Fib Low)
OTE Top = Leg Low + (Leg Range × OTE Fib High)
This creates a band in the upper portion of the leg range — price must retrace between 61.8% and 78.6% of the downward displacement before the OTE zone is active.
Why the 61.8–78.6% zone: The 61.8% (golden ratio) and 78.6% (square root of 0.618) retracement levels are the two most consistently respected Fibonacci levels in institutional price delivery. They represent the deepest pullback levels that remain structurally valid — a retracement beyond 78.6% technically invalidates the structure leg's momentum. Entries within this zone maximize reward (entering near the deepest discount in a bull leg) while minimizing risk (the stop is at the structural swing, not far from the OTE bottom).
OTE zone visualization: A semi-transparent purple box rendered from the leg start bar to two bars beyond the current bar, spanning the OTE top and bottom prices. The zone extends and updates in real time as the leg evolves. The exact OTE band price levels are displayed on the dashboard for immediate reference.
In-OTE detection: The current bar is considered in the OTE zone when the bar's low (for bull setups) reaches within the OTE band, or the bar's high (for bear setups) reaches within the OTE band. This detects the precise moment price has retraced into the optimal entry area.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
💧 Liquidity Sweep Detection
The sweep detection engine identifies liquidity grab events relative to recent price extremes, adding an important second dimension to PIVOT's entry context. A sweep is detected when price briefly extends beyond the recent high or low reference level by a minimum ATR depth, then reverses and closes back inside — the classic stop-hunt signature.
Bull sweep: The current bar's low extends below the lowest low of the lookback period (default: 20 bars) by at least the minimum sweep depth (default: 0.1× ATR), and the bar closes above that low and closes bullish (close above open). Sell-side liquidity has been grabbed.
Bear sweep: The high extends above the highest high of the lookback period by at least the minimum depth, and the bar closes below that high and closes bearish. Buy-side liquidity has been grabbed.
Sweep recency: PIVOT accepts sweeps from the current bar or either of the two preceding bars — a three-bar recency window. This accommodates the common scenario where the sweep candle precedes the OTE entry bar by one or two bars, allowing the confluence engine to credit the sweep even when entry occurs slightly after the grab.
Setup B — Sweep + CHoCH: When a sweep occurs within 40 bars of a Change of Character event and price is simultaneously in the OTE zone with a rejection candle, PIVOT's second setup type fires — the Sweep + CHoCH entry. This is the highest-conviction entry type: a CHoCH confirms the structural reversal, the sweep confirms institutional liquidity accumulation, and the OTE entry delivers the optimal price. All three institutional signals converging simultaneously.
Sweep markers (optional): Small orange circles can be plotted above or below bars where sweeps are detected. Off by default — sweeps count toward confluence scoring regardless of whether markers are displayed — but enabling them provides visual awareness of every liquidity event on the chart.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🕯 Rejection Candle Confirmation
Every PIVOT entry requires a qualifying rejection candle within the OTE zone — the candle that demonstrates price has touched the OTE level and been rejected back in the structural direction.
Bull rejection (Bullish Rejection or Engulfing):
Bullish Rejection — the bar closes bullish (close above open) and the close-to-low distance represents more than 55% of the bar's total range. The lower wick consumes the majority of the bar's range — buyers overwhelmed sellers that pushed into the OTE zone
Bullish Engulfing — a bullish close that fully engulfs the prior bearish candle — closing above the prior open while the prior candle was bearish. Confirms a clean reversal of the pullback momentum
Bear rejection (Bearish Rejection or Engulfing):
The mirror conditions — a bearish close with the high-to-close distance exceeding 55% of range, or a bearish engulfing of the prior bullish candle.
Why candle confirmation is essential: The OTE zone being touched is a necessary but not sufficient condition for entry. Price can drift through the OTE zone on low momentum without producing a genuine reversal. The rejection candle requirement ensures that the OTE touch produced a visible institutional response — not just a passive drift through the zone.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧠 The 7-Layer Confluence Engine
Every potential entry is evaluated across seven independent confluence layers. The default minimum is 5 of 7 — a high-quality gate that blocks setups where several dimensions of confirmation are missing.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 1 — Market Structure Direction
Awards 1 point when the current structural trend agrees with the signal direction — bullish structure for longs (structure == 1), bearish for shorts. This is also a hard prerequisite enforced in the setup conditions — no PIVOT signal can fire without the structural trend being established in the signal direction. Structure is simultaneously a confluence layer and a foundational entry requirement.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 2 — OTE Zone Touch
Awards 1 point when the current bar is within the OTE retracement band for the active leg direction — the 61.8–78.6% retracement zone. Also a hard prerequisite in the setup conditions. Ensures the entry is at the institutionally optimal retracement depth, not at an arbitrary price within the leg range.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 3 — Premium/Discount Zone
Awards 1 point when price is in the correct zone relative to the leg equilibrium — below EQ (discount) for bull entries, above EQ (premium) for bear entries. The PD Zone layer enforces the institutional entry positioning principle: buy when price is cheap relative to the leg's fair value, sell when expensive. A valid OTE touch in the wrong PD zone (above EQ for a bull entry) carries a fundamental positioning problem — this layer blocks it.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 4 — HTF Bias
Awards 1 point when the higher timeframe EMA structure (default: 60-minute, 21/55 EMA) agrees with the signal direction, using the same strict condition as SURGE and ANCHOR — the HTF fast EMA must be above the slow EMA and the HTF close must be above the fast EMA for a bull vote. A bull OTE entry against a bearish HTF is a counter-trend trade; this layer ensures PIVOT's signals align with the macro institutional flow.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 5 — Liquidity Sweep
Awards 1 point when a qualifying sweep has occurred within the three-bar recency window in the correct direction. A sweep before or coinciding with the OTE entry dramatically increases the probability that the pullback is a genuine institutional accumulation event rather than a mechanical retracement. When the Sweep Filter is disabled, this layer is not available for scoring — the total achievable score drops to 6 of 6 in that configuration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 6 — Rejection Candle
Awards 1 point when a qualifying bull rejection or bullish engulfing candle (long) or bear rejection or bearish engulfing candle (short) is present on the current bar. This is the candle confirmation layer — confirming that the institutional response to the OTE touch is visible and decisive on the current bar.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 7 — ADX + Volume Expansion
Awards 1 point when both the ADX filter and the volume expansion filter pass simultaneously. ADX confirms the market has directional strength rather than ranging. Volume exceeding the moving average confirms genuine institutional participation on the entry candle rather than a low-activity drift through the OTE zone. Both conditions must be true for the single layer point — they are evaluated jointly.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏷 Two Setup Types — A and B
PIVOT fires signals through two distinct setup configurations, each representing a different institutional entry scenario. Both can be enabled simultaneously.
Setup A — OTE Pullback:
The foundational PIVOT setup. Fires when the market structure is established (BOS or CHoCH has confirmed), the displacement leg is active, price pulls back into the 61.8–78.6% OTE zone, a rejection candle forms within the zone, and the full confluence stack meets the minimum score. This is the highest-frequency setup type — it captures the standard institutional pullback sequence following any qualifying structure event.
Setup B — Sweep + CHoCH:
The premium PIVOT setup. Requires all Setup A conditions plus a Change of Character within the lookback window (40 bars) and a qualifying liquidity sweep within the three-bar recency window. The sequence is: liquidity sweep (stop hunt) → CHoCH (structural reversal confirmation) → OTE pullback (optimal entry). When all three institutional events converge simultaneously in the OTE zone with a rejection candle, this is among the highest-conviction setups available in the entire AlphaX indicator suite.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Structural Stop Loss Placement
PIVOT uses structurally anchored stop placement — the stop is placed beyond the most recent confirmed swing low (for bull entries) or swing high (for bear entries), plus a small configurable ATR buffer (default: 0.25× ATR).
Why this is the correct stop for OTE entries: The OTE entry is made on the premise that the structural swing low (bull) or high (bear) will hold — it is the key level whose violation would invalidate the entire structural thesis. If price closes through the swing low after a bull OTE entry, the structure leg is negated, the displacement was a false break, and the position thesis is fundamentally wrong. The structural swing is therefore not an arbitrary stop choice — it is the precise price at which the trade is provably wrong.
This produces stops that adapt naturally to the leg size: large legs with distant swings produce wider stops and wider profit targets; tight legs with nearby swings produce tighter, higher-precision entries. The risk/reward is computed dynamically as `(close − slGuide) × TP Reward (R)`.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Live Dashboard
The 16-row real-time dashboard displays the complete internal state across four sections.
STRUCTURE
Market Struct — current structural trend: ▲ BULLISH, ▼ BEARISH, or — NEUTRAL
PD Zone — current position relative to leg equilibrium: ◧ DISCOUNT, ◧ PREMIUM, or — EQ
Leg EQ — the exact leg equilibrium price (50% of the structure leg range) in real time
OTE Band — the current OTE zone bottom and top prices. Updates live as the leg expands
FILTERS
HTF Bias — higher timeframe EMA alignment: ▲ BULL, ▼ BEAR, or — FLAT
ADX — live ADX value with ✓ or ✗ pass/fail
Session — ✓ ACTIVE or ✗ OFF
LEVELS
Swing Hi — the most recent confirmed fractal swing high price. This is the current sell-side liquidity level and bear structural reference
Swing Lo — the most recent confirmed fractal swing low. The current buy-side liquidity level and bull structural stop reference
CONFLUENCE
Bull Score — live 0–7 confluence score. Background highlights yellow-green when threshold is met
Bear Score — live 0–7 score. Background highlights red when threshold is met
Live confluence label: During BUILDING and active leg phases, a small label near the OTE zone on the last bar shows B x/7 · S x/7 in real time — identical to ANCHOR's live score display — so you can monitor confluence building without dashboard attention.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Chart Visual System
Structure Leg Box (purple, semi-transparent) — the dealing range of the current displacement leg from structural origin to current price extreme. Adapts as the leg evolves
OTE Band Box (purple, deeper tint) — the 61.8–78.6% retracement zone of the current leg, extending two bars beyond the current bar for forward visibility
Leg Equilibrium Line (purple dots) — the 50% midpoint of the structure leg, continuously updated
Swing High Line (red dashed) — the most recent confirmed fractal swing high
Swing Low Line (yellow-green dashed) — the most recent confirmed fractal swing low
▲ Small Triangle (BOS Bull) — bullish Break of Structure, semi-transparent yellow-green
▲ Large Triangle (CHoCH Bull) — bullish Change of Character, bright yellow-green, larger size
▼ Small Triangle (BOS Bear) — bearish Break of Structure, semi-transparent red
▼ Large Triangle (CHoCH Bear) — bearish Change of Character, bright red, larger size
● Circle (optional, orange) — sweep detection markers when Show Sweep Markers is enabled
▲ Large Triangle (bull signal) — PIVOT long entry. All conditions confirmed
▼ Large Triangle (bear signal) — PIVOT short entry
Live confluence label — B x/7 · S x/7 near the OTE zone on the current bar
SL Guide (red dotted circles) — structural stop loss level below/above the swing reference
TP Guide (yellow-green dotted circles) — dynamically computed reward target based on R multiple
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚀 How to Trade with AlphaX PIVOT — Step by Step
Step 1 — Identify the Structural Context
Check the dashboard Market Struct row. ▲ BULLISH or ▼ BEARISH tells you the directional bias. — NEUTRAL means no structure is established — no setup can develop
Note the Swing Hi and Swing Lo levels on the dashboard. These are the current liquidity pools and structural stop references
Check HTF Bias — does the higher timeframe agree with the current structure? HTF alignment is worth 1 confluence point and significantly improves setup quality
Step 2 — Watch for a Structure Event
A large bright ▲ CHoCH triangle below the bar marks a bullish Change of Character — the highest-priority structural event. The structure leg box and OTE zone will draw immediately
A smaller ▲ BOS triangle marks a bullish Break of Structure — confirmation the trend is continuing
After either event, the Structure Leg Box and OTE Band are drawn in real time. Note where the OTE zone sits in absolute price terms from the dashboard's OTE Band row
Step 3 — Wait for the OTE Pullback
After the displacement, watch price retrace toward the OTE zone. The purple OTE box on the chart gives you the exact price boundaries
Check PD Zone on the dashboard — for bull entries, you want ◧ DISCOUNT to confirm price is below the leg equilibrium when it enters the OTE
Watch the live B x/7 score label near the OTE zone. As price approaches the zone, the score builds in real time
Step 4 — Enter on the PIVOT Signal
A ▲ triangle at the OTE zone confirms all conditions — structure direction, OTE touch, PD zone, HTF bias, sweep (if applicable), rejection candle, and ADX/volume
The SL guide is plotted below the structural swing low (bull) — your structural invalidation level
The TP guide is plotted at the computed reward target based on your configured R multiple
For Setup B signals (Sweep + CHoCH), all three institutional events have converged — this is the highest-conviction PIVOT entry available
Step 5 — Manage and Exit
At the TP guide level, take partial or full profit
If a new CHoCH fires in the opposite direction during the trade, the structure has reversed — this is the exit signal for any remaining position
If price retests the OTE zone again during the same structural leg without triggering a new signal (cooldown active), wait for the cooldown to clear and assess whether the fresh confluence score still meets the minimum
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Identifying Low-Quality Conditions — When Not to Trade
Stand aside when:
Market Struct shows — NEUTRAL — no structural direction is established. Without a confirmed BOS or CHoCH, the leg box and OTE zone have no directional context. Wait for a structural event to occur before looking for OTE entries
HTF Bias opposes structure direction — a bullish current timeframe structure against a bearish HTF is a counter-trend setup. These carry significantly lower success rates. The HTF alignment layer will not score, reducing the confluence count
Price is in the wrong PD zone for the setup direction — a bull entry above the leg equilibrium (premium) or a bear entry below (discount) means entering when price is institutionally expensive relative to the leg's fair value. The PD zone filter blocks these when enabled
Score is at 4/7 and the minimum is 5/7 — the setup is present but not enough layers confirm. Do not force entries when confluence is borderline
Structure events (BOS/CHoCH) are flipping rapidly in both directions — alternating bull and bear structure events in quick succession indicate a choppy market with no clean trend. The OTE zones will be constantly resetting without producing completed pullback sequences
OTE zone is very close to the swing low (bull) or swing high (bear) — when the OTE band and the structural stop reference are nearly at the same price, the risk/reward is poor. The stop would be just below the OTE entry. Reduce position size or pass the setup
The ideal PIVOT setup:
CHoCH event followed by a clean displacement leg with a well-defined leg box
Price retraces into the OTE zone while in discount (bull) or premium (bear)
A qualifying sweep has occurred within the last three bars
HTF Bias aligned with structure direction
Rejection candle forms within the OTE zone
Confluence score at 6/7 or 7/7
ADX confirms trending and volume is expanding
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Key Features
📐 Real-time market structure engine — fractal pivot detection with configurable sensitivity, tracking BOS and CHoCH events with body-close confirmation mode
📦 Structure Leg Box — automatically drawn from the structural origin to the current price extreme, expanding in real time as the leg develops
🎯 Optimal Trade Entry zone — 61.8–78.6% Fibonacci retracement band computed from the structure leg, rendered as a live OTE box and displayed with exact price levels on the dashboard
⚖ Leg Equilibrium line — 50% midpoint of the structure leg acting as the dynamic PD zone divider, plotted continuously and updated as the leg grows
💧 Liquidity sweep detection — identifies stop-hunt events relative to the recent price range with configurable ATR depth and three-bar recency window
🏅 Two setup types — Setup A (OTE Pullback after any BOS/CHoCH) and Setup B (Sweep + CHoCH + OTE — the highest-conviction institutional entry pattern)
🕯 Dual candle confirmation — bullish/bearish rejection candles and engulfing candles both qualify, ensuring the OTE touch produced a genuine institutional reversal response
🧠 7-layer confluence engine — Market Structure, OTE Touch, PD Zone, HTF Bias, Liquidity Sweep, Rejection Candle, and ADX + Volume Expansion all scored independently
📊 Live confluence label near OTE zone — B x/7 · S x/7 displayed in real time on the current bar without requiring dashboard reference
🎯 Structural stop loss — placed beyond the confirmed swing low (bull) or swing high (bear) plus ATR buffer, anchored to the genuine structural invalidation level
💹 Dynamic TP target — computed as `risk × R multiple`, adapting to leg size rather than using a fixed ATR distance
📡 HTF EMA bias filter — strict dual-condition HTF alignment (EMA crossover + price above fast EMA) for maximum higher timeframe conviction
🕐 Session filter — restricts signals to configurable active trading hours
📊 16-row live dashboard — Structure, Filters, Levels, and Confluence sections updated in real time
🔔 6 alert conditions — long/short entry, bull/bear CHoCH, sweep low, sweep high
🎨 Fully cohesive dual-tone color system — yellow-green for all bullish elements, red for all bearish, purple for structural reference levels and OTE zone, orange for sweeps
⚙ Fully configurable — pivot length, structure break mode, OTE Fibonacci levels, sweep depth and lookback, setup types, confluence minimum, HTF timeframe and EMAs, ADX, volume filter, session, SL buffer, TP reward multiple, and all colors are independently adjustable
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ Settings Reference
Structure Engine
Pivot Length (bars each side) — fractal sensitivity. 3 for scalping, 5 for standard intraday (default), 7+ for swing trading
Structure Break: Close Only — when on, requires a candle body close beyond the swing level (default: on). Off = wick touch counts
Show Active Swing Levels — toggle swing high and swing low dashed lines
Show BOS / CHoCH Markers — toggle all structure event triangles
CHoCH Only (hide BOS markers) — when on, only CHoCH events are marked. BOS events still update structure but are not labeled
Structure Leg & OTE
Show Structure Leg Box — toggle the displacement leg dealing range box
Show Leg Equilibrium (50%) — toggle the leg midpoint line
Show OTE Band (62–79%) — toggle the Fibonacci retracement entry zone box
OTE Fib Low — lower Fibonacci level of the OTE band (default: 0.618)
OTE Fib High — upper Fibonacci level of the OTE band (default: 0.786)
Require Premium / Discount — when on, longs require discount positioning, shorts require premium (default: on)
Liquidity Sweep
Enable Sweep Filter — when on, Layer 5 scores the recent sweep and Setup B becomes available
Show Sweep Markers — toggle optional orange circle markers at sweep detection bars
Min Sweep Depth (xATR) — minimum wick extension beyond the reference extreme to qualify as a sweep (default: 0.1)
Sweep Reference Lookback — bars used to define the recent high/low reference for sweep detection (default: 20)
Entries & Confluence
Setup A · OTE Pullback — enable standard OTE pullback entries after BOS or CHoCH
Setup B · Sweep + CHoCH — enable the premium sweep + reversal + OTE setup type
Min Confluence Layers (of 7) — minimum score required for a signal (default: 5)
Show Entry Signals — toggle signal triangles
Show Confluence Label — toggle the live B/S score label near the OTE zone
Signal Cooldown (bars) — minimum bars between consecutive signals (default: 8)
Filters
HTF Trend Filter — toggle the higher timeframe EMA alignment requirement
HTF Timeframe — the higher timeframe for EMA data (default: 60-minute)
HTF Fast / Slow EMA — EMA periods on the HTF (defaults: 21 / 55)
ADX Trend Filter — toggle the ADX strength requirement (default: off)
ADX Length / ADX Minimum — ADX parameters (defaults: 14 / 18)
Volume Expansion Confirm — when on, entry candle volume must exceed the moving average by the minimum multiplier
Min Volume vs Avg — minimum volume ratio for the expansion filter (default: 1.1)
Volume Avg Length — SMA length for the volume baseline (default: 20)
Session Filter — toggle active hours restriction (default: off)
Active Session — configurable session window
Exit Guidance
ATR Length — lookback for ATR calculation (default: 14)
Show SL / TP Guides — toggle stop and target dotted circle plots
SL Buffer Beyond Swing (xATR) — additional ATR buffer beyond the structural swing stop reference (default: 0.25)
TP Reward (R) — take profit distance as a multiple of the risk from entry to stop (default: 2.0)
Display
Show Dashboard — toggle the full dashboard panel
Dashboard Position — Top Left / Top Right / Bottom Left / Bottom Right
Colors
Bull / Bull Bright — yellow-green family for bullish signals, fills, and labels
Bear / Bear Bright — red family for bearish signals, fills, and labels
Sweep / Alert — orange for sweep markers and alerts
Equilibrium / OTE Band — purple for structural reference levels and OTE zone
SL Guide / TP Guide — stop and target circle colors
Bull / Bear Label Text — text color for signal labels
Dash Text / Dash BG / Dash Header / Dash Section / Dash Frame — full dashboard color control
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 Alert Conditions (6 total)
Entry Alerts
Pivot Long Entry — all conditions confirmed for a long OTE setup. Signal label fired
Pivot Short Entry — all conditions confirmed for a short OTE setup
Structure Alerts
Pivot Bull CHoCH — bullish Change of Character detected. Watch for OTE pullback in discount zone
Pivot Bear CHoCH — bearish Change of Character detected. Watch for OTE pullback in premium zone
Sweep Alerts
Pivot Sweep Low — sell-side liquidity swept below recent lows. Potential long setup developing
Pivot Sweep High — buy-side liquidity swept above recent highs. Potential short setup developing
All alert messages are formatted as const strings for clean webhook and notification platform integration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Recommended Settings by Instrument & Timeframe
The default configuration is optimized for XAUUSD on M5–M15 , with general suitability for major forex pairs and crypto on the same timeframes:
Pivot Length at 5 — the classic fractal sensitivity for intraday gold and forex. Balances signal frequency with structural significance
Close Only on — body close structure breaks eliminate the vast majority of wick-based false breaks on gold and volatile instruments
Setup B (Sweep + CHoCH) on — the highest-quality setups on gold involve a sweep before the CHoCH, making this setup type particularly effective on XAUUSD
HTF at 60-minute — the standard intraday reference for M5–M15 trading
ADX filter off by default — the OTE + rejection candle requirements already provide strong quality filtering without needing ADX as an additional gate
For other instruments or timeframes, adjust:
M1–M3 scalping — reduce Pivot Length to 3, increase Cooldown to 5, reduce TP Reward to 1.5, use tight session filter
H1–H4 swing trading — increase Pivot Length to 7–10, set HTF to Daily or Weekly, increase TP Reward to 3.0–4.0, increase SL Buffer to 0.5
Crypto (BTC, ETH) — increase Sweep Depth to 0.2–0.3× ATR for the wider wicks typical of crypto, consider enabling ADX filter at 20
Indices (NAS100, US30) — use Pivot Length 5–7, enable Session Filter to 09:30–16:00, enable ADX filter
More signals — lower Min Confluence to 4, disable PD Zone requirement, enable Setup A only, reduce Cooldown
Ultra-selective entries only — raise Min Confluence to 6 or 7, require Setup B only, enable ADX filter, enable Volume Expansion
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
👥 Who This Is For
🎯 OTE and Fibonacci pullback traders — PIVOT is the definitive quantitative implementation of the Optimal Trade Entry framework. Every component — structure detection, leg computation, Fibonacci zone rendering, and rejection confirmation — is automated and scored
🏦 Smart money concepts and ICT methodology traders — PIVOT encodes the CHoCH → displacement → OTE pullback sequence that forms the core of ICT's entry model. The Sweep + CHoCH setup type specifically captures the stop hunt → reversal → optimal entry sequence
🥇 Gold (XAUUSD) and forex traders — the default settings are calibrated for intraday gold trading, where OTE pullbacks after CHoCH events are among the most consistent institutional patterns available
📊 Traders who want structure-defined risk — the structural stop placement means every trade has a stop at a genuinely meaningful level — the swing that would invalidate the structure thesis — rather than an arbitrary ATR distance
🧠 Systematic traders who want to quantify OTE entries — the 7-layer scoring system removes subjectivity from OTE trading. Every potential entry is scored objectively against the same seven criteria on every bar
📈 Traders who want to enter later at a better price — PIVOT's entire philosophy is about waiting for the pullback. If you consistently enter at breakouts and then watch price retrace before continuing, PIVOT is the solution — it waits for that retracement and enters at the optimal Fibonacci level within it
⚠ Traders who struggle with stop placement — the structural swing reference + ATR buffer produces a stop that makes structural sense. You are not guessing where to put the stop — the market's structure tells you exactly where it belongs
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📝 Notes
All signals are confirmed on bar close — the indicator is non-repainting by design. Pivot detection, structure break logic, OTE zone calculation, and confluence scoring all finalize on confirmed bars only
The pivot detection has an inherent offset of pivotLen bars — a pivot is only confirmed after pivotLen bars have passed on both sides. This is standard behavior for fractal-based pivot systems and is not repainting — it is the mathematical requirement for confirming the fractal pattern
The Structure Leg Box and OTE Zone are redrawn only on the last bar for chart cleanliness. Historical bars retain signal markers and BOS/CHoCH labels but do not show outdated box overlays
The CHoCH window for Setup B (40 bars) means a Sweep + CHoCH setup can fire up to 40 bars after the CHoCH event, as long as the OTE zone is still valid and all other conditions are met. On slower timeframes this window covers a wider clock-time range — adjust if needed
The confluence label near the OTE zone is drawn only on the last bar. It is a real-time awareness tool, not a historical indicator
Maximum 500 labels, 500 lines, and 80 boxes are rendered. On very active charts, the oldest markers may be removed by TradingView's limits
The session filter is off by default — PIVOT's structural approach is timeframe and session-agnostic. Enable the session filter for instruments where specific sessions (London, NY) produce more reliable structure events
The TP guide is computed dynamically as risk × R multiple. On bars where the swing reference and current price are very close (producing near-zero risk), the fallback is ATR × R multiple
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Disclaimer
This indicator is a technical analysis and visualization tool intended for educational and informational purposes only. It does not constitute financial advice or a recommendation to buy or sell any financial instrument. All signals are generated from historical and real-time price data using mathematical calculations — their accuracy or profitability is not guaranteed. Past performance of any signal type does not guarantee future results. Always conduct your own analysis, use proper risk management, and consult a licensed financial advisor before making any trading decisions. The author accepts no responsibility for any losses incurred from the use of this indicator.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built for traders who know that the move has already started — and who want to enter it at the precise price where the institutions who created the move are still adding to their position. Indicador
[ A L P H A X ] CATALYST - Volatility & Regime Prediction EngineAlphaX CATALYST — Volatility Ignition & Regime Prediction Engine: Compression Cycle Detection, Bias Vector Scoring, 6-Stage Regime State Machine & Ignition Probability Gate
AlphaX CATALYST is a professional-grade volatility prediction system built on a fundamentally different philosophy from every other indicator in the AlphaX suite. Where VOID, SURGE, FORTRESS, and ANCHOR all detect setups after price has established a structural context, CATALYST reads the market before the move happens. It does not wait for a breakout to confirm entry — it measures the energy compressing inside the market during quiet periods and predicts the ignition point before the explosion occurs. The core insight is simple but profound: markets breathe in cycles. They compress, coil, and then release energy in directional bursts. CATALYST quantifies every stage of that cycle — from the first signs of volatility contraction through full coil, ignition, trending expansion, and exhaustion — and fires signals only when the compression is deep enough, the directional bias during the coil is strong enough, and the higher timeframe structure confirms the direction. The result is a system that positions you at the moment of ignition — not a bar after the breakout has already occurred. Designed for volatility-aware traders across crypto, forex, gold, and indices on any timeframe.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌬 The Philosophy — Markets Breathe
Every major directional move in every liquid market is preceded by a period of compression. Price range contracts. Volume dries up. Volatility percentile falls toward historic lows. The Bollinger Bands compress inside the Keltner Channels. Narrow range bars form consecutively. This compression is not random — it is the mechanism by which institutional positions are accumulated quietly, without moving price, before the delivery move begins.
Most traders see this compression phase as boring or unreadable and look elsewhere for setups. CATALYST is built on the opposite premise: the compression phase is the most important and readable phase of the entire price cycle . The depth of the compression tells you how much energy is coiling. The directional bias during the compression tells you where that energy is most likely to be released. The higher timeframe alignment tells you whether that release is likely to be with or against the macro institutional flow.
By the time the breakout candle is obvious to everyone, CATALYST has already been tracking the setup for multiple bars — measuring compression depth, monitoring accumulation bias, and computing the ignition probability score in real time. When ignition fires, it fires with advance conviction — not reactive confirmation.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ The 6-Stage Regime State Machine
CATALYST is built around a deterministic 6-stage regime cycle that every market passes through on every timeframe. Understanding the regime is the foundation of using CATALYST correctly — the dashboard, background colors, and regime flip labels all communicate exactly which stage the market is in at every bar.
Stage 0 — QUIET
The market is dormant. No significant compression is building (score below 35). Volatility is neither low nor building toward a setup. This is the baseline state — the market is between cycles. Gray background tint. No actionable context.
Stage 1 — BUILDING
Compression is beginning to develop (score between 35 and 75). One or more compression signals are present — the squeeze may be turning on, narrow range bars may be forming, volume may be beginning to dry. The coil is winding up. Orange background tint intensifies slightly. The bias vector label appears on the current coil box to indicate which direction accumulation is occurring.
Stage 2 — COILED
Maximum compression state (score 75+, full BB/KC squeeze active). The spring is fully wound. Energy is at maximum concentration. This is the highest pre-ignition alert state. Deeper orange background tint. The coil box is rendered with higher opacity. The COILED flip label appears on the chart. Dashboard shows COMPRESS at 75%+ and SQUEEZE ON. This is the state you watch most closely — ignition can occur at any bar from here.
Stage 3 — IGNITION
A single-bar flash state. The regime transitions through IGNITION on the bar where all ignition conditions are simultaneously met — compression deep enough, bias directional enough, expansion candle large enough, ATR expanding. The cyan background tint and IGNITION flip label mark this bar. The IGNITE signal label fires on this bar. This is the entry bar. Immediately transitions to TRENDING on the next bar.
Stage 4 — TRENDING
The expansion phase. Price is in directional delivery. The regime holds TRENDING until one of the exhaustion conditions fires: RSI reaching extreme levels with climax volume, a significant wick rejection candle in the trend direction, a squeeze reforming during the trend (stall), or a reversal candle closing through the 21 EMA. Yellow-green tint during bull expansion, red tint during bear expansion.
Stage 5 — EXHAUSTION
The expansion energy is spent. One of the exhaustion conditions has triggered. Purple diamond markers appear above or below price. This is the early warning that the trend leg is ending — not necessarily the trend itself, but the current momentum leg. After EXHAUSTION, the regime resets: if compression begins building again, it cycles back to BUILDING; if not, it returns to QUIET and the cycle begins again.
Why the state machine matters: Every signal in CATALYST is regime-gated. Ignition signals can only fire from the COILED state. Exhaustion warnings can only fire from the TRENDING state. This ensures signals are always contextually appropriate — you cannot get an ignition signal without prior compression, and you cannot get an exhaustion warning without a prior trend.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📉 The Compression Score Engine — Measuring the Coil
The compression score is a 0–100 composite reading that quantifies exactly how tightly the market is coiling at any given bar. It is the primary input to the regime state machine and is displayed live on the dashboard.
Six compression components and their weights:
Squeeze State (up to 30 points):
The BB/KC squeeze is the most powerful single compression signal. When Bollinger Bands are fully inside Keltner Channels, the market is at maximum volatility contraction — 30 points. If the squeeze fired on the previous bar (just released), 15 points are still awarded, capturing the residual compression energy at the moment of release.
Narrow Range Pattern — NR (up to 20 points):
The current bar's high-low range is measured against the lowest range over the lookback period (default: 7 bars). When the current bar has the narrowest range in the lookback window, 20 points are awarded. This is the NR7 pattern generalized to a configurable lookback — the classic volatility contraction signal.
NR Streak (up to 15 points):
Consecutive narrow range bars amplify the coil energy. When the NR count over the minimum coil duration reaches the threshold, 15 additional points are awarded. Multiple consecutive NR bars indicate the market has been compressing for a sustained period — a deeper, more energetic coil.
Volume Dry-Up (up to 15 points):
Current volume below the configurable fraction of its moving average (default: 65% of the 20-bar SMA) confirms institutional accumulation is occurring quietly — institutions are building positions without creating visible volume signals. 15 points awarded when volume is dry.
Volume Dry Streak (up to 10 points):
Multiple consecutive bars of volume dry-up, identical logic to the NR streak. Sustained low volume over multiple bars is a stronger coil signal than a single dry bar.
ATR Percentile Rank (up to 10 points):
The current ATR is ranked against its own history over the configurable lookback (default: 100 bars). When ATR is in the bottom 25th percentile of its historical range — meaning volatility is at a historic low for this instrument on this timeframe — 10 points are awarded. Below the 40th percentile scores 5 points. This ensures the compression is genuine historically, not just temporarily quiet in an already volatile market.
Reading the score:
0–35 — QUIET, no meaningful compression building
35–55 — BUILDING, compression developing but not yet actionable
55–74 — COILING, significant compression present
75–100 — FULLY COILED, maximum compression, squeeze active. Ignition-ready state
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧭 The Bias Vector — Who Is Accumulating During the Coil?
Compression tells you the market is coiling. The Bias Vector tells you which direction institutions are accumulating during that coil. A range of -100 (fully bearish) to +100 (fully bullish), the bias vector is a composite of five independent directional pressure readings — each measuring accumulation from a different angle.
Volume Delta (up to ±25 points):
The estimated directional volume pressure — bull volume EMA minus bear volume EMA — forms the primary bias input. When delta is positive and rising (buyers accelerating), 25 points are added. When delta is positive but not accelerating, 10 points. The inverse applies for bear delta. This is the most direct measure of whether buyers or sellers are winning the quiet accumulation battle during compression.
Close-Position Bias (up to ±20 points):
Where closes fall within each bar's high-low range, averaged over the lookback period (default: 10 bars). When the average close position is in the upper 55%+ of the range — candles are consistently closing near their highs — buyers are controlling the candle closes. ±20 points based on whether the close bias is bullish (above 0.55) or bearish (below 0.45). This is a subtle but powerful measure of who is controlling the close during the coil.
Micro Structure (up to ±20 points):
Higher highs or higher lows over the structure lookback (default: 20 bars) vote bullish. Lower lows or lower highs vote bearish. ±20 points. Micro structure during compression tells you whether the coil is forming as a higher low (bullish coil) or a lower high (bearish coil) — the internal structure of the compression box reveals directional intent.
HTF Bias (up to ±20 points):
The higher timeframe EMA alignment (default: 60-minute, 50-period EMA). When HTF close is above the HTF EMA — the macro trend is bullish — +20 points. When below, -20 points. When Require HTF Alignment is disabled, this component is neutral. The HTF bias ensures the coil's directional reading is contextualized against the macro institutional flow.
Price vs BB Basis (up to ±15 points):
Whether the current close is above or below the BB basis (Bollinger Band midline). Price above the basis during compression means the coil is forming above fair value — a mild bullish signal. Price below the basis is mildly bearish. ±15 points. This adds a relative positioning dimension to the bias.
Reading the bias vector:
+35 to +100 — bull bias. Buyers are accumulating during the coil. Long ignition is favored
-35 to -100 — bear bias. Sellers are distributing during the coil. Short ignition is favored
-34 to +34 — neutral bias. No clear directional accumulation. Ignition may fire in either direction — lower conviction
Bias Arrow:
During BUILDING and COILED regime stages, a live bias arrow label appears below (bull bias) or above (bear bias) the coil box on the current bar, showing the directional score in real time. As new bars form, the arrow updates continuously — you can watch the bias building or shifting during the coil.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔥 The Ignition Score — 0 to 100 Probability Gate
Every bar in the COILED regime, CATALYST computes two separate ignition scores — one for long ignition, one for short. These scores gate whether a signal fires. Only when the score meets the configured minimum threshold (default: 62) does a signal become eligible.
Long ignition score components:
Compression depth (up to 20 points) — fully coiled scores 20, isCoiling scores 10, moderate compression scores 10
Squeeze state (up to 20 points) — squeeze release scores 20 (maximum — the spring just released), squeeze still active scores 10
Bias vector alignment (up to 25 points) — bias above +50 scores 25, above +35 scores 15, below 0 deducts 15
HTF alignment (up to 15 points) — HTF bullish scores 15, disabled scores 15 (neutral)
Expansion candle quality (up to 15 points) — strong bull body above ATR threshold scores 15, any bullish close scores 8
ATR expansion (up to 5 points) — ATR expanding above its short-term average confirms the coil is releasing
Volume delta confirmation (up to 10 points) — accelerating buy delta scores 10, positive delta scores 5
The short ignition score mirrors this structure with all conditions inverted.
What the score thresholds mean in practice:
90–100 — near-perfect setup. All components aligned. Extremely rare
75–89 — elite setup. Multiple high-weight components confirmed simultaneously
62–74 (default threshold) — high-quality setup. Sufficient confirmation to fire
50–61 — moderate quality. Available if you lower the threshold, but carries more false signals
Below 50 — low-quality ignition conditions. System will not fire at any reasonable threshold setting
The live long and short scores are displayed in real time on the dashboard as IGNITE L and IGNITE S — color-coded yellow-green or red when they meet the threshold, neutral otherwise. You can watch the ignition score building toward threshold in real time during the coil phase.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ The Ignition Signal — IGNITE Entry
The IGNITE label is CATALYST's primary entry signal. It fires when all of the following conditions are simultaneously confirmed on a bar close:
Hard requirements (all must be true):
Regime is in COILED state (compression score 75+, squeeze active)
The expansion candle body meets or exceeds the configured minimum (default: 1.15× ATR) — the breakout candle is large and directional
The bias vector is aligned with the signal direction (+35 or higher for long, -35 or lower for short)
ATR is actively expanding above its short-term average — the volatility expansion has begun
Squeeze has released on this bar or was releasing on the previous bar (when Require Squeeze Release is enabled)
Ignition score meets the minimum threshold (default: 62)
Session filter is satisfied (when enabled)
Signal cooldown has elapsed since the last signal
Signal label: A large IGNITE label appears below the bar (long) or above (short) on the exact ignition bar. Yellow-green for long, red for short.
Why this is fundamentally different from a standard breakout signal: A standard breakout indicator fires when price closes above a resistance level or a band. It reacts to what has already happened. CATALYST fires on the ignition bar only after verifying that the preceding compression was deep enough (COILED regime), that the directional bias during the coil was confirmed (bias vector), that the breakout candle itself is sufficiently large (body ATR check), and that the volatility is genuinely expanding (ATR expansion). Every component addresses a specific failure mode of basic breakout trading — false breakouts, weak breakouts, counter-HTF breakouts, and low-compression breakouts are all filtered before the signal fires.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔮 The Compression Coil Box
When the compression score crosses 55 and the BUILDING regime begins, CATALYST draws a live Coil Box — an orange-tinted rectangle spanning the high-low range of the entire compression period from the first coiling bar to the current bar.
What the coil box represents: The coil box is the visual representation of the spring being wound. Every bar that the coil remains active, the box extends to the right and expands to incorporate the new bar's range. The box's height represents the total price range of the compression period — the tighter this range, the more compressed the energy.
Box opacity: The box becomes more opaque when the compression reaches the fully COILED state (score 75+, squeeze active). This visual intensity progression gives you an immediate sense of compression depth — a faint box means early-stage building, a deep orange box means maximum coil.
Box on ignition: When ignition fires, the box remains on the chart at the coil range, giving you a clear visual reference for the compression zone that preceded the move. The coil box range is also used for structural stop loss placement — the SL Beyond Coil Box Edge setting places the stop loss beyond the coil box boundary rather than a fixed ATR distance from entry.
Box cleanup: When the regime returns to QUIET (compression fully dissipated without ignition), the box is deleted. When ignition occurs, the box is retained as a reference.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Exhaustion Radar — Early Warning System
The Exhaustion Radar monitors the TRENDING regime for signs that the expansion energy is being spent. When exhaustion conditions are met, purple diamond markers appear above (bull trend exhaustion) or below (bear trend exhaustion) the bar — a warning that the current momentum leg is likely approaching its end.
Exhaustion conditions (any one is sufficient):
RSI climax with volume spike — RSI above the overbought threshold (default: 72) in a bull trend with volume exceeding the configured climax multiple (default: 2.2×). This combination of extreme RSI and high volume is the classic climax top pattern — buyers are exhausting their buying capacity simultaneously
RSI climax with volume spike (bear) — RSI below the oversold threshold (default: 28) with climax volume in a bear trend. Sellers exhausting
Wick rejection in trend direction — a bar with a rejection wick exceeding the configured minimum percentage (default: 55%) in the direction of the trend. A bull trend bar with a massive upper wick indicates aggressive selling into the highs — supply overwhelming demand at the extreme
Trend stall squeeze — when a squeeze (BB inside KC) forms during the trending phase while volume is also drying up. This indicates the expansion move has stalled into a new compression without resolution — energy is being absorbed rather than continuing
Reversal candle through 21 EMA — a strong opposing candle that closes through the 21-period EMA in the trend direction. In a bull trend, a strong bearish close through the 21 EMA indicates the trend's immediate momentum structure has been broken
How to use exhaustion signals: Exhaustion diamonds are not reversal signals. They indicate that the current momentum leg is likely complete — not that the trend has ended. Use them to take partial or full profit on trend trades, tighten trailing stops, or wait for the next CATALYST compression cycle to develop before re-entering.
━━━━━━━━━━━━━━━━━════════════════════════
🎯 Coil-Anchored Risk Guidance System
On every IGNITE signal, CATALYST draws forward-projecting risk guidance levels for the duration of the trade.
Stop Loss (SL):
When SL Beyond Coil Box Edge is enabled (default: on), the stop is placed beyond the coil box boundary — below the coil box low (long) or above the coil box high (short) — plus a small ATR buffer. The coil box represents the full compression range: if price returns into and through the opposite side of the coil box after ignition, the breakout has failed and the setup is invalidated. This gives the stop structural meaning beyond just an ATR distance. When the coil SL is less conservative than the fixed ATR SL, the system uses whichever is further from entry to ensure adequate protection.
TP1 — First Target:
2.0× ATR from the entry close (configurable). The initial partial profit target. At TP1, consider scaling out 50% of the position.
TP2 — Extended Target:
4.0× ATR from entry (configurable). The full expansion target for the remaining position — allowing the trailing stop or regime-based exit (exhaustion signal) to manage the remainder.
Level visualization: All three levels are drawn as horizontal dashed or dotted lines extending 12 bars forward from the signal bar, with price labels at the right edge showing exact levels. SL in red, TP1 in dim yellow-green, TP2 in bright yellow-green.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Live Dashboard
The 14-row real-time dashboard displays every internal state of the CATALYST engine on every bar.
REGIME — current stage: QUIET / BUILDING / COILED / IGNITION / TRENDING / EXHAUSTION. Color-coded by regime type
COMPRESS — live compression score 0–100%. Orange when above 50%, deeper orange when above 75%
SQUEEZE — ON (BB inside KC, maximum coil), RELEASE (squeeze just fired — highest-quality ignition condition), or OFF
ATR RANK — current ATR percentile versus its 100-bar history. Orange when below 30th percentile (historically low volatility — coil energy building)
VOL DRY — YES when current volume is below the dry-up threshold, NO otherwise. Orange when YES
BIAS VECTOR — the composite directional accumulation score with + or - sign. Yellow-green above +35, red below -35, neutral otherwise
HTF BIAS — higher timeframe EMA direction: BULL, BEAR, or FLAT
VOL DELTA — BUYERS when bull volume dominates, SELLERS when bear volume dominates
IGNITE L — live long ignition probability score 0–100. Highlights yellow-green when at or above the minimum threshold
IGNITE S — live short ignition probability score 0–100. Highlights red when at or above threshold
COIL BARS — number of bars the current coil has been active. Orange when at or above the minimum coil duration
COIL RANGE — the high-low range of the current coil box in price terms
SESSION — ACTIVE or FILTERED based on the session filter state
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Chart Visual System
Compression Coil Box (orange) — live orange-tinted box spanning the full high-low range of the current compression period. Brightens on full coil. The core visual centerpiece of CATALYST
Regime Background Tints — subtle full-bar background colors for each regime: gray (QUIET), light orange (BUILDING), deeper orange (COILED), cyan (IGNITION), yellow-green or red (TRENDING), purple (EXHAUSTION)
IGNITE Label (below bar, yellow-green) — bull ignition signal. All conditions confirmed
IGNITE Label (above bar, red) — bear ignition signal
◆ Exhaustion Diamond (above bar, purple) — bull trend exhaustion warning
◆ Exhaustion Diamond (below bar, purple) — bear trend exhaustion warning
Bias Vector Arrow Label — appears near the coil box on the current bar during BUILDING and COILED phases, showing ▲ BIAS +xx or ▼ BIAS -xx in real time
Regime Flip Labels — small text labels marking every regime transition: BUILDING, COILED, IGNITION, TRENDING, EXHAUSTION. Color-coded by regime
SL Dashed Line (red) — stop loss guide extending 12 bars from ignition bar
TP1 Dotted Line (dim yellow-green) — first take-profit guide
TP2 Dotted Line (bright yellow-green) — extended take-profit guide
SL / TP1 / TP2 Price Labels — exact price levels labeled at the right end of each guide line
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚀 How to Trade with AlphaX CATALYST — Step by Step
Step 1 — Monitor the Regime
Check the dashboard REGIME row. If it shows QUIET, nothing actionable is developing. If it shows BUILDING, a compression cycle is beginning — start paying attention
Watch COMPRESS build toward 75+. When SQUEEZE shows ON simultaneously, the market is in maximum coil state. This is your highest-alert pre-signal phase
Note the Coil Box forming and narrowing on the chart. The tighter the box, the more energy compressed inside
Step 2 — Assess the Bias During the Coil
Watch the Bias Arrow label near the coil box. Is it showing ▲ BIAS or ▼ BIAS? A strong positive bias (+50 or above) during a tight coil is the strongest possible pre-ignition setup
Check HTF BIAS on the dashboard — does it confirm the bias arrow direction? HTF alignment is worth 15 ignition score points and significantly increases the probability of a clean directional ignition
Watch VOL DELTA — are BUYERS or SELLERS winning the accumulation battle during the quiet phase?
If the Bias Vector is below ±35, the coil does not have strong directional conviction. Lower your size expectations or wait for bias to build
Step 3 — Watch the Ignition Scores Approach Threshold
As the coil deepens, watch IGNITE L and IGNITE S scores on the dashboard climbing toward the minimum threshold. When a score crosses the threshold and highlights, the system is primed — ignition can fire on the next qualifying expansion bar
The squeeze release (SQUEEZE shows RELEASE) is the most important single event in the ignition sequence. When the squeeze releases on a strong expansion candle in the bias direction, ignition fires immediately if the score is sufficient
Step 4 — Enter on the IGNITE Label
The IGNITE label marks the exact ignition bar. Enter on the close of the signal bar or the open of the following bar
The SL is placed beyond the coil box edge — below the coil low (long) or above the coil high (short). This is your structural invalidation: if price re-enters and closes through the opposite side of the coil box, the breakout has failed
TP1 at 2.0× ATR — scale out 50% here. Move the remainder to breakeven
Let TP2 or the first exhaustion diamond manage the remaining position
Step 5 — Exit on Exhaustion or Regime Shift
A purple diamond marks the exhaustion condition. Take profit on the remaining position or tighten the stop aggressively
The dashboard shows EXHAUSTION regime — the trend energy has been identified as spent
If no exhaustion fires and price continues, the system will track the regime as TRENDING — let the move run until exhaustion appears
After EXHAUSTION, the regime resets. Watch for a new compression cycle to build in the updated directional context
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Identifying Low-Quality Conditions — When Not to Trade
Stand aside when:
Regime is QUIET and COMPRESS is below 35 — no cycle is developing. CATALYST has nothing actionable and no signal can fire. Do not force entries
Regime reaches COILED but Bias Vector is below ±35 — the coil is real but the directional accumulation is inconclusive. Ignition in this environment carries reduced directional probability. Reduce size significantly or wait for bias to develop clarity
HTF BIAS opposes the bias vector direction — a bearish HTF while the bias vector is bullish means the coil is building against the macro institutional flow. Counter-HTF ignitions have a significantly lower success rate. Wait for HTF alignment
IGNITE L and IGNITE S scores are both below threshold — the market is compressing but neither a long nor short setup has sufficient confirmation quality. No signal will fire. Wait for the scores to build
Multiple regime cycles in rapid succession without trending — BUILDING → COILED → QUIET → BUILDING cycles that never reach IGNITION indicate a market in deep chop or accumulation. Do not try to anticipate the breakout direction — wait for the cycle to complete cleanly
Session shows FILTERED — the session filter has blocked the current time window. No signals will fire
COIL BARS is below the minimum coil duration — the compression has been too brief to build meaningful energy. A coil of 2 bars has far less stored energy than a coil of 8+ bars. Prioritize setups with longer coil durations
The ideal CATALYST setup:
COMPRESS at 80+, SQUEEZE ON for multiple bars
Bias Vector at +50 or above (long) or -50 or below (short)
HTF BIAS aligned with the bias direction
VOL DELTA confirming the bias direction (BUYERS for long, SELLERS for short)
IGNITE L or S score approaching 75+
COIL BARS at 5 or more — sustained compression
Squeeze RELEASE on the ignition bar — the spring snapping
Strong body expansion candle in the bias direction
When all these conditions align, CATALYST produces its highest-conviction ignition signals — setups where the compression depth, directional accumulation, HTF alignment, volume pressure, and expansion quality are all confirming simultaneously.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Key Features
🌬 6-stage regime state machine — QUIET → BUILDING → COILED → IGNITION → TRENDING → EXHAUSTION. Every bar is classified and every signal is regime-gated
📉 Multi-component compression score — BB/KC squeeze, NR patterns, NR streaks, volume dry-up, volume dry streaks, and ATR percentile rank combined into a single 0–100 score
📦 Live compression coil box — orange-tinted box tracking the full range of the compression period in real time, brightening at maximum coil depth
🧭 5-component bias vector — Volume Delta, Close-Position Bias, Micro Structure, HTF EMA alignment, and BB Basis positioning combined into a -100 to +100 directional accumulation score
⚡ Live bias arrow label — directional score displayed near the coil box on the current bar, updating in real time during BUILDING and COILED phases
🔥 Dual ignition probability scores — separate 0–100 long and short scores computed every bar with a configurable minimum threshold gate
💥 IGNITE signal — fires only from COILED state on the exact bar where compression, bias, expansion candle, and ATR all confirm simultaneously
⚠ Exhaustion radar — RSI climax volume, rejection wick, trend stall squeeze, and reversal candle conditions produce early exhaustion warnings during the TRENDING phase
📡 HTF EMA bias filter — pulls higher timeframe directional structure into both the bias vector and the ignition scoring system
🎯 Coil-anchored SL placement — stop loss placed beyond the compression box structural boundary rather than a fixed ATR distance
🎨 Regime background tints — full-bar background colors for every regime stage, providing constant visual awareness of where the market is in the cycle
🏷 Regime flip labels — small text labels at every regime transition point on the chart history
📊 14-row live dashboard — Regime, Compress, Squeeze, ATR Rank, Vol Dry, Bias Vector, HTF Bias, Vol Delta, Ignition Scores, Coil Bars, Coil Range, Session updated every bar
🔔 5 alert conditions — Ignite Long, Ignite Short, Fully Coiled, Squeeze Release, Exhaustion Warning
⚙ Fully configurable — all ATR/BB/KC parameters, NR lookback, volume dry-up threshold, ATR percentile length, HTF timeframe and EMA, delta and structure lookbacks, ignition threshold, body size filter, exhaustion RSI/volume/wick parameters, SL/TP multiples, session windows, and all colors are independently adjustable
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ Settings Reference
Volatility Engine
ATR Length — ATR calculation lookback used across the engine (default: 14)
BB Length / BB Mult — Bollinger Band parameters for squeeze detection (defaults: 20 / 2.0)
KC Length / KC Mult — Keltner Channel parameters (defaults: 20 / 1.5)
NR Pattern Lookback — bars for narrow range comparison. NR fires when current range is the narrowest in this window (default: 7)
Volume Dry-Up Length — lookback for volume moving average (default: 20)
Max Vol vs Avg (coil) — maximum volume as a fraction of average for the dry-up condition (default: 0.65)
ATR Percentile Lookback — history window for ATR percentile rank (default: 100)
Min Coil Duration (bars) — minimum consecutive bars needed for streak bonuses (default: 3)
Bias Vector
HTF Bias Timeframe — higher timeframe for EMA bias pull (default: 60-minute)
HTF EMA Length — EMA period on the higher timeframe (default: 50)
Require HTF Alignment — when on, HTF opposing direction deducts points from ignition scores
Volume Delta Length — EMA smoothing for volume delta estimation (default: 14)
Close-Position Bias Len — lookback for average close position within bar range (default: 10)
Structure Lookback — bars for micro higher high / lower low detection (default: 20)
Ignition Signals
Min Ignition Score (0–100) — threshold below which no signal fires (default: 62). 58–68 is practical range
Min Ignition Body (xATR) — expansion candle body must exceed this multiple of ATR (default: 1.15)
Require Squeeze Release — when on, ignition must occur on or after BB/KC squeeze releases
Show Ignition BUY/SELL Labels — toggle IGNITE signal labels
Show Exhaustion Warnings — toggle exhaustion diamond markers
Signal Cooldown (bars) — minimum bars between consecutive signals (default: 6)
Exhaustion Radar
RSI Overbought / Oversold — RSI thresholds for climax exhaustion detection (defaults: 72 / 28)
Climax Volume (x avg) — volume multiple above average required for RSI climax condition (default: 2.2)
Min Rejection Wick % — minimum wick as fraction of bar range for wick rejection exhaustion (default: 0.55)
Risk Guidance
Show SL / TP Guides on Signal — toggle level lines and labels
SL Distance (xATR) — ATR-based SL floor distance (default: 1.2)
TP1 Distance (xATR) — first take-profit target distance (default: 2.0)
TP2 Distance (xATR) — extended take-profit target distance (default: 4.0)
SL Beyond Coil Box Edge — places SL at the structural coil boundary rather than fixed ATR only (default: on)
Session Filter
Enable Session Filter — toggle the session restriction
London (08:00–13:00 UTC) — toggle London session inclusion
London/NY Overlap (13:00–17:00 UTC) — toggle the highest-volume overlap session
NY Afternoon (17:00–21:00 UTC) — toggle NY afternoon session
Display
Show Compression Coil Box — toggle the live orange coil box
Regime Background Tint — toggle the full-bar regime background colors
Show Bias Vector Arrow — toggle the live bias label near the coil box
Dashboard Position — Top Right / Top Left / Top Center / Bottom Right / Bottom Left / Bottom Center
Dashboard Size — Normal / Bigger
Theme
Bull Primary / Bright / Dim — yellow-green family for all bullish elements
Bear Primary / Bright / Dim — red family for all bearish elements
Coil / Squeeze — orange for all compression and coil elements
Ignition — cyan for the ignition regime flash
Exhaustion — purple for exhaustion regime and warning diamonds
Neutral — gray for QUIET regime and neutral states
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 Alert Conditions (5 total)
Signal Alerts
CATALYST Ignite Long — all long ignition conditions confirmed. IGNITE label fired below bar
CATALYST Ignite Short — all short ignition conditions confirmed. IGNITE label fired above bar
State Alerts
CATALYST Fully Coiled — regime has entered COILED state (compression 75+, squeeze active). Ignition may be imminent — prepare
CATALYST Squeeze Release — BB has expanded outside KC on this bar. Maximum-quality ignition condition active
CATALYST Exhaustion — exhaustion conditions detected in the TRENDING regime. Trend energy fading
All alert messages are formatted as const strings for clean webhook and notification platform integration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Recommended Settings by Instrument & Timeframe
The default configuration is optimized for XAUUSD, major forex pairs, and crypto on M5–H1 :
Min Ignition Score at 62 — strong quality gate while allowing frequent enough signals on intraday timeframes
HTF at 60-minute — meaningful macro context for M5–M15 trading. The squeeze and ignition on M5 confirmed by H1 EMA alignment is the core multi-timeframe framework
ATR Percentile Lookback at 100 — calibrated for intraday volatility cycles on liquid instruments
NR Lookback at 7 — captures classic NR7 patterns while remaining sensitive enough for fast-moving instruments
For other instruments or timeframes, adjust:
M1–M3 scalping — reduce ATR Percentile Lookback to 50, reduce NR Lookback to 5, reduce Min Ignition Score to 58, shorten Cooldown to 3 bars
H1–H4 swing trading — set HTF to Daily or Weekly, increase ATR Percentile Lookback to 200–250, increase Min Ignition Score to 68–72, increase TP2 to 6.0–8.0× ATR for wider swing targets
Crypto (BTC, ETH) — increase KC Mult to 2.0–2.5 and BB Mult to 2.5 to account for wider natural volatility, increase Climax Volume threshold to 2.8–3.5 for crypto's naturally higher volume spikes
Higher signal frequency — lower Min Ignition Score to 55–58, reduce NR Lookback to 5, reduce Min Coil Duration to 2
Ultra-selective signals only — raise Min Ignition Score to 72–78, require Squeeze Release on, HTF Alignment on, increase Min Coil Duration to 5
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
👥 Who This Is For
💥 Volatility breakout and expansion traders — CATALYST is purpose-built for traders who want to enter at the moment of volatility ignition, not after the move has already extended significantly
⚡ Squeeze traders and NR pattern traders — the compression engine formalizes and quantifies every squeeze and narrow range pattern into a single score, eliminating subjective judgment about whether a coil is "tight enough"
🔮 Anticipatory traders who want to read the market before it moves — the bias vector and ignition score system provides pre-signal intelligence during the coil that no reactive indicator can match
📊 Multi-timeframe traders — the HTF bias integration means every CATALYST signal is contextualized against the higher timeframe institutional flow
🧠 Systematic traders — every component of the compression score, bias vector, and ignition score is quantified and configurable. There is no subjectivity in what constitutes a "good enough" coil
🎯 Risk-conscious traders — the coil-anchored stop loss is structurally meaningful — placed at the exact level that invalidates the breakout thesis
📈 Traders across all asset classes — the ATR normalization and percentile-ranked volatility detection means CATALYST works consistently on gold, forex, crypto, and indices without manual recalibration between instruments
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📝 Notes
All signals are confirmed on bar close — the indicator is non-repainting by design. Regime state, compression score, bias vector, and ignition scores all finalize on confirmed bars
The regime state machine is sequential — IGNITION can only be reached from COILED. This means no signal can fire without prior confirmed compression regardless of how strong the expansion candle is
The ATR percentile rank requires the configured lookback history to be available. On charts with fewer bars than the ATR Percentile Lookback setting, the rank may underperform until sufficient history accumulates. This warm-up effect resolves naturally
The bias arrow label is drawn only on the last bar and refreshes on every tick during live trading. It does not appear on historical bars — only the current bar during BUILDING and COILED regimes
The SL / TP guide lines are redrawn on every new ignition signal. Previous signal levels are deleted when a new signal fires
Maximum 500 labels, 500 lines, and 100 boxes are rendered. The coil box, regime flip labels, and SL/TP levels all count toward these limits. On very active charts with long history, the oldest labels may be removed by TradingView's rendering limits
The session filter uses UTC hours rather than exchange-specific sessions, making it instrument-agnostic across all markets globally
The indicator does not track open positions or P&L — the regime state tracks the expansion direction (bull or bear) from ignition through exhaustion, but does not connect to any broker or account
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Disclaimer
This indicator is a technical analysis and visualization tool intended for educational and informational purposes only. It does not constitute financial advice or a recommendation to buy or sell any financial instrument. All signals are generated from historical and real-time price data using mathematical calculations — their accuracy or profitability is not guaranteed. Past performance of any signal type does not guarantee future results. Always conduct your own analysis, use proper risk management, and consult a licensed financial advisor before making any trading decisions. The author accepts no responsibility for any losses incurred from the use of this indicator.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built for traders who understand that the most powerful moment to enter a market is not when everyone can see the move — it is the bar before, when the coil finally snaps. Indicador
TRX Grid Long Strategy [3Commas]TRX Grid Long Strategy
🔷 What it does:
This is a long-only price-grid strategy that harvests volatility on TRX / USDT through repeated round-trips on a pre-defined ladder of price levels between two fixed bounds. Each level is an independent slot: when price crosses down through a level, the strategy opens one slot; when price subsequently crosses up through the level immediately above, that slot is closed for a fixed round-trip profit. The grid is generated geometrically by default, so spacing adapts to the price scale.
- Up to 35 simultaneous long slots at default settings, each sized as a fixed fraction of the configured Total Investment.
- No trailing exit, no stop loss — each slot's exit is the level above its entry.
- Per-slot exposure is approximately 2.86% of equity at default settings, comfortably inside the conventional 5–10% per-trade risk band.
- Every fill and close emits a webhook-ready JSON alert payload tagged with the specific grid slot.
🔷 Who is it for:
- Swing traders harvesting volatility on TRX in range-bound regimes.
- Bot operators looking for a chart-driven signal source with per-slot webhook JSON ready to drive a DCA Bot configured for grid execution.
- Traders running a portfolio of low-correlation strategies who want a high-trade-count contributor with bounded per-trade risk.
- Range traders who prefer mechanical execution over discretionary entries.
🔷 How does it work:
Grid Construction: On script load, the strategy computes N price levels between the configured High and Low bounds. In Geometric mode (default), level k is at High × (Low/High)^(k/(N-1)), giving constant percent spacing — approximately 1.0% per step at default settings. In Arithmetic mode, levels are linearly spaced by absolute price.
Per-Slot Logic: Each grid level is an independent slot tracked by a boolean ownership flag. When bar close moves price down through an empty slot's level, a long is opened at that level for one slot's worth of capital (Investment / N). When bar close moves price up through the level immediately above an owned slot, that slot is closed, locking the round-trip profit between the two adjacent levels.
No Trailing, No Stop Loss: By design, each slot has a fixed exit (the level above). The strategy never trails the exit and never stops a slot out for a loss — slots whose entry price is below current market simply wait until price comes back. This is the canonical grid-bot behavior.
Capital Bounds: Total deployed capital cannot exceed the configured Investment. When all 35 slots are filled, no new orders are opened until price rises and starts closing slots. This structural cap is the strategy's primary risk control.
🔷 Why it's unique:
- Per-Level Webhook Ledger: Every fill and close emits a fully-formed JSON alert payload tagged with the specific grid slot ("Grid_BUY_L5" / "Grid_TP_L5"). The strategy can drive a DCA Bot configured for grid emulation without any glue layer.
- Pre-Allocated State: All up to 200 slot ledgers live in fixed-size arrays, so state lookups are constant-time and the chart can render every active slot with no performance overhead.
- Honest Backtest Surface: The avg entry line plotted on the chart and the open PnL displayed in the status table both reflect the actual broker-equivalent position state — derived from fill-by-fill bookkeeping, not synthetic averaging. The status table also reports the cumulative realized net profit (how much the grid has actually earned, in USDT and % of starting capital), so live performance is visible directly on the chart.
- Calibrated for TRX 15m: Default bounds, level count, and step size are set against TRX's recent observed range. The 35-level geometric ladder gives roughly 1.0% per step — wide enough to clear taker fees on each round-trip, granular enough to keep catching 15m swings inside the range.
🔷 Considerations Before Using the Strategy:
Market Selection & Range Validity: Grid strategies are most profitable in range-bound, mean-reverting markets. On strong directional trends below the configured Low, slots will keep loading as price falls and won't close until price reverses. The default High/Low (0.3713 / 0.2660) was set against TRX's recent observed range; update both whenever the regime changes.
Capital Deployment & Drawdown: The default Investment of 10,000 USDT equals 100% of starting capital — high-conviction setting that assumes the configured range holds. Per-slot risk is moderate (~2.86% of equity), but if price collapses below the Low bound, aggregate unrealized loss can grow further — the reference backtest reached a 10.95% maximum equity drawdown. Scale the Investment input down to match the worst-case drawdown you are willing to absorb.
No Stop Loss Justification: There is no exit on adverse moves below the lowest grid level. The strategy's per-trade risk is structurally capped by the per-slot allocation (Investment / N levels) — at defaults that is ~286 USDT per slot, inside the conventional 5–10% per-trade band. The aggregate unrealized exposure is controlled separately via the Investment input.
Trade Volume & Fees: Grid bots on 15m generate a high number of round-trips. The ~1.0% step is deliberately wider than a tight scalp grid so each round-trip comfortably clears the taker fee. The default commission (0.06% per trade) should be matched to your exchange's actual fees; with a profit factor of 1.227 the edge is modest, so a fee mismatch matters.
Demo Testing: Always demo-test before going live. Past results do not guarantee future performance, especially on a strategy whose profitability is bounded by the chosen High/Low range remaining valid.
🔷 STRATEGY PROPERTIES
Symbol: BYBIT:TRXUSDT.P (Perpetual) — strategy is portable to any TRX / USDT pair.
Timeframe: 15M
Test Period: May 1, 2025 — June 22, 2026 (~13.7 months).
Initial Capital: 10,000 USDT.
Total Investment: 10,000 USDT (100% of capital, high-conviction setting).
Order Size per Slot: Investment / 35 ≈ 286 USDT (~2.86% of equity).
Commission: 0.06% per trade.
Slippage: 3 ticks.
Margin for Long Positions: 100%.
Indicator Settings: Default Configuration.
Grid Bounds: High 0.3713 / Low 0.2660 (range −28.36%).
Grid Levels: 35 (Geometric spacing, ~1.0% per step).
Stop Loss: None — per-slot allocation is the structural risk cap.
Trailing: None.
Strategy: Long Only.
🔷 STRATEGY RESULTS
⚠️ Remember, past results do not guarantee future performance.
Net Profit: +481.18 USDT (+4.81%)
Max Equity Drawdown: 1,107.89 USDT (10.95%)
Total Closed Trades: 460
Percent Profitable: 46.30% (213 / 460)
Profit Factor: 1.227
🔷 How to Use It:
🔸 Adjust Settings: Open the strategy inputs and set the High and Low bounds to a range you expect TRX to respect. Pick Geometric for percent-spaced levels (default, recommended) or Arithmetic. Set Grid Levels (7–200) and Total Investment to match your risk profile.
🔸 Results Review: Run a full-period backtest and confirm Max Drawdown stays within your personal risk band — note this configuration reached 10.95%. The 460 closed trades are well above the ~100-trade floor for statistical relevance, but the 1.227 profit factor leaves a modest margin once real fees are applied.
🔸 Create alerts to trigger the DCA Bot: Add one alert on the strategy using "Any alert() function call". Paste your DCA Bot's webhook URL into the alert's Webhook field, and fill the Bot ID, Email Token, and Pair inputs on the script. Every grid-level buy and grid-level close will emit a dedicated JSON payload tagged with the slot index, so each level can be tracked independently downstream.
🔷 INDICATOR SETTINGS
High Price: Top of the grid. The highest level a slot can be created from.
Low Price: Bottom of the grid. The lowest level a slot can be created from.
Grid Levels: Number of price levels between High and Low (default 35, range 7–200).
Spacing Mode: Geometric (constant percent step) or Arithmetic (constant absolute step).
Total Investment (USDT): Total capital allocated across all slots. Per-slot size = Investment / Grid Levels.
Bot ID / Email Token / Pair: Webhook fields injected into every alert payload.
Visualization: Toggle grid lines, range box, HIGH/LOW labels, avg entry plot, fill labels, status table (shows range, levels, owned slots, investment, per-slot size, open PnL, and cumulative realized net profit).
Brand Watermark: Configurable text, position, size, and transparency.
👨🏻💻💭 We hope this tool helps enhance your trading. Your feedback is invaluable, so feel free to share any suggestions for improvements or new features you'd like to see implemented.
__
The information and publications within the 3Commas TradingView account are not meant to be and do not constitute financial, investment, trading, or other types of advice or recommendations supplied or endorsed by 3Commas and any of the parties acting on behalf of 3Commas, including its employees, contractors, ambassadors, etc. Estratégia
Power Order Blocks [ChartPrime]🔶 OVERVIEW
Power Order Blocks is an advanced structural detection engine designed to identify high-probability supply and demand zones. Unlike standard order block indicators, this tool focuses on "Power" — the intensity of the displacement following the block's formation, combined with a live information panel, equilibrium mapping, and touch tracking built directly into each zone.
It identifies the specific candle where institutional participants likely placed large orders, marks the resulting price inefficiency, and tracks these zones in real time until they are either mitigated or invalidated.
🔶 CORE CONCEPT — THE DISPLACEMENT VALIDATOR
The foundation of a "Power" Order Block is the displacement that follows it. For a zone to be considered valid, the market must move away from it with significant force.
The script uses a Displacement Multiplier to ensure quality:
• It compares the size of the engulfing candle to the previous candle's range.
• If the breakout candle isn't large enough relative to the setup candle, the zone is ignored.
• This filters out low-conviction market noise and focuses on areas of true institutional sponsorship.
🔶 THE POWER RATING SYSTEM
Every detected block is assigned a "Power" percentage. This rating provides immediate context regarding the strength of the move that created the zone.
• Calculation: The indicator compares the current displacement candle against the largest candle observed over a 100-bar lookback .
• Meaning: A 100% Power rating indicates the strongest displacement seen in recent history, suggesting a massive imbalance between buyers and sellers.
• Visual Intensity: When Power Intensity is enabled, the fill color of each block becomes more vivid as its Power % increases. High-power zones are immediately visible at a glance — weaker zones fade into the background naturally.
This allows traders to prioritize "High Power" zones, which typically offer more significant structural support or resistance.
🔶 DYNAMIC ZONE MANAGEMENT
The indicator manages zones dynamically to keep the chart clean and relevant:
Bullish Order Blocks (Demand): Formed when a bearish candle is followed by a high-displacement bullish candle. The zone is invalidated if price closes below the bottom of the block.
Bearish Order Blocks (Supply): Formed when a bullish candle is followed by a high-displacement bearish candle. The zone is invalidated if price closes above the top of the block.
Overlapping Cleanup: If a new order block forms that significantly overlaps an existing one, the script automatically removes the older, redundant zone to prevent clutter.
Block Limit: A maximum of 10 active blocks per side are tracked at any time, ensuring chart performance remains clean.
🔶 THE INFO PANEL
Each active Order Block renders a dedicated Info Panel — a secondary box that floats at the right edge of the zone and updates in real time.
The panel displays:
• Zone Direction: "Bullish OB" or "Bearish OB"
• Power %: The relative displacement strength at the time of formation
• Touch Counter: How many times price has tapped the zone boundary without breaking it
The touch counter is particularly valuable — a zone that has been tested multiple times without breaking demonstrates strong institutional defense and may represent a higher-conviction setup.
🔶 EQUILIBRIUM LINE
When Show Equilibrium Line is enabled, a line is drawn at the exact midpoint (50% level) of each Order Block.
• This level represents the theoretical "fair value" within the zone.
• Price often reacts precisely at the equilibrium before continuing in the original direction.
• It provides a refined entry reference within a wider zone, improving risk-to-reward on entries.
🔶 RETEST SIGNALS (MITIGATION)
When Show Retest Labels is enabled, the script monitors active zones for price interaction.
• If price returns to touch the boundary of a Bullish OB without breaking it, an upward arrow ⇡ appears below the bar.
• If price returns to touch the boundary of a Bearish OB without breaking it, a downward arrow ⇣ appears above the bar.
• A minimum 10-bar cooldown between signals prevents label spam on extended zone interactions.
• Each confirmed retest also increments the Touch Counter inside the Info Panel.
🔶 VISUAL ELEMENTS
Main OB Body: A filled rectangle spanning the order block's price range, extending forward in time. Fill intensity reflects the Power % when Power Intensity is enabled.
Info Panel: A secondary box at the right edge of each zone displaying Power % and Touch Count, updated live.
Equilibrium Line: A midpoint line inside each block marking the 50% level of the zone.
Retest Arrows: Clean arrow labels (⇡ / ⇣) marking the first tap into an active zone.
Color Coding: Fully customizable colors for Bullish (Demand) and Bearish (Supply) zones.
🔶 HOW TO USE
Entry Zones: Wait for price to return to a high-power zone. The Retest Arrow confirms the touch. Consider entries near the equilibrium line for tighter stops.
Zone Prioritization: Use the Power % to filter setups. Zones rated 70%+ represent the strongest institutional imbalances and are generally more reliable.
Touch Count Context: A zone with 0 touches is fresh and untested — typically the highest probability. Zones with multiple touches may be weakening.
Trend Confirmation: In a healthy trend, the market should consistently create and respect Power Order Blocks in the direction of the trend.
Stop Loss Placement: Order blocks provide logical structural levels for stops — just below a Bullish OB bottom or above a Bearish OB top.
Confluence: Combine the Power Rating, Equilibrium Line, and Touch Count together for the highest-quality setups.
🔶 SETTINGS REFERENCE
Displacement Multiplier: Controls how aggressive the displacement filter is. Higher values require a stronger engulfing move to validate a zone.
Bullish / Bearish OB Color: Set the fill color for each zone type.
Text Color: Controls the color of text inside the Info Panel.
Show Equilibrium Line: Toggles the midpoint line inside each block.
Power Intensity: When enabled, fill transparency scales with Power % — stronger zones appear more vivid.
Show Retest Labels: Toggles the ⇡ / ⇣ arrow labels on zone interactions.
🔶 CONCLUSION
Power Order Blocks provides a systematic way to map institutional footprint on the chart. By combining strict displacement validation with a relative power rating, live info panels, equilibrium mapping, and touch tracking, it transforms raw price action into a clear and actionable map of supply and demand imbalances — allowing traders to trade alongside the strongest market moves with precision and confidence. Indicador
Indicador
Interbank SessionsInterbank Sessions is a precision‑engineered timing tool designed for traders who rely on clean, repeatable intraday structure.
The indicator plots three vertical timelines representing the core global trading sessions:
Asia Session
London Session
New York Session
Built for Forex and cryptocurrencies, Interbank Sessions provides a clear visual framework for understanding liquidity cycles, volatility rotations, and session‑to‑session transitions.
Traders in cash indices and equities can also use it to mark the cash opens of Asia, Europe, and the United States — giving you a unified, global market timing map on any chart.
Every element is fully customizable:
Adjustable session times for any timezone
Custom colors, line styles, and label visibility
Minimalist, non‑intrusive vertical markers
Works on all timeframes and all assets
Interbank Sessions delivers a clean, institutional‑grade view of the market’s temporal rhythm — without clutter, noise, or unnecessary features. Indicador
Indicador
XRS Prop Drawdown Recovery DashboardXRS Prop Drawdown Recovery Dashboard
The XRS Drawdown Recovery Dashboard is a risk management and trade planning tool designed to help traders create a structured recovery plan after experiencing drawdown in a funded account, prop firm account, or personal trading account.
Instead of increasing position size and attempting to recover losses through aggressive trading, this dashboard focuses on preserving remaining drawdown while using asymmetric risk-to-reward ratios, limited trade counts, and disciplined risk management to improve the probability of long-term account survival.
## How It Works
Select:
* Account Size
* Total Drawdown Allowance
* Remaining Drawdown
* Recovery Speed (Conservative, Balanced, or Aggressive)
The dashboard automatically calculates a dynamic recovery plan based on the amount of drawdown remaining.
The recovery engine adjusts:
* Suggested position size
* Risk per trade
* Maximum trades per day
* Stop loss distance
* Take profit distance
* Risk-to-reward ratio
* Daily loss limit
* Recovery targets
* Trading rules based on account condition
As drawdown becomes more severe, the dashboard automatically shifts into more defensive recovery modes and recommends tighter risk controls, fewer trades, and larger reward-to-risk requirements.
## Recovery Philosophy
Most traders fail recovery attempts because they increase risk as drawdown increases.
This dashboard follows the opposite approach:
* Risk decreases as drawdown increases.
* Trade frequency decreases as drawdown increases.
* Required reward-to-risk ratios increase as drawdown increases.
* Capital preservation becomes the primary objective.
The goal is not to recover losses as quickly as possible.
The goal is to recover losses while maximizing account survival.
## Recovery States
### Survival
Designed for accounts with very little drawdown remaining.
Focus:
* Smallest position sizes
* Highest reward-to-risk ratios
* One high-quality trade opportunity
* Strict capital preservation
### Critical
For accounts approaching dangerous drawdown levels.
Focus:
* Reduced trade frequency
* Limited daily exposure
* High-quality A+ setups only
### Defensive
For moderate drawdown situations.
Focus:
* Controlled risk
* Selective entries
* Balanced recovery pace
### Controlled
For healthier account conditions where recovery remains important.
Focus:
* Moderate risk allocation
* Multiple opportunities
* Consistent execution
### Normal
For accounts with substantial drawdown available.
Focus:
* Standard risk management
* Consistent process
* Controlled growth
## Suggested Usage
This tool works best when combined with:
* A proven trading strategy
* Consistent trade execution
* Defined stop losses
* Positive expectancy setups
* Strict adherence to daily loss limits
The dashboard is intended to provide a framework for disciplined decision-making and should not be used as a replacement for a complete trading plan.
## Key Features
✔ Dynamic recovery engine
✔ Position size recommendations
✔ Risk-per-trade calculations
✔ Daily loss limits
✔ Recovery state detection
✔ Maximum trade count suggestions
✔ Recovery speed adjustment
✔ Reward-to-risk optimization
✔ Drawdown management framework
## Educational Disclaimer
This indicator is provided for educational and informational purposes only.
Nothing contained within this indicator, its calculations, suggestions, or displayed recovery plans should be considered financial advice, investment advice, trading advice, or a recommendation to buy or sell any financial instrument.
Trading futures, stocks, options, forex, cryptocurrencies, and other financial products involves substantial risk and may result in significant losses, including the loss of your entire account balance.
Past performance does not guarantee future results.
All trading decisions are made solely at your own discretion and risk. You are responsible for evaluating your own financial situation, risk tolerance, and trading objectives before placing any trade.
The creator of this indicator assumes no responsibility for any trading losses, missed opportunities, or financial damages resulting from the use of this tool.
Indicador
Indicador
Indicador
Indicador
Interactive Ichimoku Box by Tradictorz | Open-Source EditionInteractive Ichimoku Box by Tradictorz | Open-Source Edition
This is the open-source release of Interactive Ichimoku Box by Tradictorz.
The script is designed as a visual Ichimoku-based analysis tool. It combines standard Ichimoku components with interactive projection boxes based on recent high/low ranges. The goal is to help traders visually study price structure, potential range expansion areas, and Tenkan/Kijun relationship directly on the chart.
Main features:
• Ichimoku Tenkan and Kijun lines
• Optional Ichimoku cloud display
• Chikou span display
• Interactive target boxes based on 9-period, 26-period, and 52-period high/low ranges
• Higher and lower projection box options
• Visual Tenkan/Kijun cross indication
• Position label showing current directional bias and price
• Buy/Sell alert conditions based on Tenkan/Kijun crossovers
How it works:
The indicator calculates Ichimoku-style Donchian midpoints for the Conversion Line and Base Line. It then uses recent high/low ranges to draw projected boxes above and below the selected range. These boxes are intended to provide a visual framework for studying possible continuation or expansion zones.
Position label:
The position label displays the current directional state:
• Long: Conversion Line is above Base Line
• Short: Conversion Line is below Base Line
• Range: Conversion Line and Base Line are equal
Alerts:
The script includes alert conditions for:
• Buy Alert: Conversion Line crosses above Base Line
• Sell Alert: Conversion Line crosses below Base Line
Important notes:
This indicator is an analytical and educational tool only. It does not provide financial advice, trade recommendations, or guaranteed buy/sell signals. Historical behavior does not guarantee future results. Always combine this tool with your own analysis, confirmation process, and risk management.
Open-source notice:
This version is published as open source for transparency, educational review, and community feedback. You may inspect the logic, learn from it, and modify it according to TradingView’s open-source rules. If you reuse or publish modified versions of this script, please follow TradingView’s House Rules and credit the original author where required.
License:
This source code is subject to the terms of the Mozilla Public License 2.0.
© parm79 Indicador
Smart Market Dashboard PRO Gap Trader EditionA comprehensive intraday dashboard designed specifically for Borsa Istanbul (BIST) equity traders. This indicator focuses on opening gap analysis, combining volume, delta, and price action to help traders make informed decisions at market open.
Key Features:
Gap Detection & Classification – Automatically identifies and labels opening gaps (Full Gap Up/Down, Partial Gap Up/Down) with configurable minimum gap % threshold
Volume & Delta Analysis – Displays real-time cumulative delta, buy/sell volume ratio, and VWAP deviation
Multi-Timeframe Data – Fetches previous day’s OHLCV data to calculate gap reference levels accurately
Visual Dashboard – A clean on-chart table showing key metrics: gap size, volume trend, delta direction, and gap fill probability
Smart Alerts – Configurable alerts for gap setups, gap fill events, and volume anomalies
How It Works:
Gap levels are calculated using End-of-Day (previous session close) as the reference price
All calculations are based on confirmed bar data (barmerge.lookahead_off) to prevent repainting on historical bars
Recommended Usage:
Timeframe: 1–15 minute charts
Market: BIST stocks (optimized for Turkish market open at 10:00 AM)
Works best during the first 30–60 minutes of the trading session
Disclaimer: This indicator is for educational and informational purposes only. It does not constitute financial advice. Always manage your risk accordingly.
Note: As with all intraday indicators, values may update within the current live bar until it closes Indicador
Delta Volume Profile ProDelta Volume Profile Pro is a volume profile indicator built upon the quadrant structure originally introduced by BigBeluga in the Quadro Volume Profile script. Full credit for the original concept and core logic goes to BigBeluga.
🔍 What it does
This indicator divides the visible price range into four quadrants relative to the current price and distributes volume across price bins, revealing where the most significant buying and selling activity has occurred above and below the market.
Each quadrant displays:
Upper Sell Quad — sell volume concentrated above the current price
Upper Buy Quad — buy volume concentrated above the current price
Lower Buy Quad — buy volume concentrated below the current price
Lower Sell Quad — sell volume concentrated below the current price
A Point of Control (PoC) dashed line marks the price bin with the highest volume in each quadrant.
Four percentage labels at the current price level show how total volume is distributed across all quadrants, allowing traders to quickly assess the balance between buying and selling pressure on both sides of the market.
⚙️ Original additions over BigBeluga's base
1. Proxy Volume Engine — works on any broker
Many brokers and CFD platforms do not provide usable native volume data. This indicator includes an internal map of 80+ symbols to their most liquid equivalents:
Forex pairs → (tick volume, CFD-compatible scale)
Metals (Gold, Silver, Platinum)
Crypto (BTC, ETH, etc.)
Oil, Gas →
Indices & Futures
The proxy is fetched automatically via request.security. You do not need to change any settings when switching between brokers — the indicator detects the symbol and loads the appropriate volume source.
2. Proxy-First Priority
Unlike a simple fallback system, this indicator uses the proxy as the primary volume source for all mapped symbols. This guarantees consistent, real volume data regardless of the broker you are charting on — whether EasyMarkets, FXCM, or any CFD provider. The native volume is only used if the proxy fails or if you explicitly enable "Force Native Volume" in settings.
3. Daily Session Mode
When enabled, the profile anchors to the start of the current daily session and resets automatically at each new day — useful for intraday traders who want to see only today's volume distribution.
4. Daily VWAP Anchor
An optional Volume Weighted Average Price line anchored to the daily session open, calculated using the same proxy volume logic as the profile for accuracy across all brokers.
📐 How to read the indicator
Profile bars (left and right of the vertical axis):
Left side bars = dominant directional volume per price bin
Right side bars = opposing volume per price bin
Deeper color = higher volume concentration at that price level
Longer bars = more activity at that price — key support/resistance zones
The four labels at current price:
SELL% | BUY%
SELL | BUY
──────────────────── ← current price
BUY% | BUY%
BUY | SELL
Upper left (SELL%) — percentage of total volume that was selling above current price
Upper right (BUY%) — percentage of total volume that was buying above current price
Lower left (BUY%) — percentage of total volume that was buying below current price
Lower right (SELL%) — percentage of total volume that was selling below current price
Point of Control (PoC) — dashed line:
Marks the single price level with the highest volume in each quadrant
Strong reference for support and resistance
📊 How to interpret the percentages
Example from chart — USDCAD 15M:
Upper: SELL 2.90% | BUY 3.75%
Lower: BUY 51.79% | SELL 41.57%
Reading:
51.79% of all volume below price was buying → strong buy accumulation below
41.57% of all volume below price was selling → significant sell pressure also present
Only 2.90% + 3.75% above price → very little activity above current price
Interpretation: price is near the top of the range with most activity below
General rules:
Large BUY% below + small SELL% above → bullish bias, buyers in control
Large SELL% above + small BUY% below → bearish bias, sellers in control
Balanced percentages on both sides → price in equilibrium, expect breakout
PoC line in lower quad with high BUY volume → strong support level
PoC line in upper quad with high SELL volume → strong resistance level
⚠️ Important notes
This indicator is a visual analysis tool. It does not generate buy or sell signals.
Past volume distribution does not guarantee future price behavior.
The proxy volume reflects tick volume from the mapped exchange, not actual traded notional value.
On weekends or when markets are closed, volume may be incomplete, affecting the profile.
⚙️ Settings reference
ParameterDefaultDescriptionUse Daily Session ModeOFFON: resets profile each day. OFF: fixed lookbackLookback Period200Bars used when Session Mode is OFFForce Native VolumeOFFON: uses chart's native volume instead of proxyPrice Bins60Number of horizontal price levelsProfile Offset60Distance from last bar (in bars)Upper/Lower QuadsONShow/hide each profile sectionPoCON/OFFShow/hide Point of Control per quadrantShow Daily VWAPONPlots the session VWAP lineBuy ColorGreenProfile buy side colorSell ColorRedProfile sell side colorVWAP ColorWhiteVWAP line color
🙏 Credits
Original quadrant volume profile concept and core structure:
BigBeluga — Quadro Volume Profile
www.tradingview.com
Released under Mozilla Public License 2.0
mozilla.org Indicador
COT-Trader Seasonality - Indexed Geometric PathCOT-Trader Seasonality is a visual research indicator designed to study seasonal tendencies in futures, commodities, indices and other markets.
The script focuses on one specific question:
How has a market typically behaved throughout the calendar year when historical years are compared on a normalized basis?
Instead of averaging raw historical prices, the indicator indexes each historical year to a base value of 100 at the first available trading day of that year. This makes different years comparable across changing price regimes.
This is especially useful for markets such as commodities and futures, where long-term price levels can change significantly over time.
Methodology
The indicator uses an Indexed Geometric Seasonal Path approach:
1. Each historical year is indexed to 100 at its first available trading day.
2. Each following trading day is converted into a relative factor versus that year’s starting value.
3. For each calendar day, the geometric mean of the indexed historical factors is calculated.
4. The resulting seasonal curves are plotted on a synthetic January-to-December seasonal scale.
The geometric approach is used because price development is multiplicative. A 10% gain followed by a 10% loss does not return a market to its original level. Working with relative factors is therefore more appropriate than directly averaging absolute historical prices.
Displayed Curves
The indicator can display:
• 10Y Main Seasonal Curve
• 5Y Seasonal Curve
• 15Y Seasonal Curve
• 20Y Seasonal Curve
• Current Year / YTD indexed path
• Previous Year indexed path
• Synthetic seasonal month scale
The 10Y curve is the main reference curve. The 5Y, 15Y and 20Y curves are included as comparison views to help evaluate whether shorter-term seasonal tendencies differ from longer-term historical behavior.
The current year line stops at the latest available data point. It is not extended into the future.
How to Use
This indicator can be used to:
• compare the current year against historical seasonal tendencies
• identify periods where several seasonal curves move in a similar direction
• compare shorter-term and longer-term seasonal behavior
• study whether the current year is behaving normally or as an outlier
• support broader market research together with positioning, fundamentals, volatility and risk analysis
The month labels shown in the indicator are a synthetic seasonal month scale. They are not the same as the chart’s real time axis.
What This Indicator Does Not Do
This script does not generate buy or sell signals.
It does not predict future prices.
It does not automatically identify the best seasonal trading window.
It does not include stop-loss, take-profit, position sizing or strategy backtesting logic.
It is intended as a visual research tool, not as a standalone trading system.
Limitations
Seasonality describes historical tendencies, not certainties. Markets can deviate significantly from historical seasonal patterns due to macroeconomic conditions, weather, supply-demand shocks, positioning, volatility, futures contract rolls or other market-specific factors.
For futures and continuous contracts, historical data quality and roll methodology can influence the visual result.
The indicator should be used as one part of a broader analytical process.
Initial public release.
Features:
• Indexed geometric seasonal path calculation
• Fixed 10Y main seasonal curve
• 5Y, 15Y and 20Y comparison curves
• Current year / YTD indexed path
• Previous year indexed path
• Synthetic January-to-December seasonal month scale
• Built-in legend and methodology table
This indicator is designed for visual seasonal research and does not generate trading signals. Indicador
Volume Drift Profile [JOAT]Volume Drift Profile
Introduction
Volume Drift Profile is an open-source trend detection indicator that derives directional bias from rolling pivot averages rather than fixed moving averages, and visualizes volume directly on the drift lines themselves as a histogram. The volume histogram coloring adapts to three modes — delta (buy-sell pressure gradient), trend (directional mono-color), and spike-highlighted — making the volume context immediately readable without a separate volume panel.
Most trend indicators separate the price trend line from the volume analysis. The trend line tells you the direction; you look at a separate volume bar panel to interpret whether that direction is supported. Volume Drift Profile overlaps both by rendering volume bars along the drift lines themselves, so the relationship between trend level and volume support is visually immediate.
Core Concepts
1. Pivot Drift Line Calculation
The upper drift line is the rolling average of the most recent N confirmed pivot highs. The lower drift line is the rolling average of the most recent N confirmed pivot lows. This produces smoothed, structurally-anchored reference levels that adapt as new pivots confirm, rather than a fixed-period moving average that treats all bars equally.
if not na(ph)
phArr.push(ph)
if phArr.size() > avgCount : phArr.shift()
upperDrift := phArr.avg()
Trend flips when price crosses above the upper drift (bull) or below the lower drift (bear).
2. Volume Normalization
Volume is normalized by its 200-bar standard deviation, capped at 4. This z-score-like measure produces a 0-4 scale where 4 represents an extreme volume spike. The step height of each volume bar on the drift line is proportional to this normalized value, so spike bars visually dominate the histogram.
3. Three Volume Coloring Modes
Delta mode computes a buy ratio from (close - low) / (high - low) and maps it through color.from_gradient() between the bear and bull theme colors. Bars with higher closes relative to their range appear in bull color; lower closes in bear color. Volume intensity is further modulated by the normalized volume level.
Trend mode uses a single directional color with intensity modulated by normalized volume.
Spike mode uses trend color normally but switches to a dedicated spike color for bars where normalized volume reaches the extreme level.
4. Absorption Detection
An absorption bar is identified when volume exceeds twice the 20-bar average (high institutional participation) while the body-to-range ratio is below 30% (price closes near where it opened). This pattern suggests large volume without directional price movement — potential institutional accumulation or distribution.
5. Volume-Weighted Momentum
A running Volume-Weighted Momentum reading tracks cumulative signed volume weighted by price change, normalized to a readable scale. This reading reflects directional institutional bias — rising VWM during an uptrend suggests genuine buying pressure supports the move.
Features
Pivot drift lines: Upper and lower drift from rolling average of last N confirmed pivot highs and lows
Volume histogram on drift lines: Volume bars rendered along the active drift line, sized by normalized volume
Three volume coloring modes: Delta (buy-sell gradient), Trend (directional mono), Spikes (trend + spike highlights)
Gradient fill between drift and price: Translucent fill between the active drift line and current price
Candle volume coloring: Optional bar coloring by volume intensity and trend direction simultaneously
Spike detection and highlighting: Bars with extreme normalized volume shown in dedicated spike color
Absorption detection: High-volume, small-body bars marked as potential institutional absorption events
Volume-Weighted Momentum display: VWM reading normalized and displayed in dashboard
Trend flip labels: Clean text labels at trend reversal points with direction indicator
Non-repainting: Pivot detection uses standard confirmed pivot functions with symmetric lookback
Dashboard: 8-row table with trend direction, volume mode, volume intensity, absorption state, spike state, bars in trend, and VWM
Input Parameters
Drift Structure:
Pivot Lookback: Bars required on each side for pivot confirmation (default: 8)
Pivot Avg Count: Number of pivots to average for drift line (default: 3)
Volume:
Volume Color Mode: Delta / Trend / Spikes
Histogram Height: Scale of volume bars on drift line (default: 0.3)
Show Volume Histogram toggle
Color Price Bars toggle
Show Drift Fill toggle
Spike Color
Absorption:
Show Absorption Dots toggle
Absorption Volume Multiple (default: 2.0)
Max Body Ratio for absorption detection (default: 0.3)
How to Use This Indicator
Step 1: Read the Drift Line Direction
The active drift line (lower drift in uptrend, upper drift in downtrend) is the primary trend reference. When price is above the lower drift, the trend is bullish. When price crosses the upper drift downward, the trend flips bearish.
Step 2: Interpret Volume Histogram Color
In Delta mode, teal/bull-colored bars represent buying pressure dominating that bar; bear-colored bars represent selling pressure. When large volume bars appear in the trend direction, it confirms the drift.
Step 3: Monitor Absorption Events
Absorption dots mark bars where institutional participants may be accumulating. Large absorption bars at drift line levels are particularly significant — they suggest the drift level is actively defended.
Step 4: Use VWM as Direction Confirmer
Rising VWM during an uptrend means volume-weighted momentum supports price movement. Flat or declining VWM during an uptrend flags weak participation — a potential warning of trend exhaustion.
Indicator Limitations
Drift lines require at least N confirmed pivots to begin rendering. In early bars of a new chart, the lines will be absent
The volume histogram renders along the drift line. In periods of very high drift line slope, the histogram may visually overlap the price range
Absorption detection uses volume relative to a 20-bar average. In low-liquidity environments, the threshold may trigger on routine trading activity
The pivot lookback introduces a lag between when a pivot forms and when the drift line updates
Originality Statement
Rendering a volume histogram directly along pivot drift lines — rather than in a separate panel — as a real-time visualization that integrates trend level and volume support in a single overlay is an original approach
Three independently selectable volume coloring modes driven by a normalized volume z-score, combined with buy-ratio gradient coloring in delta mode, is not replicated in existing open-source pivot drift indicator publications
Disclaimer
This indicator is provided for educational and informational purposes only. It is not financial advice. Trading involves substantial risk of loss. The author accepts no responsibility for trading losses resulting from use of this indicator.
Made with passion by jackofalltrades
Indicador
IFVG Sniper Entry Engine [trade_w_samet]🎯 IFVG Sniper Entry Engine
IFVG Sniper Entry Engine is a clean, focused, and structured Inversion Fair Value Gap analysis indicator designed to help traders study filtered IFVG conditions directly on the price chart.
This script focuses on one main concept:
IFVG-based entry visualization.
It is not designed to be a complex all-in-one trading system.
It is not designed to show every possible Fair Value Gap.
It is not designed to generate constant chart noise.
Instead, the goal of IFVG Sniper Entry Engine is to detect filtered Inversion Fair Value Gap events, display clean IFVG+ / IFVG- labels, and visualize a simple active trade projection using one entry level, one stop-loss level, and one take-profit level.
The indicator includes:
• Inversion Fair Value Gap detection
• Filtered IFVG selection
• Bullish IFVG+ and bearish IFVG- chart labels
• Thin blue bullish IFVG lines
• Thin red bearish IFVG lines
• Adjustable IFVG label size
• ATR-based stop-loss projection
• Selectable take-profit RR from 1R to 6R
• Active TP / SL visual box
• One-active-trade-at-a-time logic
• Confirmed-candle IFVG processing
• IFVG invalidation handling
• Simple dashboard
• Professional alert conditions
The purpose of this script is to help users visually study where an FVG has inverted and whether that inversion may create a structured review point on the chart.
It should be treated as a chart-analysis and educational decision-support tool.
It is not financial advice.
It is not an automated trading system.
It does not guarantee profitable trades.
It does not execute broker orders.
It does not replace personal analysis, risk management, or trade validation.
━━━━━━━━━━━━━━━━━━━━━━
📌 OVERVIEW
━━━━━━━━━━━━━━━━━━━━━━
At a high level, IFVG Sniper Entry Engine does the following:
• Detects bullish and bearish Fair Value Gaps.
• Stores valid hidden FVG zones in memory.
• Watches for price to invert those zones.
• Confirms bullish IFVG when a bearish FVG is broken upward.
• Confirms bearish IFVG when a bullish FVG is broken downward.
• Applies an optional IFVG quality filter.
• Draws only filtered IFVGs on the chart.
• Displays IFVG+ for bullish IFVG events.
• Displays IFVG- for bearish IFVG events.
• Projects one active entry, stop-loss, and take-profit box.
• Allows only one active trade projection at a time.
• Removes the active TP/SL box after TP or SL is reached.
• Tracks basic visual trade outcome statistics in the dashboard.
• Provides alert conditions for IFVG entries and IFVG formations.
The script is intentionally built to be simple and focused.
It does not include multiple take-profit levels.
It does not include machine-learning optimization.
It does not include hidden performance promises.
It does not attempt to predict the future.
It provides a structured way to visualize filtered IFVG events and their projected trade model.
━━━━━━━━━━━━━━━━━━━━━━
🧠 CORE IDEA
━━━━━━━━━━━━━━━━━━━━━━
The core idea behind IFVG Sniper Entry Engine is based on Inversion Fair Value Gaps.
A Fair Value Gap represents an imbalance area created when price moves aggressively enough to leave a gap-like inefficiency between candles.
An Inversion Fair Value Gap occurs when price later breaks through a previously formed FVG in the opposite direction.
This can be useful for traders who study:
• market imbalance
• failed displacement zones
• price repricing behavior
• continuation after inversion
• possible shift in directional pressure
• clean chart-based trade planning
The script does not treat every FVG as important.
Instead, it stores FVGs and waits for inversion behavior.
Then it filters the IFVG event using quality conditions such as gap size, candle body strength, candle range, and clean break logic.
The goal is not to show more signals.
The goal is to reduce noise and highlight cleaner IFVG conditions.
━━━━━━━━━━━━━━━━━━━━━━
🧩 WHY THIS SCRIPT IS NOT A SIMPLE BUY/SELL INDICATOR
━━━━━━━━━━━━━━━━━━━━━━
IFVG Sniper Entry Engine is not intended to be used as a blind buy/sell system.
The script is structured as a visual review workflow:
Fair Value Gap forms
→ FVG is stored in memory
→ price later breaks through the opposite side
→ inversion is detected
→ IFVG quality filter is checked
→ IFVG+ or IFVG- is displayed
→ active entry / SL / TP projection is drawn
→ trade box extends while active
→ result is tracked visually
→ box is removed after TP or SL
Each part has a specific purpose.
The FVG memory system stores imbalance zones.
The inversion logic checks whether price has broken the opposite side of the stored zone.
The filter system attempts to reduce weaker IFVG events.
The entry model gives a simple visual planning level.
The ATR stop-loss model creates a consistent risk reference.
The RR setting controls the projected target distance.
The dashboard summarizes the current state.
The alert system helps monitor confirmed events.
This makes the script a structured IFVG review tool, not a guaranteed trade signal generator.
━━━━━━━━━━━━━━━━━━━━━━
⚙️ HOW THE SCRIPT WORKS
━━━━━━━━━━━━━━━━━━━━━━
The script first detects normal bullish and bearish Fair Value Gaps.
A bullish FVG is detected when the current candle structure leaves an imbalance above the candle from two bars earlier.
A bearish FVG is detected when the current candle structure leaves an imbalance below the candle from two bars earlier.
Once a raw FVG is detected, the script stores:
• top of the FVG
• bottom of the FVG
• original FVG direction
• age of the FVG
• gap size relative to ATR
• candle body ratio
• candle range relative to ATR
These values are stored internally and are later used when an inversion happens.
The script then waits for price to break through the stored FVG in the opposite direction.
For a bullish IFVG:
A previously bearish FVG must be broken upward.
For a bearish IFVG:
A previously bullish FVG must be broken downward.
When inversion is detected, the script checks whether the IFVG passes the selected filter mode.
Only filtered IFVGs are displayed on the chart.
━━━━━━━━━━━━━━━━━━━━━━
🔵 BULLISH IFVG+ LOGIC
━━━━━━━━━━━━━━━━━━━━━━
A bullish IFVG+ appears when a previously bearish Fair Value Gap is inverted to the upside.
In practical terms, the script looks for a stored bearish FVG and then checks whether price closes above the top boundary of that FVG.
If the selected filter conditions are satisfied, the script draws:
• a thin blue IFVG line
• an IFVG+ label
• a bullish active trade projection if no trade is already active
The bullish trade projection uses:
• entry level
• ATR-based stop-loss below entry
• selected RR-based take-profit above entry
This does not mean price must continue upward.
It only means the script detected a bullish IFVG condition based on its internal rules.
━━━━━━━━━━━━━━━━━━━━━━
🔴 BEARISH IFVG- LOGIC
━━━━━━━━━━━━━━━━━━━━━━
A bearish IFVG- appears when a previously bullish Fair Value Gap is inverted to the downside.
In practical terms, the script looks for a stored bullish FVG and then checks whether price closes below the bottom boundary of that FVG.
If the selected filter conditions are satisfied, the script draws:
• a thin red IFVG line
• an IFVG- label
• a bearish active trade projection if no trade is already active
The bearish trade projection uses:
• entry level
• ATR-based stop-loss above entry
• selected RR-based take-profit below entry
This does not mean price must continue downward.
It only means the script detected a bearish IFVG condition based on its internal rules.
━━━━━━━━━━━━━━━━━━━━━━
💎 IFVG FILTER SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
The script includes an IFVG filter system to reduce chart noise.
This is important because not every inversion is meaningful.
The filter system can be set to:
Off
Loose
Balanced
Strict
Custom
Off mode shows all detected IFVG events.
Loose mode allows more IFVGs and uses lower quality requirements.
Balanced mode is the default middle-ground setting.
Strict mode requires stronger IFVG conditions and will show fewer signals.
Custom mode allows the user to manually control the filter thresholds.
The filter evaluates:
• minimum gap size relative to ATR
• minimum candle body ratio
• minimum candle range relative to ATR
• clean break buffer relative to ATR
This creates a more selective IFVG workflow.
The filter does not guarantee better future outcomes.
It only controls how strict the script is before displaying an IFVG.
━━━━━━━━━━━━━━━━━━━━━━
📏 GAP / ATR FILTER
━━━━━━━━━━━━━━━━━━━━━━
The gap filter measures the original Fair Value Gap size relative to ATR.
This helps avoid very small imbalance zones that may not be meaningful on the selected chart.
A larger minimum gap requirement makes the indicator more selective.
A smaller minimum gap requirement allows more IFVGs.
The default Balanced setting uses a moderate gap requirement.
Users can adjust this in Custom mode.
━━━━━━━━━━━━━━━━━━━━━━
🕯️ BODY RATIO FILTER
━━━━━━━━━━━━━━━━━━━━━━
The body ratio filter measures the candle body compared to the full candle range.
This helps evaluate whether the candle that created the FVG had meaningful directional pressure.
A stronger body ratio requirement can reduce weaker candles.
A lower body ratio requirement allows more setups.
This is not a prediction tool.
It is only a candle-quality filter.
━━━━━━━━━━━━━━━━━━━━━━
📊 RANGE / ATR FILTER
━━━━━━━━━━━━━━━━━━━━━━
The range filter measures the candle’s full range relative to ATR.
This helps the script avoid very small candles that may not represent meaningful displacement.
A higher range/ATR requirement makes the script more selective.
A lower range/ATR requirement increases the number of visible IFVGs.
The value should be adjusted based on symbol volatility and timeframe.
━━━━━━━━━━━━━━━━━━━━━━
🧼 CLEAN BREAK FILTER
━━━━━━━━━━━━━━━━━━━━━━
The clean break filter requires price to break beyond the IFVG boundary by an ATR-based buffer.
This helps avoid very small boundary touches.
For bullish IFVGs, price must close above the stored FVG top plus the clean break buffer.
For bearish IFVGs, price must close below the stored FVG bottom minus the clean break buffer.
The clean break buffer can be controlled in Custom mode.
A higher buffer makes the inversion requirement stricter.
A lower buffer allows more IFVG events.
━━━━━━━━━━━━━━━━━━━━━━
🎯 ENTRY MODEL
━━━━━━━━━━━━━━━━━━━━━━
When a filtered IFVG appears and no active trade is already open, the script creates a visual trade projection.
The entry can be based on:
IFVG Line
Confirmation Close
IFVG Line mode uses the selected IFVG line price as the projected entry reference.
Confirmation Close mode uses the candle close that confirmed the IFVG.
The entry is only a visual reference.
It is not a broker order.
It does not mean the user must enter a trade.
It is designed to help users review how the IFVG setup would look with a structured risk/reward model.
━━━━━━━━━━━━━━━━━━━━━━
🛑 ATR STOP-LOSS MODEL
━━━━━━━━━━━━━━━━━━━━━━
The stop-loss projection is based on ATR.
The main settings are:
ATR Length
SL ATR Multiplier
For bullish IFVG entries, the stop-loss is projected below the entry.
For bearish IFVG entries, the stop-loss is projected above the entry.
ATR is used because market volatility changes across symbols and timeframes.
A higher SL ATR multiplier creates a wider visual risk area.
A lower SL ATR multiplier creates a tighter visual risk area.
This stop-loss level is a visual projection only.
It does not place an order.
It does not guarantee that the level is appropriate for every trader or every market.
━━━━━━━━━━━━━━━━━━━━━━
🎯 TAKE-PROFIT RR MODEL
━━━━━━━━━━━━━━━━━━━━━━
The script uses one take-profit level.
There are no TP1, TP2, or TP3 levels.
The take-profit is calculated from the projected risk distance.
Available RR options:
1R
2R
3R
4R
5R
6R
Default:
3R
For bullish IFVG entries, TP is projected above entry.
For bearish IFVG entries, TP is projected below entry.
The RR setting only controls the visual projected target distance.
It should not be interpreted as a recommendation or guarantee.
Users should decide whether the projected target makes sense based on their own analysis, market structure, liquidity, session, volatility, and risk plan.
━━━━━━━━━━━━━━━━━━━━━━
📦 ACTIVE TP / SL BOX SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
When a new valid IFVG entry appears, the script draws a clean active TP / SL visual model.
The visual model includes:
• TP box
• SL box
• entry line
• stop-loss line
• take-profit line
• ENTRY label
• SL label
• TP label
The TP/SL box remains visible only while the trade projection is active.
While the trade is active, the box extends to the right as new candles form.
When TP or SL is reached, the active trade box is removed from the chart.
This means historical TP/SL boxes are not kept.
The chart remains cleaner and only the active trade projection is visible.
━━━━━━━━━━━━━━━━━━━━━━
🚦 ONE ACTIVE TRADE AT A TIME
━━━━━━━━━━━━━━━━━━━━━━
The script includes one-active-trade-at-a-time logic.
If a trade projection is active, the script will not open another trade projection until the active one reaches TP or SL.
However, new filtered IFVG lines can still appear on the chart.
This design separates:
• IFVG detection
• trade projection permission
An IFVG can appear while a trade is active, but it will not create a new active TP/SL box.
The dashboard tracks blocked IFVG events internally.
This helps keep the chart structured and avoids multiple overlapping trade boxes.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ SAME-CANDLE TP / SL HANDLING
━━━━━━━━━━━━━━━━━━━━━━
If TP and SL are both touched on the same candle, the true intrabar sequence cannot be known from standard OHLC chart data.
This script uses a conservative assumption:
SL is counted first.
This avoids overly optimistic historical visual results when the actual intrabar order is unknown.
Users should understand that this is still a bar-based assumption.
It does not represent broker execution.
It does not include spread, slippage, commissions, order delay, or partial fills.
━━━━━━━━━━━━━━━━━━━━━━
🏷️ IFVG LABELS
━━━━━━━━━━━━━━━━━━━━━━
The script uses simple IFVG labels:
IFVG+
IFVG-
IFVG+ represents a bullish Inversion Fair Value Gap.
IFVG- represents a bearish Inversion Fair Value Gap.
The label size can be adjusted from the settings.
Available label sizes:
Tiny
Small
Normal
Large
Huge
The default label size is Large.
This allows users to adjust visibility depending on chart zoom, monitor size, and visual preference.
━━━━━━━━━━━━━━━━━━━━━━
📍 IFVG LINE PRICE MODES
━━━━━━━━━━━━━━━━━━━━━━
The IFVG line can be drawn using different price references.
Available modes:
Broken Boundary
Confirmation Close
Midpoint
Broken Boundary mode draws the line at the boundary that was broken during inversion.
Confirmation Close mode draws the line at the candle close that confirmed the IFVG.
Midpoint mode draws the line at the midpoint of the original FVG zone.
Each mode gives a different way to visualize the IFVG reference level.
There is no universally best option.
Users should choose the line mode that best matches their own review method.
━━━━━━━━━━━━━━━━━━━━━━
🧹 IFVG INVALIDATION
━━━━━━━━━━━━━━━━━━━━━━
The script can automatically remove invalidated IFVG lines.
For bullish IFVGs, invalidation occurs when price closes back below the lower boundary of the IFVG zone.
For bearish IFVGs, invalidation occurs when price closes back above the upper boundary of the IFVG zone.
This helps keep the chart cleaner by removing IFVG levels that are no longer valid according to the script’s internal logic.
Users can disable this setting if they prefer to keep IFVG lines visible.
━━━━━━━━━━━━━━━━━━━━━━
📟 DASHBOARD
━━━━━━━━━━━━━━━━━━━━━━
The script includes a compact dashboard.
The dashboard displays:
• selected filter mode
• selected label size
• last signal direction
• active trade status
• selected RR
• latest entry level
• latest SL level
• latest TP level
• active box state
• filtered IFVG count
• trades / wins / losses
The dashboard is designed to provide a quick summary of the current script state.
It is not a full performance report.
It is not a replacement for TradingView Strategy Tester.
It is a visual summary based on the script’s internal bar-based projection logic.
━━━━━━━━━━━━━━━━━━━━━━
🚨 ALERT SYSTEM
━━━━━━━━━━━━━━━━━━━━━━
IFVG Sniper Entry Engine includes alert conditions for:
Bullish IFVG Entry
Bearish IFVG Entry
Bullish IFVG+ formed
Bearish IFVG- formed
The entry alerts are triggered when a filtered IFVG creates a new active trade projection.
The IFVG formation alerts are triggered when filtered IFVG+ or IFVG- conditions appear.
Alerts are monitoring tools only.
They do not execute trades.
They do not place broker orders.
Users must confirm all alerts with their own analysis and risk management.
━━━━━━━━━━━━━━━━━━━━━━
🔔 HOW TO USE ALERTS
━━━━━━━━━━━━━━━━━━━━━━
A practical alert workflow:
1. Add IFVG Sniper Entry Engine to your chart.
2. Open TradingView’s alert window.
3. Select the indicator as the alert condition.
4. Choose the desired alert type.
5. Select alert frequency according to your preference.
6. Use alerts for monitoring only.
7. Confirm each alert manually before making any trading decision.
Alerts may behave differently depending on timeframe, symbol, session, and real-time candle updates.
━━━━━━━━━━━━━━━━━━━━━━
🧪 HOW TO USE THE INDICATOR
━━━━━━━━━━━━━━━━━━━━━━
A practical workflow:
1. Add IFVG Sniper Entry Engine to your chart.
2. Start with the default Balanced filter mode.
3. Review the visible IFVG+ and IFVG- labels.
4. Check whether the IFVG appears in a meaningful market context.
5. Review the active TP/SL projection if a trade model appears.
6. Use the selected RR level as a visual planning reference only.
7. Avoid treating every IFVG as a trade.
8. Combine the tool with your own market structure, liquidity, trend, session, and risk-management rules.
9. Use alerts for monitoring, not automatic execution.
10. Test the indicator on the exact markets and timeframes you personally study.
The indicator is best used as a structured IFVG review tool.
It should not be used as a blind execution system.
━━━━━━━━━━━━━━━━━━━━━━
⚙️ SETTINGS REFERENCE
━━━━━━━━━━━━━━━━━━━━━━
⚙️ IFVG Engine
Hidden FVG Memory
Controls how many raw FVGs can be stored internally.
Max Hidden FVG Age
Controls how long a hidden FVG remains eligible for inversion.
Minimum FVG Size / Ticks
Sets the minimum raw FVG size using ticks.
Max Visible IFVG
Controls how many IFVG lines and labels can remain visible.
IFVG Line Length Bars
Controls how far the IFVG line extends to the right.
IFVG Line Price
Controls whether the IFVG line is drawn from Broken Boundary, Confirmation Close, or Midpoint.
Delete Invalidated IFVG
Removes IFVG lines when the script detects invalidation.
━━━━━━━━━━━━━━━━━━━━━━
💎 IFVG Filter
IFVG Filter Mode
Controls how selective the IFVG display logic is.
Available modes:
Off
Loose
Balanced
Strict
Custom
Custom Minimum Gap / ATR
Defines the minimum FVG gap size relative to ATR when Custom mode is selected.
Custom Minimum Body Ratio
Defines the minimum body-to-range ratio when Custom mode is selected.
Custom Minimum Range / ATR
Defines the minimum candle range relative to ATR when Custom mode is selected.
Custom Clean Break Buffer / ATR
Defines the ATR-based clean break buffer when Custom mode is selected.
━━━━━━━━━━━━━━━━━━━━━━
🎯 IFVG Entry Model
Entry Price
Controls whether entry is based on IFVG Line or Confirmation Close.
ATR Length
Defines the ATR length used for risk calculation.
SL ATR Multiplier
Controls the distance of the projected stop-loss.
Take Profit RR
Controls the projected take-profit distance.
Available RR values:
1R
2R
3R
4R
5R
6R
Initial TP / SL Box Length
Controls the initial box length when a new active trade projection appears.
━━━━━━━━━━━━━━━━━━━━━━
🎨 Visual Style
Bullish IFVG Blue
Controls the color of bullish IFVG+ lines and labels.
Bearish IFVG Red
Controls the color of bearish IFVG- lines and labels.
IFVG Label Size
Controls the size of IFVG+ and IFVG- labels.
Entry Line Color
Controls the entry line color.
SL Color
Controls the stop-loss box and line color.
TP Color
Controls the take-profit box and line color.
Dashboard Background
Controls the dashboard background color.
Dashboard Text
Controls the dashboard text color.
━━━━━━━━━━━━━━━━━━━━━━
📟 Dashboard
Show Dashboard
Shows or hides the compact dashboard.
━━━━━━━━━━━━━━━━━━━━━━
🧠 WHAT MAKES THIS SCRIPT ORIGINAL
━━━━━━━━━━━━━━━━━━━━━━
IFVG Sniper Entry Engine uses familiar market concepts such as:
• Fair Value Gaps
• Inversion Fair Value Gaps
• ATR-based risk projection
• risk/reward planning
• label-based visual mapping
• active trade visualization
• alert monitoring
These concepts are not unique by themselves.
The originality of this script lies in how they are organized into a clean IFVG workflow:
Raw FVG detection
→ hidden FVG memory
→ inversion confirmation
→ IFVG quality filter
→ IFVG+ / IFVG- display
→ one-active-trade rule
→ ATR stop-loss projection
→ selectable RR target
→ active-only TP/SL box
→ compact dashboard
→ alerts
This structure is designed to give users a focused way to review filtered IFVG conditions without unnecessary chart clutter.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ IMPORTANT PRACTICAL NOTES
━━━━━━━━━━━━━━━━━━━━━━
The script’s behavior depends heavily on settings.
Signal frequency and visual output may change based on:
• filter mode
• ATR length
• SL multiplier
• RR selection
• IFVG line mode
• minimum gap settings
• candle body settings
• range/ATR settings
• clean break buffer
• timeframe
• symbol volatility
• market session
• available historical bars
A setting that looks clean on one symbol may behave differently on another.
A setting that appears useful on one timeframe may not be useful on another.
Users should test the script on the exact markets and timeframes they personally study.
━━━━━━━━━━━━━━━━━━━━━━
⚠️ LIMITATIONS AND SHORTCOMINGS
━━━━━━━━━━━━━━━━━━━━━━
This script has important limitations:
It does not guarantee profitable trades.
It does not predict future price movement.
It does not replace risk management.
It does not execute trades.
It does not place broker orders.
It does not include broker slippage.
It does not include commissions.
It does not include spreads.
It does not include order delay.
It does not include partial fills.
It uses bar-based chart data.
Same-candle TP/SL order cannot be known from standard OHLC data.
The dashboard is not TradingView Strategy Tester.
The TP/SL boxes are visual projections only.
Alerts are monitoring tools only.
Historical visual behavior does not ensure future behavior.
Filter settings do not guarantee better results.
One-active-trade logic is a visual management rule, not broker execution logic.
For these reasons, IFVG Sniper Entry Engine should be used as an educational decision-support and chart-analysis tool, not as a standalone trading strategy.
━━━━━━━━━━━━━━━━━━━━━━
👤 WHO THIS SCRIPT MAY BE USEFUL FOR
━━━━━━━━━━━━━━━━━━━━━━
This script may be useful for traders who:
• study IFVG concepts
• study Fair Value Gap inversions
• want cleaner IFVG chart visuals
• prefer filtered signals instead of every raw IFVG
• want a simple one-TP projection model
• want ATR-based risk visualization
• want one active trade projection at a time
• want active-only TP/SL boxes
• want IFVG+ and IFVG- labels
• want alert-based monitoring
• want a focused educational analysis tool
It may be less suitable for users who:
• want guaranteed buy/sell signals
• want a fully automated trading bot
• want many take-profit levels
• want every raw FVG displayed
• expect one setting to work on every market
• expect alerts to execute trades
• expect visual projections to match broker execution
• want an indicator that replaces personal decision-making
━━━━━━━━━━━━━━━━━━━━━━
🧭 BEST PRACTICE SUGGESTIONS
━━━━━━━━━━━━━━━━━━━━━━
For cleaner review:
• Start with the default Balanced filter mode.
• Use Strict mode if the chart is too noisy.
• Use Loose mode if the chart shows too few IFVGs.
• Use Custom mode only after understanding how each filter affects signal frequency.
• Review IFVGs together with market structure.
• Check whether the IFVG appears near meaningful liquidity or displacement context.
• Do not treat every IFVG+ or IFVG- as a trade.
• Use the TP/SL box as a visual planning tool only.
• Keep expectations realistic.
• Use alerts for monitoring, not automatic execution.
• Always apply independent analysis and risk management.
━━━━━━━━━━━━━━━━━━━━━━
🔓 PUBLICATION NOTE
━━━━━━━━━━━━━━━━━━━━━━
IFVG Sniper Entry Engine is published as an educational and visual market-analysis tool.
The purpose of this description is to explain:
• what the script does
• how IFVG conditions are detected
• how IFVG filters work
• how IFVG+ and IFVG- labels are created
• how the entry model is projected
• how the ATR stop-loss model works
• how the RR-based take-profit is calculated
• how the active TP/SL box behaves
• how the one-active-trade rule works
• what the dashboard shows
• what the alerts do
• what the limitations are
• how the indicator should and should not be used
The script is designed to support structured analysis.
It does not promise profitable results.
It does not remove market risk.
It does not execute trades.
It should not be used as a blind buy/sell system.
It is best used as a visual framework for reviewing filtered Inversion Fair Value Gap conditions and projected risk/reward behavior.
━━━━━━━━━━━━━━━━━━━━━━
🛡️ DISCLAIMER
━━━━━━━━━━━━━━━━━━━━━━
IFVG Sniper Entry Engine is provided for educational and informational purposes only.
It does not constitute financial, investment, or trading advice.
No indicator can guarantee future results.
Markets are uncertain, conditions change, and historical behavior does not ensure future performance.
Every user is responsible for their own analysis, validation, risk management, position sizing, and trading decisions.
The IFVG+ labels, IFVG- labels, active TP/SL boxes, dashboard values, RR projections, stop-loss projections, and alerts are visual analysis tools only.
Use this script as a structured decision-support and visual review framework, not as a promise of profitability.
Indicador
[ A L P H A X ] FORTRESS - Supply & Demand Zone EngineAlphaX FORTRESS — Supply & Demand Zone Engine with Zone Grading, Session VWAP Confluence, Liquidity Sweep Signals, HTF Zone Overlay & Live Backtest Statistics
AlphaX FORTRESS is a professional-grade supply and demand system built around an institutional zone detection engine that identifies, grades, and tracks every significant supply and demand zone on the chart — then fires precision entry signals only when price returns to those zones with genuine rejection confirmation, multi-layer filter alignment, and a qualifying zone grade. Where most supply and demand indicators simply draw boxes and leave the trader to decide what to do, FORTRESS integrates a five-factor zone grading algorithm (A+ through C), session VWAP confluence scoring, higher timeframe zone overlay, liquidity sweep detection, a full suite of entry quality filters, and a live on-chart backtest statistics tracker that counts wins, losses, and win rate in real time directly from the chart's history. Every signal is supported by zone grade verification, trend alignment, ADX confirmation, volume delta pressure, premium/discount positioning, and rejection wick quality — producing a complete, self-contained supply and demand trading system. Designed for active traders across crypto, forex, gold, and indices on any timeframe.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏛 Supply & Demand — The Institutional Framework
Supply and demand zones are the foundational building blocks of institutional price delivery. Unlike horizontal support and resistance drawn from price memory, genuine supply and demand zones are identified from the origin of explosive moves — the exact price range where institutions accumulated or distributed their positions before driving price aggressively in one direction.
Demand Zone: Formed when price makes an explosive bullish move away from a base. The base — one or more low-momentum candles directly preceding the explosive candle — represents the range where institutional buyers accumulated their full position. When price returns to this zone, unfilled buy orders are waiting. The most reliable demand zone retests produce sharp, rejection-candle bounces from within the zone.
Supply Zone: The mirror image. An explosive bearish move preceded by a base of low-momentum candles. Institutions distributed their position in the base before driving price aggressively lower. On return, unfilled sell orders produce sharp rejection moves downward from within the zone.
Why FORTRESS detects zones differently from most indicators: Most zone detectors use a simple pivot or pattern check. FORTRESS requires three simultaneous conditions for a zone to qualify — the departure candle must be explosive (ATR-scaled range), the body must represent a minimum proportion of the total range (body quality filter), and volume must confirm when enabled. Only zones formed by genuine institutional displacement are registered.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔬 Zone Detection Engine — Quality Filters
Every zone formed by FORTRESS passes three mandatory quality gates before being registered:
Explosive Move Filter:
The departure candle (the candle that leaves the base and drives price) must have a total range exceeding the ATR by a configurable multiplier (default: 1.2×). This filters out zones formed by slow, grinding moves — only impulsive, institutionally driven departures qualify. Smaller ATR multipliers produce more zones; larger values produce fewer, higher-quality zones.
Body Quality Filter:
The departure candle's body must represent at least a configurable percentage of its total range (default: 55%). A small body in a large-range candle indicates indecision — the candle moved far but closed near its midpoint, suggesting weak directional conviction. A large body relative to range confirms genuine one-directional pressure on the departure move.
Volume Confirmation (optional):
When enabled, the departure candle's volume must exceed the average volume (configurable period, default: 20 bars) by a minimum multiplier (default: 1.1×). High-volume departures carry more institutional weight than same-range moves on average volume. The volume filter is off by default — this allows the system to work effectively on instruments where volume data is unreliable (forex spot, crypto perpetuals) while providing an additional quality gate when reliable volume is available.
Base Detection:
The base candles immediately preceding the explosive departure are automatically detected — up to the configurable maximum (default: 2 candles). Base candles must have a body smaller than 0.5× ATR and must not themselves be explosive. The full base range is incorporated into the zone boundaries, accurately reflecting the complete accumulation or distribution range rather than just the departure candle alone.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏅 Zone Grading System — A+ Through C
Not all supply and demand zones are equal. A zone formed on massive volume with VWAP confluence during a premium price area carries fundamentally more institutional weight than the same pattern on average volume in a random price area. FORTRESS quantifies this difference with a five-factor algorithmic grading system that assigns every zone a grade of A+, A, B, or C at the moment of formation.
Grading factors and their weights:
Move Strength (up to 30 points) — the ratio of the departure candle's range to ATR, capped at 30 points. Stronger, more explosive departures score higher. A 3× ATR departure scores maximum; a 1.2× departure (the minimum threshold) scores proportionally lower
Volume Ratio (up to 20 points) — when volume confirmation is enabled, the ratio of departure volume to average volume, capped at 20 points. When volume confirmation is off, a flat 10 points is awarded to maintain grade comparability across instruments. High-volume departures receive the full bonus
VWAP Confluence (20 points) — full 20 points awarded when the session VWAP is within a configurable ATR tolerance of the zone boundaries at the time of formation. A zone that forms directly at the institutional session reference level carries significantly more weight than a zone formed far from VWAP. This is the VWAP Boosts Grade feature
HTF Zone Match (20 points) — full 20 points when the zone overlaps with an active higher timeframe supply or demand zone. Confluence between the current timeframe zone and the HTF zone indicates institutional activity at multiple timeframe levels simultaneously — the strongest possible zone quality condition
PD Zone Match (15 points) — awarded when the zone forms in the institutionally correct price area: supply zones in premium (above dealing range equilibrium) and demand zones in discount (below equilibrium). A supply zone in premium and a demand zone in discount are positioned where institutions naturally distribute and accumulate respectively
Base bonus (5 points) — a flat quality bonus applied to all qualifying zones
Grade thresholds:
A+ (80+ points) — elite institutional zone. All or most factors aligned. Maximum conviction
A (65–79 points) — strong zone with multiple confirming factors. High quality
B (50–64 points) — solid zone with partial confirmation. Standard quality
C (below 50 points) — low-quality zone. Formed with minimal supporting factors
The grade badge is displayed directly on the zone box on the chart. The minimum grade filter (default: B) blocks signals from C-grade zones entirely — preventing entries at the lowest-quality institutional levels.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌐 Session VWAP Confluence
The session VWAP is plotted as a continuous purple line and serves two distinct roles in FORTRESS.
Visual reference: The VWAP line and optional ±1σ bands provide the institutional session fair value reference directly on the price chart. Optional band display shows the first standard deviation envelope around VWAP.
Grade booster: When VWAP Boosts Grade is enabled (default: on), every zone that forms within ATR tolerance of the session VWAP receives 20 additional grade points — frequently elevating a B-grade zone to A or A+ when VWAP proximity confirms institutional positioning at that level.
Why VWAP at the zone matters: The session VWAP is the single most widely watched intraday reference level by institutional desks, algorithms, and market makers. When a supply or demand zone forms directly at the VWAP, it means the institutional activity that created the zone coincided with the session's fairest price level — the most contested and significant price in the session. Retests of these zones carry the highest probability of generating a sharp institutional response.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📡 HTF Zone Overlay
FORTRESS pulls supply and demand zones from a configurable higher timeframe (default: 60-minute) and overlays them on the current chart as purple dashed boxes.
What HTF zones represent: A supply or demand zone on H1 was created by a significantly larger impulsive move than anything visible on M5 or M1. These zones represent institutional positioning decisions made on a multi-hour timeframe — they carry far more weight than same-pattern zones on the current timeframe. When a current timeframe demand zone overlaps with an active H1 demand zone, two independent timeframes of institutional evidence are concentrated at the same price level.
Zone matching in the grader: When a newly formed current timeframe zone overlaps with an active HTF zone of the same type, it receives the full 20-point HTF Match bonus in the grading system — frequently pushing the zone from B to A or A+ grade. The label also appends ·HTF to confirm the match.
HTF zone lifecycle: HTF zones are maintained in real time. When price closes above an HTF supply zone or below an HTF demand zone, the zone is deleted automatically — mitigated zones are no longer relevant and are removed to keep the chart clean.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
💧 Liquidity Sweep Signal Mode
In addition to standard zone rejection signals, FORTRESS detects a powerful second entry type: the liquidity sweep — where price wicks through a zone's boundary to grab stop orders before reclaiming back inside.
Demand sweep (bull): Price wicks below the demand zone bottom by at least the minimum sweep depth (default: 0.15× ATR), then closes back above the zone bottom. Retail stops placed just below the demand zone have been triggered — institutions used that liquidity to accumulate. The reclaim close is the entry signal.
Supply sweep (bear): Price wicks above the supply zone top by at least the minimum sweep depth, then closes back below the zone top. Buy stops above supply have been triggered; the close back below is the entry.
Why sweeps are powerful: A standard zone rejection is a clean, textbook entry. A zone sweep adds an additional dimension — institutions have actively manufactured a liquidity event at the zone boundary, triggered counterparty stops to fill their own orders, and then reversed. This sequence is a clear signature of institutional stop hunting followed by directional commitment. Sweep signals are marked with an orange circle rather than a triangle to distinguish them visually from standard rejections.
Stop placement for sweeps: The SL for sweep entries is placed at the wick extreme (the sweep low for bull sweeps, the sweep high for bear sweeps) plus a small ATR buffer — anchored to the actual manipulation point rather than the zone boundary.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧠 Signal Entry Logic — Multi-Layer Filtering
A FORTRESS signal fires when a zone touch is detected with candle rejection and all configured filters pass. The full filter stack applied to every potential entry:
Zone touch verification:
The current bar's low must reach within the demand zone (for longs) or the current bar's high must reach within the supply zone (for shorts). Touch detection includes a small ATR tolerance (0.05×) to account for minor overshoot or spread differences.
Rejection candle confirmation:
The bar must close in the correct direction — bullish close (close above open) for demand entries, bearish close for supply entries. Additionally, the rejection wick must meet the minimum wick percentage requirement (default: 50% of bar range). A bar touching a zone with a tiny lower wick but a large body is a weak rejection — the minimum wick filter ensures the zone produced a genuine, visible rejection impulse.
Filter stack (all must pass):
Trend EMA — price must be above the trend EMA (default: 50-period) for demand longs, below for supply shorts. Prevents counter-trend entries
ADX minimum — market must be trending above the configured ADX threshold (default: 18). Blocks zone entries in choppy, ranging conditions
Volume Delta — estimated directional volume pressure must agree with the signal direction. Bull volume dominance for longs, bear for shorts
PD Zone requirement — price must be in discount for demand entries (below dealing range equilibrium) and in premium for supply entries (above equilibrium)
Zone grade minimum — only zones at or above the configured minimum grade (default: B) can trigger signals
Fresh zone filter — when enabled, only zones that have not been previously tested can trigger signals. A zone that has already been retested once carries less institutional fresh-order weight
One signal per zone — when enabled, each zone can only generate one signal regardless of how many valid touches occur. Prevents repeated entries at the same level
Signal cooldown — minimum bars between any two signals (default: 5). Prevents signal clustering during complex multi-touch zone reactions
Session filter — when enabled, restricts all signals to the configured active hours window
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Zone Mitigation & Lifecycle Management
FORTRESS tracks the full lifecycle of every zone from formation through mitigation. The mitigation mode is configurable:
Body Close (default): A zone is mitigated when price closes beyond its boundary — a close above a supply zone top or a close below a demand zone bottom. This is the stricter, lower-noise mode. Wicks through the zone do not count as mitigation unless they are accompanied by a body close — consistent with the idea that a wick through the zone is a sweep (an opportunity) rather than a genuine break.
Wick Touch: A zone is mitigated as soon as any price touches the boundary — high above supply top, low below demand bottom. This is a more aggressive mitigation mode that removes zones faster, keeping the chart cleaner but potentially removing zones that could have produced more entries.
When a zone is mitigated under either mode, its box, label, and grade badge are immediately deleted from the chart. The system maintains a rolling maximum of the configured number of active zones per side (default: 3), automatically removing the oldest zones when the limit is exceeded.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Live Backtest Statistics Tracker
One of FORTRESS's most distinctive features is its on-chart live backtest statistics system . Every signal fired is tracked in memory with its entry price, ATR at signal time, direction, and grade. On every subsequent bar, the tracker evaluates whether each open signal has hit the configured target (default: 2.0× ATR) or stop (default: 1.0× ATR).
Statistics tracked and displayed on the dashboard:
Total Signals — the total count of signals logged in the tracking window
Wins — signals that reached the target before the stop
Losses — signals that hit the stop before the target
Win Rate — wins as a percentage of all closed (decided) signals. Color-coded yellow-green when at or above 50%, red when below
Pending — signals still open — neither target nor stop hit yet. Shown in orange
What this tells you: The win rate displayed is not a theoretical backtest result — it is computed directly from the current chart's historical signals using the exact filter configuration currently active. Change the zone grade minimum and the win rate updates. Enable the ADX filter and it updates. This gives you immediate, live feedback on how your configuration is performing on the current instrument and timeframe without leaving the chart.
Important note on interpretation: The statistics reflect signals fired at the current settings on the current chart's visible history. They are not forward-tested results and do not account for slippage, spread, or live execution. They serve as a real-time tuning tool — not a performance guarantee.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Live Dashboard
The real-time dashboard displays the complete internal state across four sections.
ZONES
Supply — count of currently active, unmitigated supply zones on the chart
Demand — count of currently active, unmitigated demand zones on the chart
FILTERS
Trend — current EMA trend state: ▲ BULL, ▼ BEAR, or —
PD Zone — current premium/discount position: ◧ DISCOUNT, ◧ PREMIUM, or — EQ
ADX — live ADX value with ✓ or ✗ pass/fail indicator
Vol Delta — current volume delta direction: ▲ BULL, ▼ BEAR, or —
STATS
Signals — total signals tracked in the current window
Wins — confirmed target-hit signals
Losses — confirmed stop-hit signals
Win Rate — live win percentage across all closed signals, color-coded
Pending — signals awaiting outcome
Min Grade — the currently configured minimum zone grade filter
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Chart Visual System
Demand Zone Boxes (yellow-green) — semi-transparent yellow-green filled boxes with solid yellow-green borders. Extend right until mitigated
Supply Zone Boxes (red) — semi-transparent red filled boxes with solid red borders. Extend right until mitigated
DEMAND / SUPPLY Labels — appear at zone formation with ·VWAP and ·HTF suffixes when those confluences are present
Grade Badges (A+ / A / B / C) — small labels at the zone's left edge showing the computed quality grade. Color-coded: A+ bright yellow-green, A yellow-green, B orange, C gray
HTF Zone Boxes (purple dashed) — higher timeframe supply and demand zones overlaid from the configured HTF. Automatically deleted when mitigated
Session VWAP Line (purple) — continuous VWAP anchored to each session's first bar
VWAP Bands (purple, optional) — ±1σ envelope around the session VWAP
Equilibrium Line (purple dotted) — the 50% midpoint of the dealing range
Trend EMA (optional gray line) — the trend filter EMA plotted when Show EMA is enabled
▲ Triangle (below bar, yellow-green) — standard demand rejection long signal
▼ Triangle (above bar, red) — standard supply rejection short signal
● Circle (below bar, orange) — liquidity sweep long signal at demand zone
● Circle (above bar, orange) — liquidity sweep short signal at supply zone
SL Guide (red dotted circles) — stop loss reference level on signal bars
TP Guide (yellow-green dotted circles) — take profit reference level on signal bars
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚀 How to Trade with AlphaX FORTRESS — Step by Step
Step 1 — Assess the Zone Landscape
Check the dashboard: how many supply and demand zones are active? Multiple demand zones stacked in the same price area indicate a strong institutional accumulation cluster — a high-priority retest target
Identify the highest-grade zones on the chart. An A+ demand zone with ·VWAP ·HTF in the label is the highest-conviction level FORTRESS can display. Mark these as priority levels
Note the equilibrium line — are you in discount (favorable for longs) or premium (favorable for shorts)?
Step 2 — Confirm the Filter Environment
Check the dashboard: Trend ▲ BULL, PD Zone ◧ DISCOUNT, ADX ✓, Vol Delta ▲ BULL — all four green simultaneously is the ideal filter state for long entries
If any critical filter is failing, reduce position size on signals or skip the setup entirely
Watch the VWAP line — is it near the zone you are watching? VWAP proximity at the zone level confirms the highest-grade setups
Step 3 — Enter on the Signal
A ▲ triangle below the bar is a confirmed demand rejection — all quality and filter conditions met. Enter on the close or next bar open
An orange ● circle below the bar is a sweep long — the zone was violated, stops triggered, and price reclaimed. Enter on the close. Place the stop at the wick extreme
Both signal types display SL and TP guide levels (dotted circles) when Show SL / TP on Signal is enabled
Step 4 — Monitor with the Stats Dashboard
Watch the Win Rate row on the dashboard. If the current configuration is producing a win rate below 50% on this instrument and timeframe, consider tightening the filters — raise the minimum grade, increase the ADX threshold, or enable the volume filter
The Pending count tells you how many trades are currently open and unresolved — useful for position sizing decisions
If Losses are rising without corresponding Wins, check whether the market has entered a choppy regime (ADX dropping) and consider pausing trading until ADX recovers
Step 5 — Zone Management and Exit
When price reaches the TP guide level, take partial or full profit
If price closes through the zone boundary opposite to your entry (body close mitigation), the zone is invalidated — this is also your stop signal if not already stopped out
Watch for the zone to be deleted from the chart — when the box disappears, the zone has been mitigated and the trade thesis is over
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Identifying Low-Quality Conditions — When Not to Trade
Stand aside when:
ADX ✗ on the dashboard — the market is ranging. Supply and demand zones in range conditions are frequently tested and broken repeatedly without producing clean continuation moves. The ADX filter blocks signals in these conditions automatically
All active zones are grade C — no high-quality institutional levels are present. The zones on the chart were formed by weak, low-displacement moves and are unlikely to produce sharp institutional responses on retest
Win Rate is below 40% on the live stats tracker — the current configuration is underperforming on this instrument and timeframe. Tighten filters or review whether the instrument is suitable for zone-based trading at this time
Zones are being mitigated rapidly before retesting — fast, impulsive markets break through zones without retesting them. In this environment, wait for a new zone to form in the direction of the impulse rather than trying to catch retests of quickly broken levels
PD Zone shows — EQ — price is at the dealing range midpoint. Entries from equilibrium carry the worst risk/reward — the institutional advantage of buying in deep discount or selling in deep premium is absent
Vol Delta opposes the signal direction — institutional volume pressure is working against the zone entry. Even if all other conditions pass, a demand zone long with bearish volume delta means selling pressure is still dominant — the zone may not hold
No HTF zones visible and current timeframe zones are grading mostly B and C — the institutional context on the higher timeframe is not confirming the current timeframe levels. Wait for HTF supply or demand to align before entering aggressively
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Key Features
🏛 Institutional supply and demand zone detection — explosive move filter, body quality filter, and optional volume confirmation identify only genuine displacement zones
📦 Automatic base detection — incorporates up to the configured maximum of low-momentum candles preceding the explosive departure into the zone boundaries
🏅 Five-factor algorithmic zone grading — Move Strength, Volume Ratio, VWAP Confluence, HTF Match, and PD Zone together produce an A+/A/B/C grade for every zone at formation
🌐 Session VWAP integration — plotted live with optional bands, boosts zone grades when VWAP is within tolerance of the zone, and confirmed in zone labels
📡 Higher timeframe zone overlay — pulls supply and demand zones from a configurable HTF and overlays them as purple dashed boxes. HTF-matching zones receive maximum grade bonus
💧 Liquidity sweep detection — identifies stop-hunt sequences where price wicks through a zone boundary and reclaims, marking these with distinct orange circle signals
🧠 Multi-layer filter stack — Trend EMA, ADX, Volume Delta, PD Zone, Zone Grade, Fresh Zone, One-Shot, Cooldown, and Session filters all independently configurable
⚖ Premium/Discount zone requirement — enforces institutionally correct entry positioning using a dynamic equilibrium across the dealing range
📊 Live backtest statistics tracker — tracks every signal's win/loss outcome in real time on the chart, displaying signal count, wins, losses, win rate, and pending count on the dashboard
🔀 Two zone mitigation modes — Body Close (stricter, lower noise) and Wick Touch (more aggressive zone clearance)
📝 Zone labels with confluence indicators — DEMAND / SUPPLY labels append ·VWAP and ·HTF when those confluences are present at formation
🏷 Grade badges — A+/A/B/C badges displayed directly on each zone box with color-coded visual hierarchy
🎯 SL and TP guide levels — dotted circle plots at the stop and target levels on every signal bar
📊 16-row live dashboard — Zones, Filters, and Stats sections updated in real time
🔔 6 alert conditions — demand long, supply short, sweep long, sweep short, new demand zone formation, new supply zone formation
🎨 Fully cohesive dual-tone color system — yellow-green for all demand/bullish elements, red for supply/bearish, orange for sweeps and pending stats, purple for VWAP/HTF/equilibrium
⚙ Fully configurable — all zone detection thresholds, grading weights, filter settings, mitigation mode, backtest parameters, display options, and colors are independently adjustable
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ Settings Reference
Zone Detection
Max Base Candles — maximum number of low-momentum base candles to incorporate into zone boundaries (default: 2)
Move Strength (ATR x) — minimum departure candle range as a multiple of ATR (default: 1.2)
ATR Length — lookback for ATR calculation (default: 14)
Volume Multiplier — minimum volume relative to average when volume confirmation is enabled (default: 1.1)
Volume Avg Length — lookback for volume average (default: 20)
Min Body % of Range — minimum body size as a fraction of the departure candle's total range (default: 0.55)
Require Volume Confirmation — when on, departure candle must exceed the volume average by the configured multiplier (default: off)
Signal Filters
Fresh Zones Only — when on, only zones that have not been previously touched can trigger signals
One Signal Per Zone — when on, each zone produces a maximum of one signal regardless of subsequent valid touches
Min Rejection Wick % — minimum lower/upper wick as a fraction of bar range for rejection confirmation (default: 0.50)
Cooldown Bars — minimum bars between consecutive signals (default: 5)
Chart EMA Trend Filter — when on, requires price to be on the correct side of the trend EMA
Trend EMA Length — EMA period for the trend filter (default: 50)
Min Zone Grade — minimum grade required for a zone to generate signals. A+ / A / B / C (default: B)
ADX Filter — toggle the ADX trend strength gate
ADX Length / ADX Minimum — ADX calculation and threshold parameters (defaults: 14 / 18)
Volume Delta Filter — toggle the directional volume pressure requirement
Volume Delta Length — smoothing length for volume delta calculation (default: 14)
Require PD Zone — when on, longs require discount positioning, shorts require premium
Dealing Range Length — bars used for the equilibrium midpoint calculation (default: 50)
Liquidity Sweep
Enable Sweep Signals — toggle the sweep entry signal mode
Min Sweep Depth (ATR x) — minimum wick extension beyond the zone boundary to qualify as a sweep (default: 0.15)
HTF Zones
Show HTF Zones — toggle the higher timeframe zone overlay
HTF Resolution — the timeframe to pull HTF zones from (default: 60-minute)
VWAP Confluence
Show Session VWAP — toggle the VWAP line on the chart
VWAP Boosts Grade — when on, zones within VWAP tolerance receive 20 additional grade points
VWAP Tolerance (ATR x) — maximum distance from VWAP to qualify for the grade boost (default: 0.5)
Show VWAP Bands — toggle ±1σ band plots around the session VWAP
Backtest Stats
Track Signal Stats — toggle the live win/loss tracking system
Target (ATR x) — take-profit distance for stat tracking purposes (default: 2.0)
Stop (ATR x) — stop-loss distance for stat tracking purposes (default: 1.0)
Max Signals Tracked — rolling window size for the statistics tracker (default: 50)
Display
Max Active Zones / Side — maximum supply zones and demand zones maintained simultaneously (default: 3 per side)
Mitigation — Body Close or Wick Touch zone invalidation mode
Extend Zones Right — when on, zone boxes extend indefinitely to the right until mitigated
Show Zone Labels — toggle SUPPLY/DEMAND text labels on zones
Show Grade Badge — toggle A+/A/B/C grade badges on zone boxes
Show Stats Dashboard — toggle the full dashboard panel
Plot Trend EMA — toggle the trend EMA line on the chart
Show SL / TP on Signal — toggle stop and target guide circle plots on signal bars
Dashboard Position — Top Left / Top Right / Bottom Left / Bottom Right
Session
Buy / Sell Signals — master toggle for all entry signals
Session Filter — toggle the active hours restriction
Active Session — configurable session window string
Colors
Demand / Bull / Bull Bright — yellow-green family for all demand zones, signals, and labels
Supply / Bear / Bear Bright — red family for all supply zones, signals, and labels
HTF Zone — purple for higher timeframe zone overlays
VWAP / Equilibrium — purple for VWAP and equilibrium lines
SL Guide / TP Guide — stop and target circle colors
Sweep Signal — orange for liquidity sweep entry circles
Dash Text / Neutral / Dash BG / Dash Header / Dash Section / Dash Frame — full dashboard color control
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 Alert Conditions (6 total)
Entry Alerts
Fortress Demand Long — standard demand zone rejection long signal. All quality and filter conditions met
Fortress Supply Short — standard supply zone rejection short signal
Fortress Sweep Long — liquidity sweep and reclaim at demand zone. Sweep entry confirmed
Fortress Sweep Short — liquidity sweep and reclaim at supply zone
Zone Formation Alerts
New Demand Zone — a qualifying demand zone has been detected and added to the chart
New Supply Zone — a qualifying supply zone has been detected and added to the chart
All alert messages are formatted as const strings for clean webhook and notification platform integration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Recommended Settings by Instrument & Timeframe
The default configuration is optimized for XAUUSD, major forex pairs, and crypto on M1–M15 :
Move Strength at 1.2× ATR — sensitive enough to catch meaningful departures on fast-moving intraday instruments
Min Grade at B — filters out the lowest-quality zones while allowing solid B-grade setups to signal
Fresh Zones Only on — fresh, untested zones carry the most unfilled institutional orders
HTF at 60-minute — provides meaningful confluence context for intraday M1–M15 trading
Volume Confirmation off — reliable for futures and equities, unreliable for spot forex and crypto perpetuals
For other instruments or timeframes, adjust:
Higher timeframes (H1, H4) — increase Move Strength to 1.5–2.0× ATR, set HTF to Daily or Weekly, raise Min Grade to A, increase Dealing Range Length to 100–200
Crypto (BTC, ETH) — enable Volume Confirmation with 1.2× multiplier on exchanges with reliable volume data, increase Move Strength to 1.4–1.6, increase Min Sweep Depth to 0.25×
Indices (NAS100, US30) — enable Session Filter to 09:30–16:00, enable Volume Confirmation, set Min Grade to A for cleaner signal quality
More zones and signals — reduce Move Strength to 1.0, lower Min Grade to C, disable Fresh Zones Only, disable One Signal Per Zone
Fewer, highest-quality signals only — raise Min Grade to A or A+, enable Volume Confirmation, enable HTF Zones, set VWAP Boosts Grade on. Only A+ zones with VWAP and HTF alignment will produce signals
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
👥 Who This Is For
🏛 Supply and demand traders — FORTRESS is the most complete quantitative implementation of supply and demand zone trading available in the AlphaX suite. Every concept — zone quality, freshness, grade, mitigation, sweep detection — is encoded objectively and applied consistently
📊 Traders who want data on their strategy — the live backtest statistics tracker provides immediate, chart-specific feedback on how the current configuration is performing without leaving the platform
🥇 Gold (XAUUSD) and forex traders — supply and demand zone mechanics are most consistent on highly liquid institutional instruments. Default settings are calibrated for gold and major pairs
🌐 Multi-timeframe traders — the HTF zone overlay and VWAP confluence create a natural two-timeframe framework within a single indicator
🧠 Systematic traders — every entry parameter is quantified and configurable. The grading system replaces subjective zone quality assessment with objective numerical scoring
💧 Stop hunt and sweep traders — the dedicated sweep signal mode is purpose-built for traders who specifically want to enter on liquidity grab and reclaim events at institutional zones
⚠ Traders who want to stop chasing entries — FORTRESS enforces patience by design. You wait for institutional zones to form, wait for price to return, wait for the rejection candle, and wait for all filters to confirm — discipline is built into the system architecture
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📝 Notes
All signals are confirmed on bar close — the indicator is non-repainting by design. Zone detection, grading, mitigation, and signal logic all finalize on confirmed bars only
The live backtest statistics use ATR-based fixed targets and stops for tracking purposes. These are not the same as any broker-level trade execution. The purpose is configuration tuning, not performance reporting
Maximum 200 boxes, 200 labels, and 100 lines are rendered. On charts with long history and frequent zone formation, the oldest zones are automatically removed by TradingView's rendering limits. The Max Active Zones / Side setting provides additional control over zone count
HTF zone detection uses Pine Script's request.security function with lookahead off — HTF zones are non-repainting and reflect the HTF close price at each lower timeframe bar
The PD Zone equilibrium is calculated from the highest high and lowest low over the Dealing Range Length. On strongly trending instruments this level will shift progressively — it is a relative measure within the recent range, not a fixed level
The session VWAP resets at each session's first bar. For 24-hour crypto instruments, the VWAP anchors to the first bar of each calendar day. Consider disabling the VWAP grade boost on instruments where session definition is ambiguous
The sweep signal mode and standard zone rejection signal mode are independent. A zone that produces a sweep signal is marked as used (when One Signal Per Zone is enabled), preventing a subsequent standard rejection signal from the same zone — ensuring only one entry per zone regardless of which entry type fires first
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Disclaimer
This indicator is a technical analysis and visualization tool intended for educational and informational purposes only. It does not constitute financial advice or a recommendation to buy or sell any financial instrument. All signals are generated from historical and real-time price data using mathematical calculations — their accuracy or profitability is not guaranteed. Past performance of any signal type does not guarantee future results. Always conduct your own analysis, use proper risk management, and consult a licensed financial advisor before making any trading decisions. The author accepts no responsibility for any losses incurred from the use of this indicator.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built for traders who believe that the strongest entries are not found by predicting where price will go — but by knowing exactly where institutions have left their orders waiting. Indicador
OMSF Learning SpaceWelcome to the Omsf Learning Space.
This is not a commercial "holy grail" indicator, nor is it a rigid, corporate course. This is my personal sandbox and educational archive where I dissect market structure, breakout mechanics, and reversal setups.
THE CORE PHILOSOPHY:
Everything in this space is built upon my Omsf (Objective Market Structure Framework). Whether you are a beginner trying to understand how charts breathe, or an advanced trader looking for mechanical rules – this space is designed to give you a clear, visual reality check.
WHAT TO EXPECT:
This script is dynamic and will change organically over time. As I publish new trading ideas, research notes, or structural concepts, this indicator will adapt. Old parts might get swapped out, new experiments will be added, or it might evolve into a v2.0 down the road. There is no fixed schedule. It updates when it updates.
CURRENT VERSION (Launch):
Right now, we are looking at the foundational mechanics: Classic, rigid Pivots alongside the dynamic volatility adjustment of the Omsf.
- Toggle "Exercise 1" to stress-test both engines in the configuration sandbox.
- Toggle "Outlook" to see how classic Pivots perform when taken literally as a trend filter.
Enjoy the sandbox, play with the parameters, and use the Bar Replay. See you in the ideas section!
— arni Indicador
[ A L P H A X ] ANCHOR Delta Volume Adaptive Entry EngineAlphaX ANCHOR — Liquidity-Anchored Trailing Stop System with Delta Volume Profile, Adaptive Band Scaling, HVN Confluence & 6-Layer Entry Engine
AlphaX ANCHOR is a professional-grade trend-following and entry precision system built around a proprietary four-band liquidity-anchored trailing stop engine that adapts to volatility in real time. Where conventional trailing stops use a fixed ATR distance and flip on any close beyond it, ANCHOR builds a structured four-layer band system that breathes with market conditions — tightening automatically during low-volatility squeeze phases and expanding during expansion phases — while simultaneously computing a delta-weighted volume profile anchored to the current trend segment. The result is a system that does three things simultaneously: tells you the trend direction with structural confidence, shows you exactly where the institutional volume is concentrated within the current move, and fires precision entries only when price returns to the outer anchor band within a qualifying 6-layer confluence environment. Designed for swing traders, position traders, and trend-following scalpers across crypto, forex, gold, and indices on any timeframe.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚓ The Anchor Trail Engine — How It Works
The core of AlphaX ANCHOR is the four-band liquidity-anchored trailing stop system — a structured set of concentric ATR bands that trail price in the trend direction, each band serving a distinct role in the trade management framework.
Band architecture:
Band 1 (Inner) — the closest band to price. Set at the base multiplier × ATR distance (default: 6.5×). Acts as the tightest stop reference — for aggressive traders who want minimal drawdown and are willing to accept more noise exits
Band 2 (Mid-Inner) — base + 1.0× ATR additional offset. The intermediate reference zone
Band 3 (Mid-Outer) — base + 2.0× ATR additional offset. Structural breathing room for normal pullbacks
Band 4 (Anchor — Outer) — base + 3.0× ATR additional offset. The primary trend invalidation level. A close beyond this band flips the trend. This is the band the confluence engine watches for retest entries
Trailing mechanics:
In a bull trend, all four bands trail price upward — ratcheting higher with every bar that closes higher, never moving down. The trail is one-directional: in a bull trend, bands can only move up; in a bear trend, bands can only move down. This ratchet behavior prevents the bands from widening on pullbacks — once a level is established, price must return all the way to Band 4 before a trend flip is triggered. This single property is what makes ANCHOR bands structurally superior to simple ATR trailing stops: they do not exit on noise, only on genuine structural breakdowns.
Trend flip logic:
A trend flip occurs when the source price closes beyond Band 4 — the outer anchor level. On the flip bar, all four bands immediately reset to the opposite side of price at their respective ATR distances. A ▲ ANCHOR BULL or BEAR ▼ ANCHOR label marks every flip on the chart, giving you clear visual confirmation of every structural trend change.
Heatmap visualization:
When the Trailing Stop Heatmap is enabled, the space between all four bands is filled with gradient color layers — progressively more opaque from Band 1 to Band 4. This creates an immediate visual depth map of the trailing stop structure: the closer price is to Band 4, the deeper into the "danger zone" the pullback has penetrated. At a glance, you can see whether a pullback is shallow (barely in the inner fill) or deep (approaching the outer anchor line) without reading a single number.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌊 Adaptive Band Scaling — Breathing With Volatility
Standard ATR trailing stops maintain a fixed multiplier regardless of whether the market is in a squeeze or an expansion phase. ANCHOR solves this with an adaptive scaling system that continuously adjusts the effective band multiplier based on current volatility context.
How it works:
The current ATR value is percentile-ranked over the last 100 bars using a percentrank function, producing a real-time volatility percentile reading. Additionally, the system monitors whether Bollinger Bands are compressed inside Keltner Channels — the squeeze condition.
Three scaling states:
Squeeze active (BB inside KC) — multiplier scales down to the Adaptive Min Scale (default: 0.85×). Bands tighten. During a squeeze, price movement is compressed and the natural pullback range is narrower — tighter bands correctly reflect this reduced volatility and avoid giving back gains unnecessarily when the market is coiling
High volatility (ATR in top 75th percentile) — multiplier scales up to the Adaptive Max Scale (default: 1.15×). Bands widen. During expansion phases, price swings are larger and a wider band correctly avoids being stopped out by normal volatility noise
Normal conditions — multiplier stays at 1.0× the base setting. No adjustment needed
Dashboard readout:
The current adaptive scale is displayed live on the dashboard as a multiplier value (e.g., 0.85x SQZ or 1.15x) in real time, so you always know whether the system is in tight, normal, or wide band mode.
Why adaptive scaling matters: A fixed 6.5× ATR trailing stop is too wide during a squeeze and too tight during a volatility spike. Adaptive scaling means ANCHOR is always correctly sized for the current market environment — without any manual adjustment from you.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Delta-Weighted Volume Profile — Anchored to the Trend Segment
The volume profile in AlphaX ANCHOR is not a standard fixed-range profile. It is a trend-segment-anchored profile — recomputed from the exact bar where the current trend began (the last Band 4 flip) to the current bar. Every time the trend flips, the profile resets and starts building fresh from the new trend origin.
What this means in practice: The profile always shows you the volume distribution of the current institutional delivery move — not an arbitrary date range, not the last N bars, but specifically the price levels where volume has concentrated since the institutional trend began. This is the most relevant possible volume profile for understanding the current trade's context.
Delta weighting:
When Delta-Weighted Volume is enabled (default: on), each bar's contribution to the volume profile is adjusted by the estimated directional bias of that candle:
In a bull trend — the bull volume estimate (close position within the high-low range × total volume) is used. Bullish candles contribute more weight to their price levels than bearish candles
In a bear trend — the bear volume estimate is used. Bearish candles carry more weight
This delta weighting creates a profile that reflects not just where volume occurred, but where directionally committed volume occurred — the levels where buyers (in a bull trend) or sellers (in a bear trend) were most active. These are the genuine institutional accumulation and distribution zones, not just high-activity noise zones.
Profile structure:
The profile is divided into a configurable number of rows (default: 30), each representing an equal price bin across the trend segment's high-low range. The width of each bar in the rendered profile is proportional to the volume in that bin relative to the maximum bin volume — the widest bar is always the highest-volume level.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📍 POC, Value Area & HVN Detection
Point of Control (POC):
The single price bin with the highest volume in the current trend segment. This is the price level where the most delta-weighted volume has traded since the trend began — the most liquid price in the current institutional move. Plotted as a solid purple line extending from the trend start to the right edge of the profile. The POC price is displayed live on the dashboard and is available as a take-profit target mode.
Value Area High (VAH) and Value Area Low (VAL):
The price range containing a configurable percentage of total segment volume (default: 70%). The value area represents the zone where the market spent 70% of its time and volume — the institutional fair value range for the current trend segment. VAH is plotted as a dashed yellow-green line; VAL as a dashed red line. These levels act as natural support and resistance within the trend — price frequently respects VAH and VAL on pullbacks before continuing in the trend direction.
High Volume Nodes (HVNs):
Local volume peaks within the profile — bins where volume is higher than both the bin immediately below and the bin immediately above. These are the institutional congregation zones — price levels where significant two-sided activity occurred. HVNs frequently act as magnets: price is attracted to them, and once reached, tends to spend time at them before continuing. Identified algorithmically across all bins, HVN levels are plotted as horizontal lines extending from the trend start, styled and colored by the configured settings. The highest-volume HVN receives a bold line and a price label.
HVN confluence scoring:
The confluence engine awards 1 point when either the current close or the outer Band 4 level is within a tolerance of ±0.35× ATR of any HVN level. An entry that fires at the anchor band while simultaneously sitting at an HVN level means you are buying or selling at a level where the most institutional volume has transacted — a genuinely high-conviction entry location.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚖ Trend Equilibrium — Premium/Discount Positioning
The Trend Equilibrium line is the midpoint between the highest high and the lowest low since the current trend began (the trendHigh and trendLow of the segment). Plotted as a purple dotted line directly on the chart.
This level serves as the dynamic premium/discount divider for the current trend segment:
Below equilibrium = discount — price is in the lower half of the trend segment range. For bull trends, this is the institutional accumulation zone — the preferred entry location for long positions
Above equilibrium = premium — price is in the upper half of the range. For bear trends, this is the institutional distribution zone — the preferred entry location for short positions
The Require PD Zone setting enforces that long signals only fire when price is in discount and short signals only fire when price is in premium. This one filter alone eliminates a substantial class of low-quality entries — those that occur when price has already extended far from the segment midpoint and the risk/reward is structurally poor.
Unlike a fixed-range PD calculation, this equilibrium adapts dynamically to the current trend segment — it is always the midpoint of this trend's range, making it the most contextually accurate premium/discount reference available.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧠 The 6-Layer Confluence Engine
Entry signals fire only when price touches the outer Band 4 anchor level within a qualifying 6-layer confluence environment. Each layer votes independently. The default minimum is 4 of 6.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 1 — Anchor Trend Direction
Awards 1 point when the ANCHOR system's current trend direction agrees with the signal. Bull signals require trend == 1; bear signals require trend == -1. This is also a hard positional requirement — the anchor touch condition itself requires a bull trend for longs (price touching Band 4 from above) and a bear trend for shorts (price touching Band 4 from below). The trend direction is therefore inherently confirmed by the signal trigger condition.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 2 — HTF Bias
Awards 1 point when the higher timeframe EMA structure (default: 60-minute, 21/55 EMAs) agrees with the signal direction. The HTF condition for ANCHOR is stricter than in other AlphaX systems: the HTF fast EMA must be above the slow EMA and the HTF close must be above the HTF fast EMA for a bull vote — requiring both EMA alignment and price confirmation on the higher timeframe simultaneously.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 3 — ADX Trend Strength
Awards 1 point when ADX meets the minimum threshold (default: 18). Confirms the market is in a genuine trending phase where Band 4 retests are likely to produce continuation moves rather than range reversals.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 4 — Volume Delta
Awards 1 point when the estimated volume delta (bull volume EMA minus bear volume EMA) agrees with the signal direction. Confirms that the institutional order flow pressure at the anchor touch is directionally consistent with the trend. A Band 4 touch with opposing volume delta is a warning sign — institutions may be distributing at the level, not accumulating.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 5 — Premium/Discount Zone
Awards 1 point when price is in the correct zone relative to the trend equilibrium level — discount for longs, premium for shorts. A Band 4 touch in the discount zone means you are entering at the outer structural boundary of the trend and the lower half of the segment range — the optimal dual positioning that maximizes risk/reward.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Layer 6 — HVN Confluence
Awards 1 point when the current close or the Band 4 level is within ATR tolerance of any detected High Volume Node from the segment profile. This is the layer that bridges the trailing stop system and the volume profile — when a Band 4 retest coincides with an HVN, price is returning to the outer structural boundary precisely where the most institutional volume has traded. The convergence of structural (Band 4) and volumetric (HVN) confluence at the same price level is the highest-quality entry condition ANCHOR can detect.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏷 Signal Firing Logic
An ANCHOR signal fires when all of the following are simultaneously true:
Price has touched Band 4 from the correct side — low within Band 4 tolerance for longs (bull trend), high within Band 4 tolerance for shorts (bear trend)
The close is back on the correct side of Band 4 — close above Band 4 for longs, close below for shorts (confirming the touch was a retest, not a breakdown)
Confluence score meets or exceeds the configured minimum (default: 4 of 6)
Session filter confirms active hours (when enabled)
Signal cooldown has elapsed since the last signal (default: 8 bars)
Show Entry Signals is enabled
Live confluence display:
A small label near the current Band 4 level on the last bar shows the live bull and bear scores in the format B 5/6 · S 2/6 — updating in real time so you can monitor the confluence state without looking at the dashboard.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Exit Guidance System
ANCHOR provides two live guidance levels plotted as dotted circles on the chart when a signal fires — not hard mechanical exits, but institutionally informed price targets for use in your own exit planning.
SL Guide:
The stop loss guide is anchored to a configurable band (default: Band 4 — the outer anchor). The SL band can be set to any of the four bands depending on your risk tolerance. Band 4 represents the structural invalidation level — the trend has flipped if price closes beyond it. Band 1 is the tightest option for aggressive stop placement.
TP Guide (three modes):
POC Target (default) — the take-profit guide points to the current segment POC. This is the most structurally meaningful target: in a bull trend, a Band 4 retest entry with a POC target means you are entering at the lowest point of the trend's volume structure and targeting the price where the most institutional activity occurred. The POC frequently acts as a magnet — price is drawn back to it after pullbacks
Opposite Band — the TP guide points to the trendHigh (bull) or trendLow (bear) of the current segment — the opposite extreme of the trend range. Maximum trend extension target
ATR Multiple — a fixed ATR distance from the entry close (default: 2.5×). Simple and consistent across all instruments and timeframes
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📊 Live Dashboard
The real-time dashboard displays the complete internal state across four sections, updated on every bar.
TREND
Anchor Trend — current ANCHOR system trend direction: ▲ BULLISH or ▼ BEARISH. This is the primary trend state — the direction all long entries must align with
Adaptive — current adaptive scale multiplier (e.g., 0.85x SQZ, 1.00x, or 1.15x) with squeeze state flag. Tells you whether bands are currently tighter or wider than the base setting
PD Zone — current premium/discount position relative to the trend equilibrium: ◧ DISCOUNT, ◧ PREMIUM, or — EQ
FILTERS
HTF Bias — higher timeframe EMA alignment: ▲ BULL, ▼ BEAR, or — FLAT
ADX — live ADX value with ✓ or ✗ pass/fail
Vol Delta — current volume delta direction: ▲ BULL, ▼ BEAR, or —
Session — ✓ ACTIVE or ✗ OFF
VOLUME
POC — current Point of Control price level. Updated in real time as the profile builds
VAH / VAL — Value Area High and Value Area Low levels for the current trend segment
HVN Count — number of High Volume Nodes currently detected in the segment profile
CONFLUENCE
Bull Score — live 0–6 score. Background highlights yellow-green when threshold is met
Bear Score — live 0–6 score. Background highlights red when threshold is met
Anchor Band — the current Band 4 price level in real time — the exact price where the next retest entry would occur
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📈 Chart Visual System
Band 4 (Anchor — thick solid line) — the outer trailing stop and primary structural level. Yellow-green in bull trend, red in bear trend. The most important line on the chart
Band 3 (semi-transparent) — mid-outer reference, 2× ATR inside Band 4
Band 2 (more transparent) — mid-inner reference, 1× ATR inside Band 4
Band 1 (most transparent) — inner reference, base ATR distance from price
Heatmap fills — gradient color fills between all four bands. Deepening opacity toward Band 4 creates a visual depth map of trailing stop risk
Trend Equilibrium Line (purple dots) — the dynamic midpoint of the current trend segment's high-low range
▲ ANCHOR BULL / BEAR ▼ ANCHOR label — appears on every trend flip at the Band 4 flip price, marking each structural direction change
▲ Triangle (below bar) — long entry signal at Band 4 retest with confluence confirmed
▼ Triangle (above bar) — short entry signal at Band 4 retest with confluence confirmed
Live confluence label — B x/6 · S x/6 score label near the current Band 4 level on the last bar, updating in real time
Volume profile bars — delta-weighted horizontal bars rendered to the right of the current price, color-matched to trend direction, proportional to bin volume
POC line (purple solid) — the highest-volume level in the current trend segment
VAH line (yellow-green dashed) — Value Area High boundary
VAL line (red dashed) — Value Area Low boundary
HVN lines — horizontal lines at every local volume peak. The dominant HVN (highest volume) receives a bold line and price label
SL Guide (red dotted circles) — stop loss reference level at the configured anchor band
TP Guide (yellow-green dotted circles) — take-profit reference pointing to POC, opposite band extreme, or ATR target
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚀 How to Trade with AlphaX ANCHOR — Step by Step
Step 1 — Establish Trend Context
Check the dashboard: what is the Anchor Trend? This is your trading direction — only take longs in ▲ BULLISH, only take shorts in ▼ BEARISH
Check HTF Bias — does the higher timeframe agree? A bull Anchor Trend with bull HTF Bias is the ideal setup condition
Check the Adaptive row — is the system in squeeze mode (0.85x SQZ)? If so, bands are tighter and a Band 4 touch is more likely. Expansion mode (1.15x) means wider bands and deeper pullbacks to reach Band 4
Note the POC and VAH/VAL levels on the dashboard and the chart. These are your key target and support/resistance levels within the current trend
Step 2 — Watch for Band 4 Approach
Monitor the heatmap — as price pulls back from the trend high, it moves progressively through the Band 1, 2, 3 fills. By the time price is deep in the Band 3 fill and approaching the solid Band 4 line, a retest touch is imminent
Check the live confluence label near Band 4. Is the bull score at or near the threshold? If so, a signal may fire on the next bar
Check the PD Zone row — is price in discount for a long entry? A Band 4 touch in discount zone is the optimal entry scenario
Step 3 — Enter on the ANCHOR Triangle
A ▲ triangle confirms the Band 4 touch with qualifying confluence. Enter on the close or next bar open
Note whether an HVN level is near the entry price — an HVN + Band 4 confluence entry is the highest-quality ANCHOR setup
The SL Guide dotted line shows your stop reference. The TP Guide shows the POC, opposite extreme, or ATR target depending on your mode setting
Step 4 — Manage with the Band Structure
As the trade moves in your favor, watch the bands ratchet upward (bull) with price — your trailing stop is automatically rising
The POC line is your primary profit target in POC Target mode. As price approaches the POC, consider scaling out
The VAH level (bull trend) acts as the next resistance after POC — if price clears VAH with momentum, the trade has potential to reach the trendHigh
If price pulls back into the Band 3 or Band 4 zone again without a trend flip, this is a secondary entry opportunity — the same confluence check applies
Step 5 — Trend Flip Exit
A close beyond Band 4 triggers a trend flip — the BEAR ▼ ANCHOR label appears, the bands invert, and the volume profile resets for the new trend segment
Exit the prior trend position on the flip bar or the following open
Wait for the new trend to establish and a Band 4 retest to develop in the new direction before re-entering
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Identifying Low-Quality Conditions — When Not to Trade
Stand aside when:
Trend flips are occurring rapidly — multiple ▲ / ▼ ANCHOR flip labels in quick succession indicate a choppy, oscillating market where the Band 4 trailing stop is being crossed repeatedly. The volume profile will be very short (few bars since last flip) and the POC will be meaningless. Wait for a trend to establish and sustain for at least 10–15 bars before looking for Band 4 retest entries
HTF Bias opposes the anchor trend — a bull ANCHOR trend with bear HTF Bias means the current timeframe is moving against the higher timeframe flow. Band 4 retest entries in this environment carry significantly reduced success rates
ADX ✗ on the dashboard — the market is not trending. ANCHOR is a trend-following system by design — Band 4 touches in ranging markets frequently result in immediate trend flips rather than continuations
HVN Count shows 0 — the volume profile has not yet built enough data to identify volume nodes. This typically occurs immediately after a fresh trend flip. Wait for the trend to develop more bar history before relying on HVN confluence
Adaptive shows 1.15x (expansion) and price is approaching Band 4 rapidly — high-volatility expansion phases can produce fast, aggressive moves to Band 4 and beyond. Reduce position size in expansion mode entries
Price is in premium for a bull entry or discount for a bear entry — the PD Zone filter will block these automatically when enabled, but if disabled, be aware that entries at the wrong side of equilibrium carry structurally poor risk/reward
The ideal ANCHOR setup condition:
Anchor Trend established for 15+ bars — sufficient history for meaningful volume profile
HTF Bias aligned with trend direction
ADX ✓ confirming a trending market
Adaptive at 1.0x or 0.85x (normal or squeeze — not expansion)
Price in discount (bull) or premium (bear)
Band 4 touch coincides with a visible HVN level
Confluence score at 5/6 or 6/6
When all these conditions align simultaneously, an ANCHOR entry is the closest to a textbook institutional continuation setup the system can produce.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚡ Key Features
⚓ Four-band liquidity-anchored trailing stop — Band 1 through Band 4, each ATR offset apart, ratcheting in trend direction with a one-directional lock preventing widening on pullbacks
🌊 Adaptive band scaling — automatically tightens during squeeze phases and widens during high-volatility expansion. Scale multiplier displayed live on dashboard
🔥 Trailing stop heatmap — gradient opacity fills between all four bands creating a real-time visual depth map of pullback risk from shallow to deep
📊 Delta-weighted volume profile — anchored to the current trend segment from the last Band 4 flip, using directional volume weighting for institutional accuracy
📍 POC detection — highest-volume level in the current trend segment plotted live and available as a TP target mode
📐 Value Area High/Low — 70% volume concentration zone for the current trend segment, plotted as dynamic support/resistance levels
🔮 HVN detection — algorithmic local volume peak identification across all profile bins. Lines extend from the trend origin through the profile
⚖ Trend equilibrium — dynamic PD zone midpoint anchored to the current trend segment high and low, updating in real time as the segment expands
📡 HTF bias filter — dual-EMA + price confirmation from a configurable higher timeframe, stricter condition than standard EMA crossover
🧠 6-layer confluence gate — Anchor Trend, HTF Bias, ADX, Volume Delta, PD Zone, and HVN Confluence all scored independently on every bar
📊 Live confluence label on chart — B x/6 · S x/6 displayed near Band 4 in real time without requiring dashboard attention
🎯 Three TP target modes — POC Target (institutional magnet), Opposite Band (maximum trend extension), or ATR Multiple (fixed distance)
⚙ Configurable SL anchor band — choose Band 1 through Band 4 for stop placement based on your risk preference and trading style
🏷 Trend flip labels — ▲ ANCHOR BULL and BEAR ▼ ANCHOR labels mark every structural trend change on the chart
📊 18-row live dashboard — Trend, Filters, Volume, and Confluence sections updated in real time
🔔 6 alert conditions — bull/bear trend flips, long/short entries, and HVN + anchor confluence touches
🎨 Fully cohesive dual-tone color system — yellow-green for all bullish elements, red for all bearish, orange for squeeze, purple for VWAP/equilibrium/POC
⚙ Fully configurable — ATR length, base multiplier, adaptive scaling range, volume profile rows and width, value area percentage, HTF timeframe and EMA periods, ADX threshold, PD zone requirement, TP mode, SL band, and all colors are independently adjustable
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙ Settings Reference
Anchor Trail Engine
ATR Length — lookback for the ATR calculation used in all band offsets (default: 14)
Source — price source for trailing stop calculations (default: close)
Band Offset (Base) — ATR multiplier for Band 1, the innermost band. Bands 2–4 add +1, +2, +3 automatically (default: 6.5)
Adaptive Band Scaling — toggles the volatility-adaptive multiplier adjustment
Adaptive Min Scale — multiplier floor applied during squeeze conditions (default: 0.85)
Adaptive Max Scale — multiplier ceiling applied during high-volatility expansion (default: 1.15)
Volume Profile
Show Volume Profile — toggle the rendered profile bars to the right of price
Profile Rows — number of price bins in the volume profile (default: 30)
Profile Width (Bars) — maximum horizontal width of the profile in bars (default: 40)
Delta-Weighted Volume — when on, weights each bar's contribution by directional candle bias
Show HVN Levels — toggle horizontal High Volume Node lines
HVN Line Style — Dotted / Solid / Dashed
HVN Line Width — thickness of HVN lines (default: 1)
Show Value Area (POC/VAH/VAL) — toggle POC, VAH, and VAL line plots
Value Area % — percentage of total volume used to define the value area boundaries (default: 70%)
Show Trend Equilibrium — toggle the dynamic segment midpoint line
Confluence & Entries
HTF Trend Filter — toggle the higher timeframe EMA bias requirement
HTF Timeframe — the higher timeframe for EMA calculations (default: 60-minute)
HTF Fast / Slow EMA — EMA periods on the higher timeframe (defaults: 21 / 55)
ADX Trend Filter — toggle the ADX minimum requirement
ADX Length — ADX calculation lookback (default: 14)
ADX Minimum — threshold below which signals are suppressed (default: 18)
Volume Delta Filter — toggle the volume delta directional requirement
Volume MA Length — EMA smoothing length for volume delta calculation (default: 14)
Require PD Zone — when on, longs require discount positioning, shorts require premium
Session Filter — toggle active hours restriction (default: off — ANCHOR is designed for all-session use on most instruments)
Active Session — configurable session window
Min Layers (of 6) — minimum confluence score to fire a signal (default: 4)
Signal Cooldown — minimum bars between consecutive signals (default: 8)
Show Entry Signals — toggle signal triangles on or off
Show Confluence Label — toggle the live B/S score label near Band 4
Exit Guidance
Show SL / TP Guides — toggle the guide level dotted circle plots
SL Anchor Band — which of the four bands to use as the stop loss reference (default: Band 4)
TP Target Mode — POC Target / Opposite Band / ATR Multiple
TP ATR Mult — ATR distance for the ATR Multiple TP mode (default: 2.5)
Display
Trailing Stop Heatmap — toggle the gradient opacity fills between bands
Trend Flip Labels — toggle the ▲ ANCHOR BULL / BEAR ▼ ANCHOR labels
Show Dashboard — toggle the full dashboard panel
Dashboard Position — Top Left / Top Right / Bottom Left / Bottom Right
Colors
Bull / Bull Bright — yellow-green family for all bullish bands, fills, and labels
Bear / Bear Bright — red family for all bearish elements
Squeeze — orange for squeeze state indicators
Equilibrium — purple for the trend equilibrium line
POC Line — purple for the Point of Control
VAH / VAL Lines — yellow-green and red for value area boundaries
SL Guide / TP Guide — stop and target guide line colors
Bull / Bear Label Text — text color for confluence and flip labels
Dash Text / Dash BG / Dash Header / Dash Section / Dash Frame — full dashboard color control
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔔 Alert Conditions (6 total)
Trend Alerts
Anchor Bull Flip — trend has anchored bullish. Band 4 closed above, all bands reset upward. Watch outer band for pullback entry development
Anchor Bear Flip — trend has anchored bearish. Band 4 closed below, all bands reset downward
Entry Alerts
Anchor Long Entry — Band 4 touched from above with confluence confirmed. Long signal fired
Anchor Short Entry — Band 4 touched from below with confluence confirmed. Short signal fired
HVN Confluence Alerts
HVN + Anchor Long Touch — price is touching the anchor band at or near a High Volume Node support zone. Pre-signal awareness alert
HVN + Anchor Short Touch — price is touching the anchor band at or near a High Volume Node resistance zone
All alert messages are formatted as const strings for clean webhook and notification platform integration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 Recommended Settings by Instrument & Timeframe
The default configuration is optimized for XAUUSD, major forex pairs, crypto, and indices on M5–H1 . ANCHOR is uniquely versatile — the volume profile adapts to any trend length and the adaptive scaling handles any volatility regime:
Band Offset at 6.5× — wide enough to avoid noise exits on intraday timeframes while keeping the trail structurally relevant
HTF at 60-minute — provides meaningful context for M5–M15 intraday trading
Delta-Weighted Volume on — directional weighting produces the most institutionally relevant profile on all liquid instruments
Value Area at 70% — the standard institutional value area definition used by professional volume profile traders
Session filter off by default — ANCHOR is designed for continuous multi-session trading on most instruments
For other instruments or timeframes, adjust:
M1–M3 scalping — reduce Band Offset to 4.5–5.5, reduce ATR Length to 10, increase Profile Rows to 20 for faster profile builds
H4 / Daily swing trading — increase Band Offset to 8.0–10.0, set HTF to Weekly, reduce Profile Rows to 15–20 for cleaner node identification, increase TP ATR Mult to 4.0–5.0
Crypto (BTC, ETH) — increase Adaptive Max Scale to 1.25 to accommodate wider expansion swings, increase Band Offset to 7.5–8.5
Low-volatility forex pairs — reduce Band Offset to 5.5–6.0, reduce Adaptive Min Scale to 0.80 for tighter squeeze-phase bands
Tighter signal quality — raise Min Layers to 5/6, enable PD Zone requirement, raise ADX minimum to 22
More frequent signals — lower Min Layers to 3, disable HTF filter, disable PD Zone requirement
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
👥 Who This Is For
📈 Trend followers and swing traders — the four-band trailing stop with heatmap visualization is built specifically for riding extended directional moves with structural confidence, not second-guessing every pullback
📊 Volume profile traders — the delta-weighted, trend-anchored profile provides the most contextually relevant volume analysis available for any given trend segment
🥇 Gold (XAUUSD) and forex traders — default settings are tuned for these instruments. The adaptive band scaling handles XAUUSD's distinctive alternation between low-volatility coiling and high-velocity expansion
🎯 Pullback entry traders — ANCHOR is specifically designed to fire at the outer structural boundary of the trend (Band 4) rather than on breakouts or initial moves. Every entry is a pullback-to-structure trade at the institutional trailing stop level
📡 Multi-timeframe traders — the HTF bias filter and trend equilibrium system create a natural multi-timeframe framework within a single indicator
🧠 Traders who want volume context with every entry — the live POC, VAH/VAL, and HVN levels provide immediate institutional volume context for every trade without requiring a separate volume profile tool
🔥 Visual traders — the heatmap, gradient fills, trend flip labels, and volume profile create one of the richest single-indicator chart environments in the AlphaX suite. Everything needed for a complete trend trade is visible on the chart simultaneously
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📝 Notes
All signals are confirmed on bar close — the indicator is non-repainting by design. Band positions and trend state finalize on confirmed bars only
The volume profile is recomputed on every bar using the full trend segment history. On very long trend segments (hundreds of bars), this computation is resource-intensive. The max_bars_back is set to 5000 to accommodate extended trend segments. If you notice performance degradation on very low timeframes with long chart history, reduce Profile Rows or reduce the chart's visible bar count
The volume profile is rendered only on the last bar and redrawn on every real-time update. Historical bars show the band structure but not the profile rendering — the profile always reflects the current trend segment state
When a trend flip occurs, the volume profile resets completely. The first few bars after a flip will show a very short profile with minimal data — meaningful HVN confluence typically requires 15–20+ bars of trend history to develop
The adaptive scale is based on ATR percentrank over 100 bars. On instruments or timeframes with less than 100 bars of history, the percentrank may not be fully calibrated. This is a warm-up effect and resolves naturally as history accumulates
The session filter is off by default because ANCHOR is designed as a multi-session trend system. Unlike scalping systems that are most effective during active hours, ANCHOR band retests can occur at any time during a developing trend. Enable the session filter only if you specifically want to restrict entries to active trading hours on your instrument
The Trade Status section tracks position direction from signal to exit within the chart session — it does not connect to your broker or brokerage account
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚠ Disclaimer
This indicator is a technical analysis and visualization tool intended for educational and informational purposes only. It does not constitute financial advice or a recommendation to buy or sell any financial instrument. All signals are generated from historical and real-time price data using mathematical calculations — their accuracy or profitability is not guaranteed. Past performance of any signal type does not guarantee future results. Always conduct your own analysis, use proper risk management, and consult a licensed financial advisor before making any trading decisions. The author accepts no responsibility for any losses incurred from the use of this indicator.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built for traders who understand that the most powerful entries are not at the breakout — they are at the moment price returns to the structural anchor where institutions are waiting. Indicador
